Whirlpool Refrigerator Ice Maker Assembly W10884390 — Fix No Ice & Failed Ice Production

$131.99
$143.87
Buying Options: XPart

Product variant with selected options does not exist!

Frequently Bought Together
OEM REPLACEMENT PART

Whirlpool Refrigerator Ice Maker Assembly W10884390 — Fix No Ice & Failed Ice Production

Part# W10884390 Replaces W10377152 Replaces W10469286 Fits Whirlpool Fits KitchenAid Fits Maytag

Whirlpool Refrigerator Not Making Ice or Ice Maker Stopped Working? Ice Maker Assembly W10884390 – Fix It Fast

If your Whirlpool, KitchenAid, Maytag, or Jenn-Air refrigerator has stopped producing ice, is making ice slowly, or the ice maker module has completely failed, the ice maker assembly is the most likely failed component. In most Whirlpool-platform refrigerators, the ice maker assembly contains the motor, thermostat, ejector blades, and control module that manage the full ice-making cycle — when any internal component fails, the entire assembly stops producing ice and must be replaced as a unit. ⚡ One of the most common service calls on Whirlpool, KitchenAid, and Maytag bottom-mount and French door refrigerators. Part W10884390 is the genuine OEM replacement ice maker assembly that restores full ice production immediately — available in OEM and aftermarket options.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

  • ✔ Refrigerator is cooling normally and freezer temperature is at or below 0°F (-18°C)
  • ✔ Water supply line to the refrigerator is connected, not kinked, and water pressure is adequate
  • ✔ Water inlet valve has been tested and is functioning correctly
  • ✔ ONLY problem is the ice maker has stopped producing ice, produces ice very slowly, or the ice maker module is not cycling

Not sure? Send us your model number — we'll confirm before you order.

🔧 Common Symptoms

  • Ice maker completely stopped — no ice produced for 24+ hours
  • Ice maker cycles but no ice drops into the bin — ejector arm or motor failed
  • Ice maker produces ice very slowly — thermostat or heater element failing
  • Ice maker makes a humming or clicking noise but no ice is produced
  • Ice maker arm is in the down position but no ice is being made
  • Ice bin is empty despite water supply being confirmed good

✔ If these symptoms match, this is the most likely failed component in the system.

✔ In most cases, replacing the W10884390 ice maker assembly restores full ice production within 24 hours of installation.

📦 Part Details

  • Part Number: W10884390
  • Type: Refrigerator Ice Maker Assembly (Complete Module with Motor, Thermostat & Ejector) — OEM Whirlpool
  • Replaces: W10377152, W10469286, W10793298, WPW10377152, WPW10469286
  • Brands: Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Kenmore (Whirlpool-built platform)
  • Aftermarket Option: Premium aftermarket alternative available — engineered to meet or exceed OEM specifications
⚠️ Recommended While Repairing:
Before replacing the ice maker assembly, test the water inlet valve — a failed or restricted inlet valve is the #1 cause of no-ice complaints that are misdiagnosed as ice maker failures. If the valve is not opening fully, a new ice maker assembly will fail to produce ice for the same reason. Also check the freezer temperature — the ice maker will not cycle if the freezer is above 10°F (-12°C).

⚙️ Installation

Skill Level: Easy — 15–30 minutes. Disconnect power before servicing. Remove the ice bin and locate the ice maker module mounted to the freezer wall or ceiling. Disconnect the wiring harness and water fill tube, remove the 2–3 mounting screws, and slide the old assembly out. Install the new W10884390 in reverse order, reconnect the harness and fill tube, restore power, and allow 24 hours for the first ice production cycle to complete.

✓ Compatible Models

Confirmed compatible with WRF532SMHZ, WRF535SMHZ, WRF535SWHZ, WRF540CWHZ, WRFA32SMHZ, WRFA35SWHZ, KRFC300ESS, KRFF302ESS, KRFF305ESS, JFC2089BEM, JFC2290VEM, MBF1958FEZ, MBF2258FEZ, MFF2258FEZ, MFF2558FEZ, AFD2535DEB, GB2FHDXWB, KBFS20EVMS, KBFS22EWBL, KBFS25EWBL (all suffix variants) and 300+ additional Whirlpool, KitchenAid, Maytag, Jenn-Air, and Kenmore refrigerator models. Contact us to verify your model number before ordering.

❓ Frequently Asked Questions

Does W10884390 replace W10377152 and W10469286?
Yes — W10884390 is the updated OEM part number that supersedes W10377152, W10469286, and W10793298. All are the same ice maker assembly; W10884390 is the current factory part number.

