Whirlpool Washer Hose, Pressure Switch Assembly W11456953, Replaces W11041162, W11314654, W11319791

OEM pressure-switch hose assembly used in Whirlpool-family washing machines; it connects the tub air pressure system to the water-level pressure switch.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Washer may overfill or underfill because the pressure signal is restricted, leaking, or interrupted.
• Water-level sensing or pressure-sensor errors may occur.
• The washer may fail to recognize the correct fill level or may stop filling unexpectedly.
• A loose, kinked, obstructed, or damaged hose can prevent normal pressure feedback.

Check Before Replacing

• Disconnect electrical power before inspecting the hose or accessing internal components.
• Visually inspect the hose and both connection points for disconnection, cracking, abrasion, or obvious leakage.
• Check that the hose is routed correctly and is not pinched, kinked, or crimped.
• Check the hose and connected air-trap path for visible water, suds, or debris; do not use sharp objects or force excessive air pressure through the hose.
• If the hose appears clear and correctly connected, follow the washer’s model-specific service diagnostic procedure before replacing the hose, because the pressure switch, air trap, wiring, or control may also be involved.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM hose assembly.
• Designed for the washer pressure-sensing circuit.
• Connects the tub air-pressure system with the water-level pressure switch.
• Listed by Parts Town with approximate dimensions of 7.1 × 6.55 × 2.85 inches and weight of 0.07 lb.

Installation Notes

• Disconnect power before installation or service access.
• Reconnect the hose firmly at the pressure-switch and tub/air-trap connection points.
• Route the replacement hose as the original was routed, keeping it free of pinches, sharp bends, and cabinet interference.
• Verify that the hose and connections are clear and secure before restoring power and testing the washer.

Verified Compatible Models

7MMHW6621HC0, 7MMHW6621HC1, 7MMHW6621HC2, 7MMHW6621HW0, 7MMHW6621HW1, 7MWFC9822HC0, 7MWFC9822HC1, 7MWFW560CHW0, 7MWFW560CHW1, 7MWFW560CHW2, 7MWFW5622HW0, 7MWFW6621HC0, 7MWFW6621HC2, 7MWFW6622HW0, 7MWFW6622HW1

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
