Whirlpool Dishwasher Not Filling with Water? Inlet Valve 611906 – Fix No-Fill and Restore Proper Water Flow Fast
If your Whirlpool, Maytag, or KitchenAid dishwasher is not filling with water, filling too slowly, or running a wash cycle with no water in the tub, a failed water inlet valve is the most common cause. In most Whirlpool-built dishwashers, the water inlet valve is an electrically operated solenoid valve that opens at the start of each cycle to allow water into the tub. When the solenoid coil burns out, the valve screen clogs with mineral deposits, or the valve body cracks, the dishwasher either fails to fill entirely or fills so slowly that the control board times out and aborts the cycle. ⚡ One of the most frequently replaced parts on Whirlpool, Maytag, and KitchenAid dishwashers. Part 611906 is the OEM replacement water inlet valve that restores full, properly timed water fill and gets your dishwasher cleaning again.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ Dishwasher powers on and the control panel responds normally
- ✔ Water supply to the dishwasher is confirmed on and the supply line is not kinked
- ✔ The door latch and door switch are functioning correctly
- ✔ ONLY problem is no water entering the tub, slow fill, or a fill timeout error
Not sure? Send us your model number — we'll confirm before you order.
🔧 Common Symptoms
- Dishwasher starts a cycle but no water enters the tub
- Dishwasher fills very slowly and the cycle times out or aborts
- Humming sound at the start of the cycle but no water flow
- Dishwasher displays a fill error or F8 E1 / F8 E4 type fault code
✔ If these symptoms match, this is the most likely failed component in the system.
✔ In most cases, replacing this water inlet valve restores normal fill and full wash performance immediately.
📦 Part Details
- Part Number: 611906 (OEM) / 611906XP (XPart aftermarket)
- Type: Dishwasher Water Inlet Valve — Solenoid-Operated
- Replaces: 611906, 611906XP
- Brands: Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana
While the lower access panel is off to replace the inlet valve, inspect the dishwasher door latch assembly and door switch — a faulty door switch can mimic a fill failure by preventing the control board from sending the fill signal even when the valve is good. Also check the float switch inside the tub — a stuck float will signal the board that the tub is already full and prevent the inlet valve from opening.
⚙️ Installation
Skill Level: MODERATE — 30–45 minutes. Disconnect power and shut off the water supply valve under the sink before servicing. Remove the lower access panel and toe kick to access the inlet valve at the front-left of the dishwasher base. Disconnect the water supply line, the fill hose to the tub, and the two wire harness connectors. Install the new 611906 valve in the same orientation, reconnect all connections, restore water and power, and run a short cycle to confirm proper fill.
✓ Compatible Models
Compatible with Whirlpool, Maytag, KitchenAid, Jenn-Air, and Amana dishwasher models using the 611906 water inlet valve. Contact us to verify your model number before ordering.
⚠️ Model-specific dishwasher repair pages: BIDIR hub links pending — handles must be verified before publishing.
Before ordering, confirm the inlet valve is the actual failure point. Set a multimeter to resistance (ohms) and test across the solenoid terminals on the valve — a healthy solenoid reads approximately 500–1500 ohms. An open circuit (OL / infinite resistance) confirms the solenoid coil has burned out and the valve must be replaced. If the solenoid tests good, the problem may be upstream (water pressure, supply valve, or control board) — saving you an unnecessary part purchase.
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