How long does it take to make ice after installation?
Allow up to 24 hours for the first full ice production cycle after installation. The ice maker must complete a full freeze-and-harvest cycle before ice drops into the bin. If no ice is produced after 24 hours, verify freezer temperature is at or below 0°F and water supply is confirmed.

What is the difference between OEM and the aftermarket option?
The OEM part (W10884390) is the original Whirlpool factory assembly. The aftermarket option is a premium alternative engineered to meet or exceed OEM specifications at a lower price point. The aftermarket part is not affiliated with, sponsored by, or endorsed by Whirlpool or any OEM manufacturer.

✓ Model-Specific Repair Pages

💡 Pro Tip

Check the Freezer Temperature and Water Valve Before You Order:
The two most common causes of a no-ice complaint that are NOT the ice maker assembly are: (1) freezer temperature above 10°F — the ice maker will not cycle if the freezer is too warm; and (2) a failed or restricted water inlet valve — no water means no ice regardless of how good the ice maker module is. Test both before ordering the assembly. If the freezer is cold and water flows freely to the valve, the ice maker assembly is the correct repair.

✅Compatibility & Cross Reference

Part number W10884390 replaces W10377152, W10469286, W10793298, WPW10377152, WPW10469286


10672002011, 10672002013, 10672002015, 10672003012, 10672003013, 10672003014, 10672003016, 10672003017, 10672003018, 10672009011, 10672009013, 10672009015, 10672013017, 596467934251, 596467934351, 596467934451, 596467934951, 59672002011, 59672002013, 59672002015, 59672003012, 59672003013, 59672003014, 59672003016, 59672003017, 59672003018, 59672009011, 59672009013, 59672009015, 59672012012, 59672012014, 59672012016, 59672013012, 59672013013, 59672013014, 59672013015, 59672013017, 59672019012, 59672019014, 59672019016, 59679222011, 59679222012, 59679222013, 59679222014, 59679223011, 59679223012, 59679223013, 59679223014, 59679223015, 59679229011, 59679229012, 59679229013, 59679229014, 59679312510, 59679312511, 59679313510, 59679313511, 59679319510, 59679322011, 59679322013, 59679322015, 59679323012, 59679323014, 59679323016, 59679329011, 59679329013, 59679329015, 59679342510, 59679343510, 59679344510, 59679349510, 59679422410, 59679422411, 59679423410, 59679423411, 59679462410, 59679463410, 59679522013, 59679522014, 59679522015, 59679523014, 59679523015, 59679523016, 59679529013, 59679529014, 59679529015, 59679532014, 59679532016, 59679532018, 59679533015, 59679533017, 59679533019, 59679539014, 59679539016, 