LG Dryer Drum Belt 4400EL2001F — Fix a Drum That Won’t Spin
4400EL2001F is a genuine LG poly-V dryer drum belt used on select LG-built dryers. It is the current OEM number, replacing older LG numbers 4400EL2001A, 4400EL2001C and 4400EL2001E.
The belt wraps around the dryer drum, motor pulley and idler system to rotate the drum. A broken, stretched or displaced belt can cause the drum not to turn.
Similar symptoms can also result from the motor, idler pulley, drum rollers, belt switch or another component. Confirm the complete dryer model before ordering.
Disconnect electrical power before service and follow the model-specific belt-routing diagram.
❓ Is This the Right Part?
Inspect the belt and related drive components before ordering. This part may be correct if:
- ✔ Your dryer is an LG, Kenmore or Kenmore Elite built on an LG platform
- ✔ Your model number appears in the confirmed compatible list below
- ✔ The dryer powers on and the motor runs, but the drum does not rotate
- ✔ The original belt is visibly broken, stretched or has slipped off the pulleys
- ✔ The motor, idler pulley, drum rollers and belt switch have been inspected and are not the cause
Not sure? Send us your model number — we’ll confirm before you order.
🔧 Common Symptoms
- Dryer drum not spinning while motor runs
- Clothes still wet after a full cycle — drum was stationary
- Loud thump or snap heard before drum stopped turning
- Belt visible broken or lying loose inside the drum cabinet
- Dryer starts then stops immediately — belt switch triggered
- Burning rubber smell from the dryer cabinet
A damaged belt is one possible cause of a drum that does not rotate. The motor, idler pulley, drum rollers and belt switch should also be inspected before ordering.
📦 Part Details
- Part Number: 4400EL2001F (Genuine OEM — Current)
- Verified Old Numbers: 4400EL2001A, 4400EL2001C, 4400EL2001E
- Type: Poly-V dryer drum drive belt — approx. 92 inches long, 1/4 inch wide, 4 ribs / 3 grooves
- Brands: LG; used in select LG, Kenmore and Kenmore Elite dryers
Inspect the idler pulley and drum rollers while the dryer is open and replace only worn or damaged components. These parts are accessible during the same repair and replacing them when defective prevents a repeat teardown.
⚙️ Installation
Skill Level: Moderate — 30–45 minutes. Disconnect electrical power before beginning. Remove the top panel and front panel to access the drum. Slip the old belt off the drum and motor/idler pulleys, route the new belt around the drum (ribbed side against the drum), then thread it around the idler pulley and motor pulley following the model-specific belt-routing diagram on the cabinet interior or in the service manual for your model. Reassemble in reverse and run a short test cycle before loading laundry.
✓ Compatible Models
Confirmed compatible with 79661552610, 79661553610, 79671552610, 79671553610, 79681392610, 79681393610, 79691392610, 79691393610, DLE7200WE, DLEX3570V, DLEX3570W, DLEX7600KE, DLEX7600WE, DLEY1901KE, DLEY1901WE, DLG4971W, DLGX5781VE, DLGX5781WE, DLGX7601KE, DLGX7601WE, DLGY1702V, DLGY1902KE, and 100+ additional LG and Kenmore models. Contact us to verify your model number before ordering.
💡 Pro Tip
Before pulling the broken belt out, photograph the idler pulley and motor pulley routing from multiple angles — even a snapped belt will show you the correct path. Incorrect belt routing is the #1 cause of callbacks on this repair, and a 10-second photo eliminates that risk entirely.
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
