Range Burner Not Responding? Energy Regulator DG44-01006C – Fix Burner Stuck on High or No Heat Fast
A failed energy regulator leaves your Samsung range burner stuck on high, completely dead, or cycling erratically — making the cooktop unsafe and unusable. In most Samsung NE63A and NE63T electric ranges, this is caused by a failed infinite switch (energy regulator). When it fails, the burner either won't heat at all, locks on full power with no way to turn it down, or cycles unpredictably at any setting. ⚡ Common failure point in Samsung-built electric ranges. Part DG44-01006C is the genuine OEM 240V replacement that directly supersedes PER001-12D and 240720V, restoring full, precise burner heat control with no modification required.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ Your range powers on and the display/clock functions normally
- ✔ Other burners on the cooktop work correctly
- ✔ Household 240V power supply confirmed OK at the outlet
- ✔ Oven bake and broil elements work normally
- ✔ ONLY problem is one surface burner stuck on high, completely dead, or cycling erratically
Not sure? Send us your model number — we'll confirm before you order.
🔧 Common Symptoms
- Surface burner won't heat up — stays completely off when turned on
- Burner locked on high — won't reduce heat when knob is turned down
- Burner cycles on and off unpredictably at any heat setting
- Control knob feels loose or lacks smooth stepped resistance
- Visible burn marks, scorching, or melting around the switch area
- One burner affected while all others work normally
✔ If these symptoms match, the energy regulator is the most likely failed component in the system.
✔ In most cases, replacing this infinite switch restores normal burner operation immediately.
📦 Part Details
- Part Number: DG44-01006C
- Type: Energy Regulator / Infinite Switch — 240V surface burner control
- Replaces: OEM direct-fit infinite switch assembly — supersedes PER001-12D, 240720V (no modification required)
- Brands: Samsung (Genuine OEM)
- Compatible Series: Samsung NE63A, NE63T electric ranges
- Condition: New — factory spec
⚠️ Recommended While Repairing:
Inspect the terminal block and burner element spade connectors while the control panel is open — a failed infinite switch often causes arcing that degrades these components. Replacing a low-cost terminal block now prevents a repeat failure on your brand-new regulator.
Inspect the terminal block and burner element spade connectors while the control panel is open — a failed infinite switch often causes arcing that degrades these components. Replacing a low-cost terminal block now prevents a repeat failure on your brand-new regulator.
⚙️ Installation
Skill Level: MODERATE — 30–45 minutes. Disconnect power at the breaker AND unplug the range before beginning — this part operates at 240V. Remove the control knob and panel screws to access the regulator; photograph the wiring harness before disconnecting. Install the new DG44-01006C in the same position, reconnect all wires securely, reattach the panel and knob, restore power, and test the burner at multiple heat settings. Observe for several minutes to confirm proper cycling and no unusual noise or odour.
✓ Compatible Models
Confirmed compatible with NE63A6751SG/AA, NE63A6751SS/AA, NE63A6711SG/AA, NE63A6511SG/AA, NE63A6511SS/AA, NE63A6511SS/AC, NE63T8311SG/AA, NE63T8311SS/AA, NE63T8111SG/AA, NE63T8111SS/AA, plus additional Samsung NE63 series models. Contact us to verify your model number before ordering.
💡 Pro Tip
Inspect the Terminal Block While You're In There:
A failed infinite switch frequently causes arcing at the terminal block and can degrade the burner element's spade connections. Before installing the new DG44-01006C, inspect the terminal block for carbon tracking, melting, or loose terminals — and check the element's spade connectors for heat damage. Replacing a $15 terminal block now prevents a repeat failure call on a brand-new $145 switch.
A failed infinite switch frequently causes arcing at the terminal block and can degrade the burner element's spade connections. Before installing the new DG44-01006C, inspect the terminal block for carbon tracking, melting, or loose terminals — and check the element's spade connectors for heat damage. Replacing a $15 terminal block now prevents a repeat failure call on a brand-new $145 switch.
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
