Refrigerator Not Dispensing Water or Ice? Water Inlet Valve W11647768 – Fix No Flow Fast
No water from the dispenser and no ice production almost always trace back to a failed water inlet valve. In most Whirlpool, KitchenAid, and Maytag refrigerators, the water inlet valve is the electrically controlled solenoid that opens to allow water into the ice maker and dispenser system. When it fails, water flow stops entirely, slows to a trickle, or the ice maker stops producing — even when water pressure at the supply line is confirmed normal. ⚡ Common failure point in Whirlpool-built French door and side-by-side refrigerators. Part W11647768 is the genuine OEM replacement that restores full water and ice dispenser function immediately upon installation.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ Your refrigerator powers on and all other functions work normally
- ✔ The ice maker motor and dispenser auger are functioning correctly
- ✔ Household water supply line pressure is confirmed adequate (min. 20 PSI)
- ✔ ONLY problem is no water at the dispenser, no ice production, or severely reduced water flow
Not sure? Send us your model number — we'll confirm before you order.
🔧 Common Symptoms
- Water dispenser produces no water or only a slow trickle
- Ice maker stopped making ice entirely
- Ice maker fills very slowly or produces undersized cubes
- Humming or buzzing from the back of the fridge when dispenser is activated but no water flows
✔ If these symptoms match, this is the most likely failed component in the system.
✔ In most cases, replacing this water inlet valve restores full water and ice dispenser operation immediately.
📦 Part Details
- Part Number: W11647768
- Type: Refrigerator Water Inlet Valve (dual solenoid)
- Replaces: W11175771, W10408179, W10498976
- Brands: Whirlpool, KitchenAid, Maytag, Amana
Inspect the water supply line and filter at the same time. A clogged or expired water filter (replace every 6 months) can mimic valve failure symptoms by restricting flow. Replace the filter first — if flow is still poor after a fresh filter, the valve is your fix. Also check the water line for kinks behind the fridge before ordering.
⚙️ Installation
Skill Level: Moderate — 20 to 30 minutes. Disconnect power and shut off the water supply before servicing. Pull the refrigerator away from the wall to access the valve at the rear lower panel. Disconnect the water lines and electrical connectors, remove the mounting screws, and swap in the new valve. Reconnect all lines, restore water supply, and check for leaks before pushing the fridge back and restoring power.
✓ Compatible Models
Confirmed compatible with WRF535SWHZ00, WRF535SWHZ01, WRS325SDHZ00, WRS325SDHZ01, WRS571CIHZ00, WRX735SDHZ00, WRX735SDHZ05, MFI2570FEZ00, MFI2570FEZ01, KRMF706ESS00, WRF532SMHZ05, WRF532SMHZ06 plus additional Whirlpool, KitchenAid, and Maytag refrigerator models. Contact us to verify your model number before ordering.
💡 Pro Tip
Use a multimeter to test solenoid resistance across each valve coil — a healthy solenoid reads approximately 200–500 ohms. An open circuit (OL) or zero reading confirms the coil is burned out and the valve must be replaced. This 2-minute test saves you from pulling the fridge apart unnecessarily and confirms W11647768 is your fix before you order.
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