59679539018, AFD2535DEB10, AFD2535DEB11, AFD2535DEB9, AFD2535DEW10, AFD2535DEW11, AFD2535DEW9, AFD2535FES11, EB9SHKXVQ04, EB9SHKXVQ05, EB9SHKXVQ07, EF36BNNFSS11, GB2FHDXWB03, GB2FHDXWB04, GB2FHDXWB06, GB2FHDXWB07, GB2FHDXWQ03, GB2FHDXWQ04, GB2FHDXWQ06, GB2FHDXWQ07, GB2FHDXWQ08, GB2FHDXWS05, GB2FHDXWS06, GB2FHDXWS08, GB2FHDXWS09, GB9FHDXWB03, GB9FHDXWB04, GB9FHDXWB06, GB9FHDXWB07, GB9FHDXWQ03, GB9FHDXWQ04, GB9FHDXWQ06, GB9FHDXWQ07, GB9FHDXWS05, GB9FHDXWS06, GB9FHDXWS08, GB9FHDXWS09, GX2FHDXVB05, GX2FHDXVB06, GX2FHDXVB07, GX2FHDXVB08, GX2FHDXVQ04, GX2FHDXVQ05, GX2FHDXVQ06, GX2FHDXVQ07, GX2FHDXVY010, GX2FHDXVY07, GX2FHDXVY08, GX2FHDXVY09, GX5FHDXVB06, GX5FHDXVB07, GX5FHDXVB08, GX5FHDXVQ05, GX5FHDXVQ06, GX5FHDXVQ07, GX5FHDXVY010, GX5FHDXVY08, GX5FHDXVY09, GX5FHTXVB06, GX5FHTXVB07, GX5FHTXVB08, GX5FHTXVQ05, GX5FHTXVQ06, GX5FHTXVQ07, GX5FHTXVY010, GX5FHTXVY08, GX5FHTXVY09, IX3HHEXDSM00, IX5HHEXWS08, IX5HHEXWS09, IX5HHEXWS10, IX6HHEXDSM00, IX6HHEXDSM01, IX6HHEXDSM03, IX7HHEXDSM00, JFC2089BEM00, JFC2089BEM01, JFC2089BEM03, JFC2089BEM04, JFC2089BEP00, JFC2089BEP01, JFC2089BEP03, JFC2089WEM11, JFC2089WEM7, JFC2089WEM9, JFC2089WEP11, JFC2089WEP7, JFC2089WEP9, JFC2089WTB5, JFC2089WTB7, JFC2089WTB9, JFC2290VEM6, JFC2290VEM7, JFC2290VEM8, JFC2290VEP6, JFC2290VEP7, JFC2290VEP8, JFC2290VPF3, JFC2290VPF4, JFC2290VPF5, JFC2290VPR2, JFC2290VPR3, JFC2290VPR4, JFC2290VPY3, JFC2290VPY4, JFC2290VPY5, JFC2290VTB3, JFC2290VTB4, KBFS20ECBL00, KBFS20ECMS00, KBFS20ECWH00, KBFS20EVBL6, KBFS20EVBL8, KBFS20EVMS11, KBFS20EVMS13, KBFS20EVMS9, KBFS20EVWH6, KBFS20EVWH8, KBFS22ECBL00, KBFS22ECMS00, KBFS22ECWH00, KBFS22EWBL3, KBFS22EWBL5, KBFS22EWBL7, KBFS22EWMS5, KBFS22EWMS7, KBFS22EWMS9, KBFS22EWWH3, KBFS22EWWH5, KBFS22EWWH7, KBFS25ECBL00, KBFS25ECMS00, KBFS25ECWH00, KBFS25EWBL5, KBFS25EWBL7, KBFS25EWBL9, KBFS25EWMS10, KBFS25EWMS6, KBFS25EWMS8, KBFS25EWWH5, KBFS25EWWH7, KBFS25EWWH9, KBRS20EVBL4, KFCO22EVBL3, KFCO22EVBL4, KFCO22EVBL5, KFCP22EXMP3, KFCP22EXMP4, KFCP22EXMP5, KFCS22EVBL3, KFCS22EVBL4, KFCS22EVBL5, KFCS22EVMS6, KFCS22EVMS7, KFCS22EVWH3, KFCS22EVWH4, KFCS22EVWH5, KRFC300EBL00, KRFC300EBL01, KRFC300EBL03, KRFC300EBS00, KRFC300EBS01, KRFC300EBS02, KRFC300ESS00, KRFC300ESS01, KRFC300ESS03, KRFC300ESS04, KRFC300EWH00, KRFC300EWH01, KRFC300EWH03, KRFC300EWH04, KRFF302EBL00, KRFF302EBL01, KRFF302EBS00, KRFF302EBS01, KRFF302EBS02, KRFF302ESS00, KRFF302ESS01, KRFF302ESS02, KRFF302ESS03, KRFF302EWH00, KRFF302EWH01, KRFF302EWH02, KRFF302EWH03, KRFF305EBL00, KRFF305EBS00, KRFF305EBS01, KRFF305EBS02, KRFF305EBS03, KRFF305ESS00, KRFF305ESS02, KRFF305ESS03, KRFF305ESS04, KRFF305EWH00, KRFF305EWH02, KRFF305EWH03, KRFF305EWH04, MBF1953DEE00, MBF1953DEH00, MBF1953DEM00, MBF1953YEB2, MBF1953YEB4, MBF1953YEW2, MBF1953YEW4, MBF1958DEE00, MBF1958DEH00, MBF1958DEM00, MBF1958FEB00, MBF1958FEE00, MBF1958FEH00, MBF1958FEW00, MBF1958FEZ00, MBF1958FEZ01, MBF1958FEZ02, MBF1958FEZ03, MBF1958FEZ04, MBF1958FEZ05, MBF1958XEB2, MBF1958XEB3, MBF1958XEB5, MBF1958XEB6, MBF1958XEQ2, MBF1958XES2, MBF1958XES3, MBF1958XES5, MBF1958XES6, MBF1958XEW2, MBF1958XEW3, MBF1958XEW5, MBF1958XEW6, MBF2258DEE00, MBF2258