Range Burner Not Heating? Surface Element 5304516159 – Fix Dead or Uneven 8" Burner Fast

If your Frigidaire or Electrolux electric range has an 8" burner that won't heat, heats unevenly, or trips the limiter repeatedly, the surface element is the most likely cause. In most Frigidaire-built electric ranges, this is caused by a failed 5304516159 surface element. When it fails, the large burner produces no heat or cycles erratically, making it impossible to boil, fry, or cook on the primary element. ⚡ Common failure point in Frigidaire and Electrolux-built electric ranges. Part 5304516159 is the genuine OEM replacement that restores full, consistent 900–1400W heat to your 8" burner immediately.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

• ✔ Range powers on and other burners work normally
• ✔ The affected burner is the 8" large element (not the 6" — order 5304516160 for the 6")
• ✔ Oven and clock/control functions are unaffected
• ✔ Infinite switch (burner control knob) has been confirmed functional
• ✔ ONLY problem is the 8" surface burner not heating or heating unevenly

Not sure? Send us your model number — we'll confirm before you order.

🔧 Common Symptoms

• 8" burner produces no heat at any setting — most common complaint
• Burner heats unevenly or only on part of the coil
• Element glows red in one spot but not across the full coil
• Burner cycles off prematurely — limiter tripping due to element failure
• Visible burn marks, breaks, or blistering on the coil surface
• Burner works intermittently — heats sometimes, fails others

✔ If these symptoms match, this is the most likely failed component in the system.

✔ In most cases, replacing this surface element restores normal operation immediately.

📦 Part Details

• Part Number: 5304516159
• Type: 8" Electric Range Surface Coil Element with Integrated Limiter, 900–1400W
• Replaces: A13197401
• Brands: Frigidaire, Electrolux
• Note: For the 6" small element, order part 5304516160 instead

⚙️ Installation

Skill Level: EASY — 5–10 minutes. Disconnect power to the range at the breaker or by unplugging before beginning. The surface element plugs directly into the receptacle block — lift the element slightly, pull straight out to disconnect, and push the new element firmly into the receptacle until fully seated. No tools required. Restore power and test across all heat settings to confirm full operation.

✓ Compatible Models

Confirmed compatible with FFEF3016VWD, FFEF3016VWC, FFEF3016VWA, CFEF3017UWD, CFEF3017UWB, CFEF3016VWD, FFEF3012UWC, FFEC3005UWA, VCRC3016AWE, 79092573810, 79092563810, 79092562810, 79092552810, 79092452910, 79041323810 plus additional Frigidaire and Electrolux models. Contact us to verify your model number before ordering.

💡 Pro Tip
