The W11543994 is the OEM electronic control board for select Whirlpool top-load washers. If your washer won't start, displays F# E# error codes, stops mid-cycle, or has completely unresponsive controls, the main control board — the brain of your machine — is the most likely cause. This is the exact factory replacement part to restore full function.

✓ Model-Specific Repair Pages

Don't see your model? Contact us for fit verification before ordering.

The control board (CCU) manages every function of your washer — motor, water fill valves, drain pump, lid lock, spin speed, load sensing, shift actuator, and communication with the user interface. When it fails due to a power surge, moisture intrusion, or component burnout, the washer may appear completely dead or behave erratically even when individual components test fine.

✓ Common Symptoms Fixed

Washer won't start or turn on, displays persistent F# E# error codes, stops mid-cycle without completing, won't advance through cycles, unresponsive control panel, washer completely dead with no response, or erratic and unpredictable behavior during any cycle.

✓ Key Features & Specifications

OEM part number: W11543994. Replaces: W11297429, W11201284, W11105155, W11105148, W11284145, W11419173, W11479877, W11498803, W11538088. Genuine OEM replacement — direct fit, no modifications required. Compatible with Whirlpool, Maytag, Amana, Roper, Crosley, and Kenmore top-load washers. Moderate 30–45 minute DIY repair. Weight: 10 lbs.

✓ Buying Options

OEM / New: The original factory-manufactured control board. Guaranteed to meet Whirlpool's original specifications for fit, form, and function. This is the same part installed at the factory — exact plug-and-play replacement with no programming required.

Used / Tested: A pull from a working machine, tested for functionality. Ideal for budget-conscious repairs or when an OEM new part is unavailable. All used parts are inspected before listing.

✓ Replacement Part Numbers

W11543994 (OEM) | Replaces: W11297429, W11201284, W11105155, W11105148, W11284145, W11419173, W11479877, W11498803, W11538088 | W11543994XP (aftermarket cross-reference)

✓ Installation Tips

Unplug the washer before beginning any repair. The control board is located under the main top panel — remove the three screws at the rear of the top panel, tilt it forward, and the board is mounted to the cabinet frame. Photograph all wire harness connections before disconnecting. Reconnect all connectors firmly, restore power, and run a diagnostic cycle to confirm the repair. If error codes persist, perform a hard reset by unplugging for 5 minutes before running diagnostics.

✓ Compatible Models

MVW6230HC0, MVW6230HC1, MVW6230HW0, MVW6230HW1, MVW6230RHW0, MVW6230RHW1 — and additional Whirlpool, Maytag, Amana, Roper, Crosley, and Kenmore top-load models. Check product tags for your model number or contact us to confirm fit.

✓ Frequently Asked Questions

How do I know if my washer control board is bad?
If you've tested the lid lock, motor, pump, and valves and they check out fine but the washer still malfunctions — the control board is the likely culprit. Persistent F# E# error codes that don't clear after a reset are a strong indicator.

Is this an OEM part?
Yes. W11543994 is the genuine OEM replacement board manufactured to Whirlpool's factory specifications.

How difficult is installation?
This is a moderate 30–45 minute DIY repair. Always unplug the washer before working on electrical components. Contact our support team if you need guidance.
