Front-Load Washer Leaking at the Door? Door Boot Spring Clamp 134616200 – Fix Bellow Seal Leaks Fast

A loose or broken door boot clamp is one of the most overlooked causes of front-load washer door leaks. In most Electrolux and Frigidaire front-load washers, the door boot spring clamp holds the door bellow (boot seal) firmly against the front panel and drum lip. When the clamp stretches, corrodes, or snaps, the bellow loses its seat and water escapes from the door area during every cycle. ⚡ Frequently missed during bellow replacements — a worn clamp on a new bellow causes repeat leaks within months. Part 134616200 is the genuine OEM replacement clamp that locks the door bellow in place and eliminates seal-related leaks immediately.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

• ✔ Washer powers on and runs normally
• ✔ Door bellow rubber itself is intact — no visible tears or cracks
• ✔ Water supply and drain lines confirmed OK
• ✔ ONLY problem is water leaking from the door edge, or the bellow visibly pulling away from the front panel or drum lip

Not sure? Send us your model number — we'll confirm before you order.

🔧 Common Symptoms

• Water leaking from the front door edge during or after a wash cycle
• Door bellow visibly sagging, pulling away, or not seated flush against the panel
• Clamp visibly stretched, corroded, broken, or missing
• Leak returns shortly after a door bellow replacement (clamp was not replaced)

✔ If these symptoms match, this is the most likely failed component in the system.

✔ In most cases, replacing this spring clamp restores a firm, watertight bellow seal immediately.

📦 Part Details

• Part Number: 134616200
• Replaces: 7134616200
• Type: Front Load Washer Door Boot Spring Clamp (Outer Retaining Clamp)
• Brands: Electrolux, Frigidaire
• OEM: Genuine Electrolux replacement part

⚙️ Installation

Skill Level: Easy — 20–30 minutes. Disconnect power before servicing. Peel back the outer edge of the door bellow to expose the existing clamp, remove the old clamp using needle-nose pliers or a flat screwdriver, seat the new spring clamp into the bellow groove around the full circumference of the front panel opening, and press firmly until the clamp snaps into place. Verify the bellow is seated flush before closing the door and running a test cycle.

✓ Compatible Models

Confirmed compatible with select Electrolux and Frigidaire front-load washer models including EFLS517, EFLS527, EFLS617, EFLS627, ELFW7537, and ELFW7637 series. Contact us to verify your model number before ordering.

💡 Pro Tip
