W11260592 Whirlpool Refrigerator Wire Harness – Fix Electrical Faults, Ice Maker Failures & Component Errors

Replaces W10292244 Replaces W10280423, W11050969 Whirlpool, Maytag, KitchenAid, Amana

A damaged or failed wire harness disrupts the electrical connections between the refrigerator’s control board, compressor, fans, ice maker, and sensors. When the harness fails, components stop receiving power or signals — resulting in intermittent cooling, ice maker shutdowns, error codes, or complete loss of function. The W11260592 is the genuine OEM wire harness for Whirlpool, Maytag, KitchenAid, and Amana refrigerators, directly replacing W10292244, W10280423, W11050969, and WPW10292244.

⚠️ Pro tip: Before replacing the wire harness, inspect all connectors and terminals for corrosion, burn marks, or loose pins — a single damaged connector can cause the same symptoms as a fully failed harness. If connectors are clean and seated, the harness itself is the likely cause. Always unplug the refrigerator before disconnecting any wiring.

Common Symptoms This Fixes

  • Refrigerator not cooling or cooling intermittently
  • Ice maker stopped working or producing no ice
  • Error codes or fault codes on the control panel display
  • Fan motors not running (evaporator or condenser fan)
  • Compressor not starting or cycling on and off erratically
  • Lights or dispenser not functioning
  • Visible burn marks, melted insulation, or damaged connectors on the existing harness

Part Details

  • Part Number: W11260592
  • Replaces: W10292244, WPW10292244, W10280423, W11050969
  • Type: Refrigerator main wire harness assembly
  • Compatible Brands: Whirlpool, Maytag, KitchenAid, Amana, Inglis

Installation Notes

Difficulty: Moderate — 30–60 minutes. Always unplug the refrigerator before servicing. Photograph all connector locations and routing paths before disconnecting the old harness. Disconnect each connector one at a time and reconnect to the new harness in the same position. Route the new harness along the same path as the original to avoid pinching. Plug in and test all functions before closing up.

Why Order From XPart Supply?

  • In stock for same-day shipping when ordered before 4PM
  • Genuine OEM parts from trusted suppliers
  • Fast fulfillment across Canada and the US
  • Expert support — contact us to confirm compatibility

W11260592 Whirlpool Refrigerator Wire Harness – Parts Diagram

✅ Cross Reference Information

Part number W11260592 replaces W10280423, W10292244, W11050969, WPW10292244
