Frigidaire M Series Ignition Coil Kit / Dryer Gas Valve Solenoid Coil Kit 5303931775, Replaces 08015679, 08015680, 3201243, 3201244, 3281142, 3281143, 5300622602, 5303307291, 5303307292, 5308015680, F140570-300, F140570-

Genuine Frigidaire two-piece gas-valve coil kit for gas clothes dryers. The kit contains one 2-wire secondary coil and one 3-wire booster coil; both coils are used together to open the gas valve during dryer operation.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• No heat
• Insufficient heat
• Dryer takes too long to dry
• Dryer heats initially but stops heating after several minutes
• Intermittent burner ignition or failure to maintain burner operation

Check Before Replacing

• Disconnect electrical power and shut off the dryer’s gas supply before inspection or service.
• Confirm the dryer is configured for gas operation and that the external gas supply is available; do not bypass safety devices.
• With power disconnected, inspect both coil connectors and wiring for loose connections, damaged insulation, corrosion, or signs of overheating.
• If qualified to perform electrical testing, check each coil for continuity according to the appliance’s service documentation; continuity alone does not prove that the coil is operating correctly.
• During a normal heating cycle, observe only through the appliance’s approved inspection opening, if provided: an igniter that glows but does not produce or maintain burner ignition can be consistent with a gas-valve-coil problem, but other components can cause the same symptom.

Pro Tip

Part Details

Key Features

• Genuine Frigidaire OEM gas-valve solenoid coil kit
• M Series ignition-coil design
• Includes one 2-wire secondary coil and one 3-wire booster coil
• Used together to open the dryer gas valve during heating
• Appliance-specific fitment should be confirmed by full model number before ordering

Installation Notes

• Disconnect electrical power and shut off the gas supply before beginning.
• Access procedures vary by dryer model; follow the model-specific service instructions for panel removal.
• Disconnect the coil wire harnesses before removing the retaining bracket and old coils.
• Install both replacement coils in the same positions and preserve the spacer and bracket arrangement.
• Reconnect the wiring and reinstall all panels and guards before restoring gas and electrical service.
• After service, check for normal operation and stop immediately if a gas odor or abnormal ignition is observed.

Verified Compatible Models

417.97042700, 41759012890, 41759022890, 41771712510, 41771712511, 41771712512, 41771722510, 41771722511, 41771722512, 41771723510, 41771723511, 41771723512, 41771732810, 41771732811, 41771733810, 41771733811, 41774182300, 41774182301, 41779042900, 41779042990, 41779042991, 41779052990, 41779052991, 41788980100, 41788989100, 41788989800, 41790032990, 41790042990, 41790042991, 41790052990, 41790052991, AGQ8000FG1, DE28A5DTFB, DE28A5WTFB, DE28A5YTFB, DE28A7DTFB, DE28A7WTFB, DE28T3DTFB, DE28T3WTFB, DG250KXD1, DG250KXD3, DG650KXD5, DG2000DL1, DG2000DW1, DG6520AL1, DGCIFW3, DGFW1, GGR442CS0, MLXG62RBW3, WGR242AQ2

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
