W11171886 Whirlpool Cooktop Wire Harness for Electric Ranges, Restores Surface-Element Electrical Connections

W11171886 is a genuine Whirlpool electric-range cooktop wire harness. The harness connects compatible cooktop electrical components and carries power and control signals to the surface-element circuits. It replaces the original harness when fitment is confirmed by the complete appliance model number.

A burned, broken or loose harness may contribute to one or more surface elements not heating, intermittent burner operation, dead cooktop functions or visibly overheated terminals. Similar symptoms can also result from a failed surface-element switch, defective heating element, damaged terminal block, control-board fault or incorrect incoming voltage.

Whirlpool diagrams identify W11171886 as the cooktop harness. It should not be confused with the range’s console harness, main chassis harness or power-cord wiring. Confirm the complete range model and original harness number before ordering. Compare all connectors, terminal positions and wire routing. Disconnect electrical power at the breaker before accessing range wiring. High-voltage range repairs should be completed by a qualified technician when required.

Is This the Right Part?

Confirm the complete model number before ordering. Similar harnesses may use different connector counts, terminal positions, wire gauges or routing paths. Fits select Whirlpool and Canadian Whirlpool electric ranges — confirm the complete model before ordering.

Common Symptoms

• One or more surface elements not heating at any setting
• Intermittent burner operation — element works sometimes but not consistently
• Dead cooktop controls — no response from surface-element switches
• Visibly burned, melted or overheated wiring or connectors at the cooktop
• Power loss to cooktop components after a surge or overload event

Check Before Replacing

• Inspect surface-element switches for continuity and physical damage
• Test heating elements for continuity and check for contact with the drip pan or housing
• Inspect terminal blocks for burning, corrosion or loose connections
• Confirm correct incoming voltage at the range outlet (240V for electric ranges)
• Inspect all harness connectors for heat damage, brittleness or loose retention before replacing the full harness

Part Details

Inspect every connector and terminal on the used harness before installation. Reject burned, brittle, cut or repaired wiring. Confirm continuity and connector retention on all circuits.

Installation Notes

1. Disconnect power at the breaker before servicing.
2. Photograph all wiring, connector positions and routing paths before disassembly.
3. Compare the new harness with the original — verify connector count, positions and wire gauge.
4. Inspect nearby switches, elements and terminal blocks for damage before installing.
5. Test the appliance and check for unusual sounds or error codes after reassembly.

Disconnect electrical power at the breaker before accessing range wiring. High-voltage range repairs should be completed by a qualified technician when required.

Verified Compatible Models

WEE510S0FB0, WEE510S0FB1, WEE510S0FB2, WEE510S0FS0, WEE510S0FS1, WEE510S0FS2, WEE510S0FV2, WEE510S0FW0, WEE510S0FW1, WEE510S0FW2, WEE510SAGB0, WEE510SAGB1, WEE510SAGS1, WEE510SAGW0, WEE510SAGW1, WEE515S0LB0, WEE515S0LB1, WEE515S0LB2, WEE515S0LB3, WEE515S0LS0, WEE515S0LS1, WEE515S0LS2, WEE515S0LS3, WEE515S0LV0, WEE515S0LV1, WEE515S0LV2, WEE515S0LV3, WEE515S0LW0, WEE515S0LW1, WEE515S0LW2, WEE515S0LW3, WEE515S0LZ0, WEE515S0LZ1, WEE515S0LZ2, WEE515S0LZ3, WEE515SALB0, WEE515SALB1, WEE515SALB2, WEE515SALB3, WEE515SALS0, WEE515SALS1, WEE515SALS2, WEE515SALS3, WEE515SALW0, WEE515SALW1, WEE515SALW2, WEE515SALW3, YWEE510S0FB2, YWEE510S0FS2, YWEE510S0FV2, YWEE510S0FW2, YWEE515S0LB0, YWEE515S0LB1, YWEE515S0LB2, YWEE515S0LB3, YWEE515S0LS0, YWEE515S0LS1, YWEE515S0LS2, YWEE515S0LS3, YWEE515S0LV0, YWEE515S0LV1, YWEE515S0LV2, YWEE515S0LV3, YWEE515S0LW0, YWEE515S0LW1, YWEE515S0LW2, YWEE515S0LW3

Fitment reminder: Match the complete model number, including suffixes and revision digits, before ordering. Contact us to verify your model number before ordering.
