Range Burner Won't Turn Off? GE Infinite Switch WS01F06677 – Fix Burner Stuck on High Fast

⚠️ This part (WS01F06677) is No Longer Available from GE. We recommend contacting us for a compatible alternative before ordering.

If your GE range burner won't shut off, stays stuck on high, or won't respond to the control knob, the infinite switch is the most common cause. In GE PCS940 series ranges, the infinite switch regulates burner heat by cycling power on and off. When it fails, the burner may run continuously at full heat or become completely unresponsive. ⚡ Common failure point in GE-built dual-fuel and electric ranges. Part WS01F06677 is the genuine OEM replacement that restores proper burner heat control and safe operation.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

• ✔ QUALIFIER 1 — Range powers on and other burners work normally
• ✔ QUALIFIER 2 — Oven and other functions operate correctly
• ✔ QUALIFIER 3 — Power supply and wiring to the burner confirmed OK
• ✔ ONLY problem is one burner stuck on high, won't turn off, or knob has no effect

Not sure? Send us your model number — we'll confirm before you order.

🔧 Common Symptoms

• Burner stays on full heat regardless of knob position
• Burner won't turn off after cooking
• Control knob turns freely but has no effect on burner output
• Burner cycles erratically or won't maintain a consistent temperature

✔ If these symptoms match, the infinite switch is the most likely failed component in the surface burner circuit.

✔ In most cases, replacing the infinite switch restores normal burner heat control immediately.

📦 Part Details

• Part Number: WS01F06677
• Type: Infinite Switch Assembly — controls surface burner heat output by cycling power
• Replaces: 222D5231G005
• Brands: GE
• SKU: A024708G
• Availability: No Longer Available (NLA) — contact us for alternatives

⚙️ Installation

Skill Level: MODERATE — 30–60 minutes. Disconnect power before servicing. Remove the cooktop or range top panel to access the switch mounting bracket. Disconnect the wiring harness, remove the retaining screws, swap the switch, and reconnect in reverse order. Confirm burner cycles correctly at low, medium, and high settings before reassembling.

✓ Compatible Models

Confirmed compatible with PCS940DF1BB, PCS940DF1WW, PCS940DF2BB, PCS940DF2WW, PCS940DF3WW, PCS940DF4WW, PCS940EJ1ES, PCS940EJ2ES, PCS940SF1SS, PCS940SF2SS, PCS940SF3SS, PCS940SF4SS plus additional GE PCS940 series models. Contact us to verify your model number before ordering.
