Samsung Refrigerator Heater-P Cord DA47-20198C

XPart Number XP10018416
$13.95
Available to order
Buying Options: OEM Genuine

Product variant with selected options does not exist!

Frequently Bought Together

Check Fit & Find Parts
Bubba checks verified models, product descriptions, cross-references and store data. Find your model number →
FREEZER EVAPORATOR OR DRAIN-AREA ICING WHEN THE HEATER CIRCUIT IS OPEN OR FAILED

Samsung Refrigerator Heater-P Cord DA47-20198C, Fixes Freezer evaporator or drain-area icing when the heater circuit is open or failed

Samsung HEATER-P CORD(F) used in the freezer/freezing-compartment evaporator assembly; rated 115V/30W.

Part DA47-20198CSamsung
Guaranteed to Fit — or your money back.
Confirm your full appliance model number before ordering.

Is This the Right Part?

Part NumberDA47-20198C
ManufacturerSamsung
Appliance TypeRefrigerator
Part TypeHeater-P Cord

Common Symptoms

  • Excessive frost or ice buildup in the freezer evaporator area
  • Restricted freezer airflow caused by ice accumulation
  • Freezer-compartment heater circuit not heating

Check Before Replacing

  • Confirm the refrigerator model and that the installed heater is specified as DA47-20198C.
  • With power disconnected, inspect the heater cord and wiring for visible damage, burned insulation, or disconnected terminals.
  • Have a qualified technician test the heater circuit for continuity and compare the result with the component’s 115V/30W rating.

Pro Tip

Do not substitute the visually similar DA47-20198A, DA47-20198B, or DA47-20198D; those versions have different voltage ratings.

Part Details

Part NumberDA47-20198C
Part TypeHeater-P Cord
ManufacturerSamsung
Appliance TypeRefrigerator
Primary FunctionProvides heating for the freezer/freezing-compartment heater circuit.

Installation Notes

  • Disconnect electrical power before servicing the refrigerator.
  • Use the correct voltage-rated heater version; the documented DA47-20198C rating is 115V/30W.
  • Reassemble wiring and insulation as originally installed, keeping the harness secured and away from moisture and moving components.

Verified Compatible Models

SR-S24DTA, SR-S24FTA, SR-S25DTA, SR-S25FTA, SR-S25NTA, SR-S26NTA, SR-S27DTA, SR-S27FTA, SRS24FTBS

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
