Frigidaire / Electrolux Refrigerator evaporator fan motor 242219206, Replaces 242077704, 5304530651, 5304539152

Genuine OEM evaporator fan motor for refrigerators. The motor circulates air through the fresh-food compartment and refrigerator/freezer compartments to support even cooling.

Is This the Right Part?

Common Symptoms

• Freezer not freezing properly
• Fresh-food compartment warm while the freezer remains cold, or the reverse
• Little or no airflow from the refrigerator vents
• Unusual fan noise such as grinding or squealing
• Frost or ice buildup around the evaporator area
• Refrigerator runs continuously while cooling performance declines

Check Before Replacing

• With the refrigerator operating, listen for a steady evaporator-fan sound when the compressor is running.
• If the design permits, press and hold the freezer door switch while observing or listening for fan operation; do not bypass or defeat the switch permanently.
• With power disconnected, check whether the fan blade turns freely by hand and inspect for visible frost, ice, or a broken blade.
• If qualified to perform electrical testing, disconnect power and check the motor windings for continuity with a multimeter; lack of continuity indicates the motor circuit is open, but other refrigerator faults can produce similar symptoms.

Pro Tip

Part Details

Key Features

• Genuine OEM Frigidaire/Electrolux refrigerator evaporator fan motor
• Designed to circulate air through the fresh-food and freezer compartments
• Used on select Frigidaire refrigerators
• 120 VAC motor specification documented by an appliance-parts distributor

Installation Notes

• Disconnect electrical power before servicing the refrigerator.
• Safely protect or remove perishable food before leaving the refrigerator without power.
• Access is through the evaporator/fan area behind the applicable rear panel; disconnect the motor wiring before removing the motor.
• After installation, confirm that the fan blade turns freely, the wiring connector is secure, and airflow returns before fully completing reassembly.

Verified Compatible Models

FFHI1835VS0, FFHI1835VS1, FFHI1835VS2, FFHI1835VS3, FFHI1835VS4, FFHI1835VS6, FFHT1814VB0, FFHT1814VW0, FFHT1814WB0, FFHT1814WB1, FFHT1814WB2, FFHT1814WB3, FFHT1814WB4, FFHT1814WW0, FFHT1814WW1

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
