LG Dryer Distortion Spring 4970EL4002C, Replaces 4970EL4002A

Genuine LG dryer distortion spring used at the lint-filter assembly / lint-screen cover area.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Lint screen or cover feels loose or does not seat flush.
• Filter flap does not return or close correctly after the lint screen is removed.
• Lint may escape around a cover that is not held securely.
• A damaged or missing spring can contribute to lint-filter fit or airflow problems.

Check Before Replacing

• Unplug the dryer before inspection.
• Remove the lint screen and visually check whether the spring is missing, distorted, disconnected, or visibly damaged.
• With the dryer unplugged, verify that the lint-screen flap moves freely and returns to its normal position under spring tension.
• Check that the lint screen and cover seat flush and that lint buildup is not obstructing the filter area.
• Clean the lint filter and inspect the surrounding filter housing for accumulated lint before concluding that the spring is faulty.

Pro Tip

Part Details

Key Features

• Genuine LG OEM distortion/filter-flap spring.
• Used at the dryer lint-screen cover or lint-screen duct-cover area.
• Supports lint-screen cover retention and proper filter-area fit.
• Small spring component supplied separately rather than as a complete lint-filter assembly.

Installation Notes

• Disconnect electrical power before servicing.
• Follow the appliance-specific parts diagram or service instructions for access to the lint-filter cover assembly.
• The replacement procedure documented for this part removes the filter cover, releases the filter holder, removes the flap and old spring, then seats the new spring in the flap slots before reassembling the cover.
• After installation, confirm the flap is retained, moves freely, and the lint screen and cover seat correctly before operating the dryer.

Verified Compatible Models

DLE1101W, DLE4970W, DLEX3370R, DLEX3370W, DLEX3570V, DLEX3570W, DLEX4270V, DLEX7700VE, DLG1002W, DLG3051W, DLGX3571W, DLGX4271V, DLGX5681V, DLGX5681VE, DLGX5781VE

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
