The 5304495520 is the OEM oven control board for Frigidaire and Electrolux electric ranges. If your range has lost temperature control, won’t heat, or displays error codes, this board is the direct factory replacement that restores full function. Available new or used from XPart Supply.

✓ Model-Specific Repair Pages

Don’t see your model? Contact us

The 5304495520 control board manages all oven functions including bake, broil, and self-clean cycles. It communicates with the temperature sensor and relay board to maintain precise heat levels. This is a direct OEM part — not a generic substitute — ensuring full compatibility with your range’s wiring harness and control panel overlay.

✓ Common Symptoms Fixed

This board resolves the most common Frigidaire electric range failures: oven not heating to set temperature, F-series error codes (F10, F11, F30, F31), oven not turning on, self-clean cycle not starting, and display showing incorrect readings or going blank. If your bake or broil element tests good but the oven still won’t heat, the control board is the next logical replacement.

✓ Key Features & Specifications

Part Number: 5304495520. OEM Frigidaire / Electrolux control board. Compatible with BGEF, CGEF, FGEF, and LGEF series 30” electric ranges. Replaces superseded part numbers 316560105, 3290456, PS9494055, and 3164627. Note: overlay (glass touch panel) is sold separately as part number 316419821.

✓ Buying Options

New OEM (Part# 5304495520): Factory-original board, full lifespan. Best for appliances under 10 years old or where reliability is the priority.

Used / Tested (Part# 5304495520): Pulled from working units, tested before listing. A cost-effective option for older appliances or budget repairs. Limited quantity available.

XPart Supply aftermarket replacement parts are not affiliated with, sponsored by, or endorsed by Frigidaire, Electrolux, or any OEM manufacturer.

✓ Replacement Part Numbers

5304495520 replaces: 316560105, 3290456, PS9494055, 3164627

XPart cross-reference: 5304495520XP (aftermarket cross-reference)

✓ Installation Tips

Disconnect power to the range before beginning. The control board is located behind the rear panel of the control console. Take a photo of all wire harness connections before disconnecting. Transfer connections one at a time to avoid miswiring. Restore power and run a bake cycle to confirm the repair. If the overlay (316419821) was damaged, replace it at the same time to avoid a second disassembly.
