Samsung Range Not Working? Wire Harness DG96-00378A – Fix Power Loss & Burner Faults Fast

If your Samsung electric range has lost power to one or more burners, the oven won't heat, or you're seeing intermittent electrical faults, a damaged or failed wire harness is a primary suspect. In most Samsung NE59J7630-series ranges, the main wire harness routes power and control signals between the control board, surface elements, and oven components as a single integrated assembly. When it fails — due to heat damage, chafing, or a loose connector — burners stop responding, the oven won't reach temperature, or the range throws error codes with no other obvious cause. ⚡ Common failure point in Samsung-built electric ranges, particularly after high-heat events or extended use. Part DG96-00378A is the genuine OEM replacement that restores full electrical continuity and gets your range operating reliably again.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

• ✔ Range powers on — display and clock function normally
• ✔ Control board has been tested or ruled out as the fault source
• ✔ Power supply confirmed OK — breaker is on, outlet voltage is correct
• ✔ ONLY problem is one or more burners not heating, oven not responding, or intermittent electrical faults with no clear cause

Not sure? Send us your model number — we'll confirm before you order.

🔧 Common Symptoms

• One or more surface burners not heating or responding to controls
• Oven not reaching set temperature or not heating at all
• Intermittent error codes (e.g. SE, E-08) with no consistent trigger
• Visible burn marks, melted insulation, or scorched connectors on the existing harness

✔ If these symptoms match, this is the most likely failed component in the system.

✔ In most cases, replacing this wire harness restores full burner and oven operation immediately.

📦 Part Details

• Part Number: DG96-00378A
• Type: Range Main Wire Harness — routes power and control signals between the control board, surface elements, and oven assembly
• Replaces: AP5967723, PS11722596
• Brands: Samsung

⚙️ Installation

Skill Level: ADVANCED — 45–75 minutes. Disconnect power at the breaker before servicing — this is a high-voltage component. Pull the range away from the wall and remove the back panel to access the wire harness routing. Carefully disconnect each connector from the control board and element terminals, route the new harness along the same path, and reconnect all plugs securely before reassembling and restoring power.

✓ Compatible Models

Confirmed compatible with NE59J7630SB/AA, NE59J7630SG/AA, NE59J7630SS/AA, NE59J7630SW/AA plus additional Samsung NE59J7630-series models. Contact us to verify your model number before ordering.