DEH00, MBF2258DEM00, MBF2258FEB00, MBF2258FEE00, MBF2258FEH00, MBF2258FEW00, MBF2258FEZ00, MBF2258FEZ01, MBF2258FEZ02, MBF2258FEZ03, MBF2258FEZ04, MBF2258FEZ05, MBF2258XEB3, MBF2258XEB5, MBF2258XEB6, MBF2258XEW3, MBF2258XEW5, MBF2258XEW6, MBL2258XES3, MBL2258XES5, MBL2258XES6, MBR1953YES2, MBR1953YES4, MBR2258XES3, MBR2258XES5, MBR2258XES6, MFC2061KES14, MFC2062DEM00, MFC2062DEM01, MFC2062FEZ00, MFC2062FEZ01, MFC2062FEZ02, MFC2062FEZ03, MFC2062FEZ04, MFC2062FEZ05, MFD2562VEB9, MFD2562VEM11, MFD2562VEM9, MFD2562VEW6, MFD2562VEW8, MFF2258DEE00, MFF2258DEE01, MFF2258DEH00, MFF2258DEH01, MFF2258DEM00, MFF2258DEM01, MFF2258FEZ00, MFF2258FEZ01, MFF2258FEZ02, MFF2258FEZ03, MFF2258FEZ04, BOTTOM-MOUNT, MFF2258FEZ05, MFF2258VEB5, MFF2258VEB6, MFF2258VEB7, BOTTOM, MOUNT, MFF2258VEB8, MFF2258VEM7, MFF2258VEM8, MFF2258VEM9, MFF2258VEW4, MFF2258VEW5, MFF2258VEW6, MFF2258VEW7, MFF2558DEE00, MFF2558DEH00, MFF2558DEM00, MFF2558FEB00, MFF2558FEE00, MFF2558FEH00, MFF2558FEW00, MFF2558FEW01, MFF2558FEZ00, MFF2558FEZ01, MFF2558FEZ02, MFF2558FEZ03, MFF2558FEZ04, MFF2558FEZ05, BOTTOM-MOUNT, MFF2558FEZ06, MFF2558VEB6, MFF2558VEB7, MFF2558VEB8, MFF2558VEM9, MFF2558VEW5, MFF2558VEW6, MFF2558VEW7, WRB322DMBB00, WRB322DMBB01, WRB322DMBB02, WRB322DMBM00, WRB322DMBM01, WRB322DMBM02, WRB322DMBW00, WRB322DMBW01, WRB322DMBW02, WRB322DMHV00, WRB322DMHV01, WRB322DMHV02, WRB329DMBB00, WRB329DMBB01, WRB329DMBB02, WRB329DMBM00, WRB329DMBM01, WRB329DMBM02, WRB329DMBW00, WRB329DMBW01, WRB329DMBW02, WRF532SMBB00, WRF532SMBB01, WRF532SMBM00, WRF532SMBM01, WRF532SMBW00, WRF532SMBW01, WRF532SMHB00, WRF532SMHB01, WRF532SMHB02, WRF532SMHV00, WRF532SMHV01, WRF532SMHV02, WRF532SMHW00, WRF532SMHW01, WRF532SMHW02, WRF532SMHZ00, WRF532SMHZ01, WRF532SMHZ02, WRF532SMHZ03, WRF532SMHZ04, WRF535SMBB00, WRF535SMBM00, WRF535SMBW00, WRF535SMHB00, WRF535SMHB01, WRF535SMHB02, WRF535SMHB03, WRF535SMHW00, WRF535SMHW01, WRF535SMHW02, WRF535SMHW03, WRF535SMHZ00, WRF535SMHZ01, WRF535SMHZ02, WRF535SMHZ03, WRF535SMHZ04, WRF535SMHZ05, WRF535SWBB00, WRF535SWBM00, WRF535SWBW00, WRF535SWHB00, WRF535SWHB01, WRF535SWHB02, WRF535SWHB03, WRF535SWHV00, WRF535SWHV01, WRF535SWHV02, WRF535SWHV03, WRF535SWHW00, WRF535SWHW01, WRF535SWHW02, WRF535SWHW03, WRF535SWHZ00, WRF535SWHZ01, WRF535SWHZ02, WRF535SWHZ03, WRF535SWHZ04, WRF535SWHZ05, WRF540CWBB00, WRF540CWBB01, WRF540CWBM00, WRF540CWBM01, WRF540CWBW00, WRF540CWBW01, WRF540CWHB00, WRF540CWHB01, WRF540CWHB02, WRF540CWHV00, WRF540CWHV01, WRF540CWHV02, WRF540CWHW00, WRF540CWHW01, WRF540CWHW02, WRF540CWHZ00, WRF540CWHZ01, WRF540CWHZ02, WRF540CWHZ03, WRF540CWHZ04, WRFA32SMHN00, WRFA32SMHN01, WRFA32SMHZ00, WRFA32SMHZ01, WRFA32SMHZ02, WRFA32SMHZ03, WRFA32SMHZ04, WRFA35SWHN00, WRFA35SWHN01, WRFA35SWHN02, WRFA35SWHZ00, WRFA35SWHZ01, WRFA35SWHZ02, WRFA35SWHZ03, WRFA35SWHZ04, WRFA35SWHZ05

Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
