Item #42 in diagram.

Thermistor, Temperature Sensor, Dryer Sensor, NTC Thermistor, Moisture Sensor, Temperature Control Sensor

3390292, 3406294, 3976615, 772546, 8577274, WP8577274VP

Whirlpool, Kenmore, Maytag, KitchenAid, Roper, Estate, Inglis, Crosley, Amana

11060052990, 11060052991, 11060056990, 11060056991, 1106007299, 11060072990, 11060072991, 11060092990, 11060092991, 11060094990, 11060094991, 11060096990, 11060096991, 11060097990, 11060372710, 11060882990, 11060884990, 11060887990, 1106093299, 11060932990, 1106093699, 11060936990, 1106094299, 11060942990, 1106095299, 11060952990, 11060954990, 1106095699, 11060956990, 1106095799, 11060957990, 11060972990, 1106098299, 11060982990, 1106099299, 11060992990, 11060994990, 1106099699, 11060996990, 1106099799, 11060997990, 11061062000, 11061064000, 11061066000, 11061082000, 11061084000, 11061086000, 11061092000, 11061632610, 11061632611, 11061633611, 11062032100, 11062036100, 11062042100, 11062052100, 11062054100, 11062056100, 11062062100, 11062062101, 11062062102, 11062062103, 11062064100, 11062064101, 11062064102, 11062064103, 11062066100, 11062066101, 11062066102, 11062066103, 11062082100, 11062082101, 11062082102, 11062084100, 11062084101, 11062084102, 11062086100, 11062086101, 11062086102, 11062882100, 11062882101, 11062884100, 11062884101, 11062886100, 11062886101, 11062932100, 11062936100, 11062942100, 11062952100, 11062954100, 11062956100, 11062972100, 11062972101, 11062972102, 11062974100, 11062974101, 11062974102, 11062982100, 11062982101, 11062982102, 11062992100, 11062992101, 11062992102, 11062994100, 11062994101, 11062994102, 11062996100, 11062996101, 11062996102, 11063042100, 11063042101, 11063042102, 11063046100, 11063046101, 11063046102
11063052100, 11063052101, 11063052102, 11063062100, 11063062101, 11063062102, 11063064100, 11063064101, 11063064102, 11063066100, 11063066101, 11063066102, 11063932100, 11063932101, 11063932102, 11063942100, 11063942101, 11063942102, 11063952100, 11063952101, 11063952102, 11063954100, 11063954101, 11063954102, 11063956100, 11063956101, 11063956102, 11064082200, 11064082201, 11064082202, 11064084200, 11064084201, 11064084202, 11064086200, 11064086201, 11064086202, 11064972300, 11064972301, 11064976300, 11064976301, 11064982300, 11064982301, 11064992300, 11064992301, 11064994300, 11064994301, 11064996300, 11064996301, 11065062500, 11065064500, 11065066500, 11066002010, 11066952690, 11066952691, 11066954690, 11066954691, 11066955690, 11066955691, 11066972500, 11066972501, 11066982500, 11066982501, 11066992500, 11066992501, 11066994500, 11066994501, 11066996500, 11066996501, 11067032600, 11067032601, 11067042600, 11067042601, 11067052600, 11067062600, 11067072600, 11067082600, 11067086600, 11067087600, 11067092600, 11067102310, 11067132411, 11067841600, 11067851600, 11067861600, 11067862600, 11067864600, 11068002010, 11068002011, 11068062800, 11068062801, 11068072800, 11068072801, 11068082700, 11068082701, 11068087701, 11068092700, 11068092701, 11068097701, 11068103310, 11068132411, 11068132412, 11068132414, 11068133412, 11068133413, 11068133414, 11068822700, 11068832700, 11068837700, 11068842700, 11068847700, 11068932790, 11068932791, 11068932792, 11068934790, 11068934791, 11068934792, 11068942890, 11068942891, 11068942892, 11068944890, 11068944891, 11068944892, 11068972890, 11068972891, 11068972892, 11068974890, 11068974891, 11068974892, 11069132410, 11069132411, 11069132412, 11069132413, 11069133411, 11069133412, 11069133413, 11069133414, 11069822800, 11069822801
