Whirlpool Washer User Control and Display Board Assembly / Console Fascia Assembly W11478519, Replaces W11112918, W11413406

Whirlpool OEM washer user-interface and control-panel assembly. The assembly is mounted on the control panel and provides the washer’s control surface and display functions.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Washer will not start because control-panel inputs are not registering.
• Some control-panel buttons work while others do not.
• Display is blank or malfunctioning even though the washer has power.
• Cycle settings cannot be selected or changed through the console.

Check Before Replacing

• Confirm the washer is receiving power and that the household circuit has not tripped.
• Press several control-panel buttons and note whether all, some, or none respond.
• If the display is blank or controls are unresponsive, disconnect power to the washer, restore power after a short reset, and retest.
• If only some controls fail, compare the affected buttons with functioning buttons before identifying the user-interface assembly as the cause.
• Disconnect power before inspecting the console assembly or its accessible wiring connections; do not test live circuitry unless qualified.

Pro Tip

Part Details

Key Features

• Whirlpool OEM washer user-control and display assembly.
• Combines the washer’s control interface and display functions in the console assembly.
• Mounted on the washer control panel.
• Supports user input for cycle and option selection.

Installation Notes

• Disconnect electrical power before servicing or replacing the assembly.
• Use the model-specific service information and installation instructions for console access and connector placement.
• Protect the console and electronic components from moisture and static discharge during handling.
• Reassemble the control panel and any removed covers before restoring power and testing the washer.

Verified Compatible Models

WTW5100HC0, WTW5100HC1, WTW5100HC2, WTW5100HW0, WTW5100HW1, WTW5100HW2, WTW5105HC0, WTW5105HC1, WTW5105HC2, WTW5105HC3, WTW5105HC4, WTW5105HW0, WTW5105HW1, WTW5105HW2, WTW5105HW3

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
