Whirlpool Gas Dryer Not Heating or Igniting? Valve Assembly W11216837 – Fix Gas Flow Failure Fast

A gas dryer that tumbles but produces no heat, ignites briefly then goes cold, or never ignites at all almost always has a failed gas valve assembly. In most Whirlpool and Maytag gas dryers, the valve assembly contains the solenoid coils that open the gas valve during each ignition cycle — when one or more coils fail, the valve stays closed and gas cannot reach the burner. When it fails, the igniter may glow normally but the burner never lights, or the dryer heats for one cycle then goes cold for the rest. ⚡ Failed gas valve coils are the most common cause of no-heat on Whirlpool-platform gas dryers. Part W11216837 is the genuine OEM valve assembly that restores reliable gas flow and consistent heat immediately.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

• ✔ Your dryer is a Whirlpool or Maytag gas model (MGD, WGD, YMGD, or YWGD series)
• ✔ The drum tumbles normally — motor and belt are working
• ✔ The igniter glows orange/red but the burner does not light — or lights once then goes cold
• ✔ The thermal fuse and high-limit thermostat test good (continuity confirmed)
• ✔ ONLY problem is no heat or intermittent heat — not a drum, motor, or control fault

Not sure? Send us your model number — we’ll confirm before you order.

🔧 Common Symptoms

• Gas dryer not heating — drum tumbles but clothes come out cold and damp
• Igniter glows but burner never lights — valve coils not opening the valve
• Dryer heats for first cycle then goes cold for remainder of load
• Long drying times despite clean lint filter and clear exhaust duct
• Burning smell from igniter area without actual flame ignition
• Dryer runs full cycle with no heat — clothes still wet at end

✔ If these symptoms match, this is the most likely failed component in the system.

✔ In most cases, replacing the gas valve assembly restores consistent heat and normal drying immediately.

📦 Part Details

• Part Number: W11216837
• Type: Gas Dryer Valve Assembly — includes solenoid coil pack and valve body
• Replaces: OEM direct-fit valve assembly — supersedes W11157054 (no modification required)
• Brands: Whirlpool, Maytag, Amana, Kenmore (gas dryer models)

⚙️ Installation

Skill Level: Moderate — 30–45 min DIY. Unplug the dryer and close the gas supply valve before beginning any service. Access the burner assembly from the front or bottom panel depending on your model — disconnect the wire harness from the valve coils and remove the valve mounting screws. Note the orientation of the coil pack before removing it from the valve body. Install the new W11216837 assembly in the same orientation, reconnect the harness, restore gas supply, and plug in the dryer. Run a heat cycle and confirm the burner ignites and sustains flame before reassembling panels. Check all gas connections for leaks with soapy water before leaving the area.

💡 Pro Tip
