Speed Queen / Alliance Laundry Systems Dryer Igniter And Bracket Assembly D510184P, Replaces 369P3, 503604, 510184, 510184P, 56408, 56970, 58823, 60868, 61076, D518679P, M405424 – Superseded by D518679

Genuine OEM gas dryer igniter and bracket assembly. The igniter may be supplied in either round-spiral or flat style; the supplier states both styles fit and function as replacements.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• No ignition or no flame during a heat cycle
• Dryer produces little or inconsistent heat
• Dryer takes unusually long to dry clothes

Check Before Replacing

• With the dryer disconnected from electrical power and fully cooled, inspect the igniter through the available burner-area access for cracks, breakage, or obvious physical damage.
• Observe a heat cycle only from a safe position and without bypassing any safety device: the igniter should heat before gas ignition; no glow does not by itself prove the igniter is defective.
• If qualified to perform electrical testing, follow the appliance service documentation and test igniter continuity with power disconnected; an open circuit is consistent with a failed igniter, but other ignition-system faults can produce the same symptom.
• Do not touch or tap the igniter filament; it is fragile and can break easily.

Pro Tip

Part Details

Key Features

• Genuine OEM Speed Queen / Alliance Laundry Systems igniter and bracket assembly
• Designed for gas dryers
• Supplied as an igniter-and-bracket assembly rather than an igniter alone
• Manufacturer documentation identifies D510184P for North American models through August 31, 2021 and for other listed applications
• The production part may use either round-spiral or flat igniter construction

Installation Notes

• Disconnect electrical power, allow the dryer to cool completely, and shut off the gas supply before servicing the gas ignition area.
• Handle the igniter carefully and avoid striking, bending, or touching the fragile heating element.
• Use the appliance's applicable service documentation to access the burner area, remove the existing assembly, and reinstall the replacement in the same position.
• Reconnect wiring securely and verify that the bracket and igniter are seated correctly before restoring power and gas.
• If gas odor is present, stop servicing, shut off the gas supply if safe, ventilate the area, and contact a qualified appliance or gas technician.

Verified Compatible Models

AGS20AWF, ATE50FGP171TW01, ATG50FGP111TW01, CTSA7AWN, CTSA7AWN1500, CTSA9AWN, LGA80AW/PLGA80AW, LTSA7AQN3000, LTSA7AWN3000, LTZA7AQN, LTZA7AQN2802, LTZA9AQN, SDG609QF, SSG809LF, SSGX09WF

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