11069832800, 11069832801, 11070052990, 11070052991, 11070056990, 11070056991, 11070072990, 11070072991, 11070092990, 11070092991, 11070094990, 11070094991, 11070096990, 11070096991, 11070097990, 11070372710, 11070882990, 11070882991, 11070884990, 11070884991, 11070887990, 11070887991, 11070932990, 11070936990, 11070942990, 1107095299, 11070952990, 11070954990, 1107095699, 11070956990, 1107095799, 11070957990, 1107097299, 11070972990, 11070982990, 1107099299, 11070992990, 11070994990, 1107099699, 11070996990, 11070997990, 11071062000, 11071064000, 11071066000, 11071082000, 11071084000, 11071086000, 11071092000, 11071633610, 11072032100, 11072036100, 11072042100, 11072052100, 11072054100, 11072056100, 11072062100, 11072062101, 11072062102, 11072062103, 11072064100, 11072064101, 11072064102, 11072064103, 11072066100, 11072066101, 11072066102, 11072066103, 11072082100, 11072082101, 11072082102, 11072084100, 11072084101, 11072084102, 11072086100, 11072086101, 11072086102, 11072882100, 11072882101, 11072884100, 11072884101, 11072886100, 11072886101, 11072932100, 11072936100, 11072942100, 11072952100, 11072954100, 11072956100, 11072972101, 11072972102, 11072972103, 11072974101, 11072974102, 11072974103, 11072982101, 11072982102, 11072982103, 11072992100, 11072992101, 11072992102, 11072994100, 11072994101, 11072994102, 11072996100, 11072996101, 11072996102, 11073042100, 11073042101, 11073042102, 11073046100, 11073046101, 11073046102, 11073052100, 11073052101, 11073052102, 11073062100, 11073062101, 11073062102, 11073064100, 11073064101, 11073064102, 11073066100, 11073066101, 11073066102, 11073932100, 11073932101, 11073932102, 11073932103, 11073942100, 11073942101, 11073942102, 11073952100, 11073952101, 11073952102, 11073954100, 11073954101, 11073954102, 11073956100, 11073956101, 11073956102, 11074082200, 11074082201, 11074082202, 11074084200, 11074084201, 11074084202, 11074086200, 11074086201, 11074086202, 11074972300, 11074972301, 11074976300, 11074976301, 11074982300, 11074982301, 11074992300, 11074992301, 11074994300, 11074994301, 11074996300, 11074996301, 11075062500, 11075062501, 11075064500, 11075066500, 11075066501, 11076002010, 11076002011, 11076134610, 11076952690, 11076952691, 11076952692, 11076952693, 11076954690, 11076954691, 11076954692, 11076954693, 11076955690, 11076955691, 11076955692, 11076955693, 11076972500, 11076972501, 11076972502, 11076982500, 11076982501, 11076982502, 11076992500, 11076992501, 11076992502, 11076994500, 11076996500, 11077032600, 11077032601, 11077042600, 11077042601, 11077052600, 11077062600, 11077072600, 11077082600, 11077086600, 11077087600, 11077092600, 11077102310, 11077132411, 11077132412, 11077841600, 11077851600, 11077861600, 11077862600, 11077864600, 11078002010, 11078002011, 11078002012, 11078062801, 11078072801, 11078082700, 11078082701, 11078087701, 11078092700, 11078092701, 11078097701, 11078132412, 11078132413, 11078133410, 11078133412, 11078822700, 11078832700, 11078837700, 11078842700, 11078847700, 11078932790, 11078932791, 11078932792, 11078934790, 11078934791, 11078934792, 11078942890, 11078942891, 11078942892, 11078944890, 11078944891, 11078944892, 11078972890, 11078972891, 11078972892, 11078974890, 11078974891, 11078974892, 11079132411, 11079132412, 11079132413, 11079132414, 11079133410, 11079133412, 11079133413, 11079133414, 11079822800, 11079822801, 11079832800, 11079832801, 11081932511, 11081942710, 11081952710, 11082822100, 11082822101, 11082822102, 11082822103, 11082824100, 11082824101, 11082824102, 11082824103, 11082826100, 11082826101, 11082826102, 11082826103, 11082832100, 11082834100, 11082836100, 11084821300, 11084821301, 11084831300, 11084831301, 11084832200, 11084832201, 11084832202, 