BROIL MODE PRODUCES LITTLE OR NO HEAT
Samsung Range Broil Element / Heater Sheath-Grill DG47-00068A, Fixes Broil mode produces little or no heat
Genuine Samsung OEM upper oven broil element, also described by parts distributors as a 240-volt heater sheath-grill. It is located at the top of the oven and supplies heat for broiling.
Part DG47-00068ASamsung
Guaranteed to Fit — or your money back.
Confirm your full appliance model number before ordering.
Confirm your full appliance model number before ordering.
Is This the Right Part?
Part NumberDG47-00068A
ManufacturerSamsung
Appliance TypeRange
Part TypeRange Broil Element / Heater Sheath-Grill
✅ Cross Reference Information
Current Part NumberDG47-00068A
Common Symptoms
- The upper element does not glow when Broil is selected.
- Food does not brown or sear properly from above.
- Visible holes, blisters, burn marks, or a break in the element sheath.
- The oven may heat in Bake mode but fail to heat normally in Broil mode.
- A burning odor or sparking may occur if the element sheath is visibly damaged; these symptoms can also indicate other appliance faults.
Check Before Replacing
- With the range completely disconnected from electrical power, visually inspect the upper broil element for breaks, holes, blistering, or severe discoloration.
- With power disconnected, test the element for electrical continuity using an appropriate multimeter procedure; lack of continuity indicates an open element, but continuity alone does not rule out wiring, control, or supply problems.
- When operating the appliance, observe whether the upper element heats during Broil only if doing so can be performed safely and according to the appliance manual; do not touch the element or exposed wiring.
Pro Tip
A visibly damaged element or an open continuity reading supports an element fault, but a no-broil complaint can also involve wiring, controls, or the electrical supply. Confirm power is disconnected before inspecting or removing the element.
Part Details
Part NumberDG47-00068A
Part TypeRange Broil Element / Heater Sheath-Grill
ManufacturerSamsung
Appliance TypeRange
Primary FunctionSupplies radiant heat from the top of the oven cavity for the Broil function and contributes upper heat during some oven heating cycles.
Installation Notes
- Disconnect electrical power at the range before servicing; this is a high-voltage appliance circuit.
- Allow the oven and element to cool completely before handling, and use protective gloves because the element and surrounding sheet-metal edges may be sharp.
- Access and mounting details vary by Samsung range model. Remove only the model-specific retaining hardware needed to release the upper element, then carefully expose the wire connections.
- Transfer the wire connections to the replacement element in the same arrangement and secure the element using the original mounting points; do not work on exposed wiring while power is connected.
- Verify the replacement against the appliance model and the removed part before installation.
Verified Compatible Models
DOP30T940DS/DA, DOP30T940IS/DA, NE59J7630SB/AA, NE59J7630SG/AA, NE59J7630SS/AA, NE59J7630SS/AC, NE59J7630SW/AA, NE59J7650WS/AA, NE59J7651WS/AC, NE59J7750WS/AA, NE59J7750WS/AC, NE59J7850WG/AA, NE59J7850WG/AC, NE59J7850WS/AA, NE59J7850WS/AC
Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
