Frigidaire Washer Door Strike 131763302, Replaces 131763300, 131763310, 131763340, 134456600, 134456602, 134456640

131763302 is the current genuine Frigidaire and Electrolux front-load washer door strike. It replaces discontinued OEM part numbers 131763300, 131763310, 131763340, 134456600, 134456602 and 134456640. The current replacement may differ in colour or appearance from discontinued 131763310 but is the manufacturer-designated service replacement.

The strike attaches to the washer door and enters the door-lock assembly when the door closes. This mechanical engagement allows the separate lock assembly (commonly 131763256) to detect and secure the door before the washer starts. The strike does not electrically lock the door — it provides the mechanical engagement point used by the door-lock assembly.

A cracked, worn or misaligned strike is one possible cause of a door that will not latch or prevents the washer from starting. Similar symptoms can also result from a defective door-lock assembly, loose hinge, door misalignment, damaged door frame, wiring problem or control failure. Inspect the door lock and alignment before ordering.

Is This the Right Part?

Confirm the complete washer model before ordering. Disconnect electrical power before servicing the washer.

Common Symptoms

• Washer door will not latch or lock shut on its own
• Washer will not start — door sensor not detecting a closed door
• Door requires pressure to remain closed during operation
• Visible cracking, wear, or breakage on the door strike tab
• Strike not entering the lock assembly correctly when the door closes

Check Before Replacing

• Inspect the door-lock assembly (131763256) on the machine body — a worn or failed lock can produce the same symptoms as a broken strike
• Check the door hinges for looseness or damage that causes the door to misalign with the lock
• Verify the door frame and mounting screws are secure — a loose strike mounting causes premature wear
• Check wiring and control board if the door latches mechanically but the washer still will not start

Part Details

Installation Notes

1. Disconnect electrical power before servicing the washer.
2. Open the washer door fully and photograph the strike mounting position.
3. Remove the screws securing the inner door panel and separate the door panels to access the strike.
4. Unclip the old strike and compare with the new 131763302 before installing.
5. Snap the new strike into position and reassemble the door panels.
6. Test latch engagement and run a short cycle to confirm the door locks and the washer starts normally.

Use a qualified technician when diagnosis or installation is outside your experience.

Verified Compatible Models

41741122310, ATF6000ES0, ATF6000ES1, ATF6000FS0, ATF6000FS1, ATF6000FS2, ATF8000FS1, ATFB6000ES0, ATFB6000ES1, ATFB6000FS0, BLTF2940ES0–FS1, BTF1240ES0–FS1, BTF2140ES0–FS1, CFW2000FW0–FW2, CFW4000FW0–FW1, CFW4500KW0, CFW4700LW0, CFW4701QW0, CFW5000FW0–FW1, CFWH7300RW0, CLCE900FW0–FW2, CLCG900FW0–FW3, CRTF1240AS0, CRTR9300AS0, CTF140ES0–FS2, FAFW3001LW0–LW7, FAFW3511KW0–KW2, FAFW3801LW0–LW5, FAFW3921NW0–NW1, FAFW4011LW0, FAFW4221LW0, FCCW2000LS0, FCCW3000ES0–FS4, FFFW4000QW0, FFFW5000QW0, FRFW3700LW0, FTF530FS0–FS4, FTF630AS0, FTF2140ES0–FS2, FTF5000HS0, FTFB4000FS0–GS1, FTR630AS0, FWFB9100ES0–ES1, FWFB9200ES0–ES2, FWT425RHS0, FWT449GFS2, FWT645RHS0–RHS1, FWT647GHS0–GHS1, FWT648GHS0, FWT867GHQ0–GHS0, FWTB59RGS0, FWTB69RGS0, FWTB8200DS0, FWTBB30DS0, FWTR445RFS2, FWTR549GG–GGS0, FWTR645RHS0–RHS1, FWTR647GHS0–GHS1, FWTR865RHQ0–RHS0, FWTR867GHQ0–GHS0, GCEH1642DS1–FS4, GLEH1642DS0–FS4, GLGH1642DS0–FS5, GLTF1040AS0, GLTF1240AS0, GLTF1570ES0–FS3, GLTF1670AS0–AS1, GLTF2070CS0–DS0, GLTF2940ES0–FS2, GLTF530DS0–DS1, GLTR1670AS0–FS1, GMT1670AS0, GSTF1670AS0–DS0, GSTF7200DS0, GSTR1670AS0–DS0, GTF1040AS0–FS3, GTR1040AS0–CS0, GWT445RGS2, GWT645RHS0, GWTR645RHS0, LAFW3511KW0, LAFW6000LW0, LEH1642DS0, LFW201EW0, LGH1642DS0, LTF1670DS0, LTF2140ES0–FS2, LTF2940ES0–FS1, LTF530DS0–FS1, LTF6000ES0–FS0, NGST127AQ0–AS0, NGSTR127AS0, STF2940HS0–HS1, WTF330HS0–HS2, WTR1240AQ0–AS0, WTR430ES0–FS1, and many more 41700–41748 series models.

Fitment reminder: Match the complete model number, including suffixes and revision digits, before ordering. The current replacement 131763302 may differ in colour or appearance from discontinued 131763310 but is the manufacturer-designated service replacement.
