Dryer Not Heating Properly? Thermostat WP3387137 – Fix Heat Cycling Issues Fast
A failed cycling thermostat is one of the most common reasons a dryer runs but produces no heat — or overheats and shuts off mid-cycle. In most Whirlpool-platform dryers, the cycling thermostat regulates the drum temperature by cycling the heating element on and off. When it fails, the dryer either runs cold, overheats and trips the thermal fuse, or shuts off before clothes are dry. ⚡ Common failure point in Whirlpool, Maytag, Kenmore, and KitchenAid dryers built on the same platform. Part WP3387137 is the genuine OEM replacement that restores accurate temperature cycling and protects your thermal fuse from repeat failures.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ Dryer powers on and drum turns normally
- ✔ Timer and controls respond correctly
- ✔ Thermal fuse has been tested and is not blown (or has already been replaced)
- ✔ ONLY problem is no heat, insufficient heat, or dryer shutting off before cycle completes
Not sure? Send us your model number — we'll confirm before you order.
🔧 Common Symptoms
- Dryer runs but produces no heat
- Clothes still damp after a full cycle
- Dryer overheats and shuts off mid-cycle
- Thermal fuse blows repeatedly after replacement
- Dryer takes multiple cycles to dry a normal load
✔ If these symptoms match, the cycling thermostat is the most likely failed component in the heat circuit.
✔ In most cases, replacing this thermostat restores normal drying performance immediately.
📦 Part Details
- Part Number: WP3387137
- Type: Cycling Thermostat — regulates drum temperature by cycling the heating element on and off
- Replaces: 3387137, 3387135, AP6008270, PS11741406, EAP11741406
- Brands: Whirlpool, Maytag, Kenmore, KitchenAid, Roper, Estate, Inglis, Amana
If your thermal fuse also blew, replace it at the same time — a failed cycling thermostat is the #1 cause of repeat thermal fuse failures. Replacing only the fuse without fixing the thermostat will result in the fuse blowing again. Check our store for the matching thermal fuse for your model.
⚙️ Installation
Skill Level: EASY — 20–30 minutes. Disconnect power before servicing. Remove the back panel or front panel depending on your model to access the heating element housing. The cycling thermostat mounts directly to the heating element housing with two screws and two spade connectors. Disconnect the wires, swap the thermostat, reconnect, and reassemble. No special tools required.
✓ Compatible Models
Confirmed compatible with WED4800XQ1, WED4900XW0, WED5000DW0, WED5100VQ1, WED5200VQ1, WED5300SQ0, WED5500XW0, WED5600XW0, WED5700XW0, WED5800SW0, WED6200SW1, WED7300XW0, WED8300SW0, MED5100DW0, MED5500FW0, MED5600TQ0, MED5700TQ0, MED5800TW0, MED6200TQ1, MED7300XW0, 110.66132500, 110.66142500, 110.66152500, 110.66162500, 110.66172500, 110.66182500, 110.66192500, 110.66202500, 110.66212500, 110.66222500, 110.66232500, 110.66242500, 110.66252500, 110.66262500, 110.66272500, 110.66282500, 110.66292500, 110.66302500, 110.66312500, 110.66322500, 110.66332500, 110.66342500, 110.66352500, 110.66362500, 110.66372500, 110.66382500, 110.66392500, 110.66402500, 110.66412500, 110.66422500, 110.66432500, 110.66442500, 110.66452500, 110.66462500, 110.66472500, 110.66482500, 110.66492500, 110.66502500, 110.66512500, 110.66522500, 110.66532500, 110.66542500, 110.66552500, 110.66562500, 110.66572500, 110.66582500, 110.66592500, 110.66602500, 110.66612500, 110.66622500, 110.66632500, 110.66642500, 110.66652500, 110.66662500, 110.66672500, 110.66682500, 110.66692500, 110.66702500, 110.66712500, 110.66722500, 110.66732500, 110.66742500, 110.66752500, 110.66762500, 110.66772500, 110.66782500, 110.66792500, 110.66802500, 110.66812500, 110.66822500, 110.66832500, 110.66842500, 110.66852500, 110.66862500, 110.66872500, 110.66882500, 110.66892500, 110.66902500, 110.66912500, 110.66922500, 110.66932500, 110.66942500, 110.66952500, 110.66962500, 110.66972500, 110.66982500, 110.66992500, KEYS750GQ0, KEYS750LQ0, KEYS750LQ1, KEYS850GQ0, KEYS850JQ0, KEYS850JQ1, KEYS850LQ0, KEYS850LQ1, KGYS750GQ0, KGYS750LQ0, KGYS750LQ1, KGYS850GQ0, KGYS850JQ0, KGYS850JQ1, KGYS850LQ0, KGYS850LQ1 plus additional Whirlpool-platform models. Contact us to verify your model number before ordering.
💡 Pro Tip
If your thermal fuse blew, the cycling thermostat almost certainly caused it. Replacing just the fuse is a temporary fix — the fuse will blow again within weeks if the thermostat is still faulty. Save yourself a second repair call by replacing both components together. It adds less than $15 to the repair and eliminates the most common callback on this job.
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
