Whirlpool Washer Electronic Control Board W11411581, Replaces W11043670, W11158149, W11298486

Genuine Whirlpool electronic control board (central control unit) for a washer; manages functions including filling, washing, draining, and spinning.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Washer does not power on or cycles cannot be selected.
• Washer does not advance through its cycle.
• Washer displays error codes.
• Washer has improper agitation or spin operation.
• Washer drains unexpectedly or has extended cycle times.

Check Before Replacing

• Confirm the wall outlet has power and check the household breaker or fuse before attributing a no-operation condition to the control.
• Use the model-specific tech sheet to enter service diagnostics and retrieve stored fault codes; codes can point to other systems such as the lid lock, valves, drain pump, motor, or wiring.
• With power disconnected, inspect accessible control-board wiring connections for loose or displaced connectors before replacing the board.
• Do not perform energized voltage measurements unless qualified to do so; the technical manual limits diagnostic voltage measurements to authorized technicians.

Pro Tip

Part Details

Key Features

• Genuine OEM Whirlpool/Maytag electric control board.
• Central control unit for major washer functions including fill, agitation, rinse, drain, and spin.
• Operates at 120 volts.
• The cycle-selector knob connects to this control, and the board is supplied in its plastic control housing.

Installation Notes

• Disconnect electrical power before servicing the washer.
• Follow the appliance's model-specific tech sheet/service information rather than generic control-board instructions.
• Before disconnecting the old board, document connector locations; reconnect every harness and the pressure hose, where applicable, to the corresponding location on the replacement board.
• After replacement, perform the model-specified calibration procedure where required.

Verified Compatible Models

MVWP575GW0, MVWP576KW0

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
