Whirlpool Refrigerator Door Switch W11123941, Replaces W10847853

Genuine Whirlpool OEM two-terminal refrigerator door switch. The switch turns the refrigerator interior light off when the door is closed and on when the door is opened.

Is This the Right Part?

Common Symptoms

• Interior light stays on when the door is closed.
• Interior light does not turn on when the door is opened.
• Door-ajar alerts or beeps may occur incorrectly.
• On models that use the door switch for dispenser interlock, water or ice dispensing may be disabled.

Check Before Replacing

• With the refrigerator energized and the door open, manually depress the switch and release it; verify that the interior light turns off and on as the switch position changes.
• Visually check that the switch is not broken, loose, recessed, or obstructed and that the door liner actually presses it when the door closes.
• Check whether the refrigerator is level and the door is properly aligned, since misalignment can prevent the door from fully actuating the switch.
• After disconnecting refrigerator power, inspect the two switch terminals and wire connections for looseness or visible damage. Do not perform live-voltage testing unless qualified.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM refrigerator door switch.
• Two-terminal electrical configuration.
• Spring-loaded cabinet-mounted switch operated by the refrigerator door.
• Used to control interior lighting and provide door-status input; some models also use that input for dispenser or other door-related functions.

Installation Notes

• Disconnect refrigerator power before removing or connecting the switch.
• Transfer the wires to the corresponding terminals and ensure both connections are fully seated before restoring power.
• Confirm that the replacement switch matches the removed two-terminal switch and is fully seated in its cabinet mounting location.
• Verify after installation that opening the door turns the interior light on and closing the door turns it off.
• Use the refrigerator model's service or installation documentation for any model-specific access and removal instructions.

Verified Compatible Models

59669312011, 59669313011, 59669319011, 59679312511, WRF767SDHZ04, WRS315SDHM08, WRS315SDHZ08, WRS325SDHW08, WRS325SDHZ08, WRS555SIHZ06, WRS571CIHZ00, WRS571CIHZ01, WRS571CIHZ04, WRT311FZDW02, WRT518SZFM02, WRT148FZDW04, WRT148FZDM04

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
