Dacor Wine cellar / refrigerator 24-inch Wine Cellar, Single Zone, Left Hinge HWC241L

Dacor built-in 24-inch single-zone wine cellar with a left-hinged stainless-steel and glass door, designed to store up to 54 standard 750 ml wine bottles.

Is This the Right Part?

Common Symptoms

• Wine compartment temperature rises above the selected setting
• Temperature alarm activates when the compartment warms
• Interior cooling performance is inadequate

Check Before Replacing

• Verify that the front ventilation area is unobstructed.
• Confirm the unit is operating in an ambient temperature between 60°F and 90°F.
• Check that the electrical outlet is accessible and the unit is connected to a grounded 115 VAC circuit.
• Confirm the temperature setting on the electronic control panel.
• Check whether the temperature alarm is active.

Pro Tip

Part Details

Key Features

• Single temperature zone
• Left-hand door hinge
• Stainless-steel and glass finish
• Capacity up to 54 bottles using 750 ml bottles
• Automatic defrosting system
• Interior LED lightingל?

Installation Notes

• Install on a solid, stable, level surface.
• Provide a completely unobstructed front ventilation area.
• For enclosed installation, maintain at least 1/4 inch on both sides, 1/2 inch above, and 2 1/4 inches behind the unit.
• Use a dedicated, grounded 115 VAC, 15 amp, three-wire circuit with a three-prong power cord.
• Keep the electrical outlet accessible after installation.
• Do not install near ovens, grills, direct sunlight, or other high-heat sources.

Verified Compatible Models

HWC241L

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