11084834200, 11084834201, 11084834202, 11084836200, 11084836201, 11084836202, 11085081400, 11085081401, 11085087400, 11085087401, 11085088400, 11085088401, 11085089400, 11085089401, 11085091400, 11085091401, 11085861400, 11085861401, 11085862400, 11085862401, 11085866400, 11085866401, 11085871400, 11085872400, 11085872401, 11085874400, 11085874401, 11085876400, 11085876401, 11086562500, 11086562501, 11086572500, 11086572501, 11086694100, 11086694110, 11086694120, 11086694300, 11086694310, 11086694320, 11086694500, 11086694510, 11086694520, 11086694700, 11086694710, 11086694720, 11086694800, 11086694810, 11086694820, 11086742700, 11086742701, 11086742702, 11086747700, 11086747701, 11086747702, 11086757701, 11086762700, 11086762701, 11086894100, 11086894300, 11086894500, 11086894700, 11086894800, 11086994100, 11086994300, 11086994500, 11086994700, 11086994800, 11087081601, 11087081602, 11087086601, 11087086602, 11087087601, 11087087602, 11087088601, 11087088602, 11087089601, 11087089602, 11087091601, 11087511700, 11087511701, 11087511702, 11087531700, 11087531701, 11087531702, 11087561601, 11087561602, 11087561603, 11087562601, 11087562602, 11087562603, 11087566601, 11087566602, 11087566603, 11087567700, 11087567701, 11087571601, 11087571602, 11087571603, 11087572601, 11087572602, 11087572603, 11087576601, 11087576602, 11087576603, 11087577700, 11087581601, 11087582601, 11087694100, 11087694300, 11087694500, 11087694700, 11087694800, 11087701700, 11087701701, 11087709700, 11087709701, 11087721700, 11087721701, 11087721702, 11087727701, 11087727702, 11087728701, 11087728702, 11087729700, 11087729701, 11087729702, 11087731700, 11087731701, 11087731702, 11087737701, 11087737702, 11087738701, 11087738702, 11087739701, 11087739702, 11087751800, 11087751801, 11087761800, 11087761801, 11087872601, 11087872602, 11087872603, 11087892601, 11087892602, 11087894100, 11087894300, 11087894500, 11087894700, 11087894800, 11087994100, 11087994300, 11087994500, 11087994700, 11087994800, 11091932511, 11091942710, 11091952710, 11092822100, 11092822101, 11092822102, 11092822103, 11092824100, 11092824101, 11092824102, 11092824103, 11092826100, 11092826101, 11092826102, 11092826103, 11092832100, 11092834100, 11092836100, 11094821300, 11094821301, 11094831300, 11094831301, 11094832200, 11094832201, 11094832202, 11094834200, 11094834201, 11094834202, 11094836200, 11094836201, 11094836202, 11095081400, 11095081401, 11095081402, 11095087400, 11095087401, 11095087402, 11095088400, 11095088401, 11095088402, 11095089400, 11095089401, 11095089402, 11095091400, 11095091401, 11095091402, 11095861400, 11095861401, 11095862400, 11095862401, 11095862402, 11095866400, 11095866401, 11095866402, 11095871400, 11095871401, 11095872400, 11095872401, 11095872402, 11095874400, 11095874401, 11095874402, 11095876400, 11095876401, 11095876402, 11096094100, 11096094300, 11096094500, 11096094700, 11096094800, 11096195100, 11096195110, 11096195120, 11096195500, 11096195510, 11096195520, 11096195800, 11096195810, 11096195820, 11096562500, 11096562501, 11096572500, 11096572501, 11096595200, 11096595220, 11096595400, 11096595420, 11096595500, 11096595520, 11096694700, 11096694800, 11096742700, 11096742701, 11096742702, 11096747701, 11096747702, 11096757701, 11096757702, 11096762700, 11096762701, 11097081601, 11097081602, 11097086601, 11097086602, 11097087601, 11097087602, 11097088601, 11097088602, 11097089601, 11097089602, 11097091601, 11097094100, 11097094300, 11097094500, 11097094700, 11097094800, 11097195100, 11097195110, 11097195120, 11097195500, 11097195510, 11097195520, 11097195800, 11097195810, 11097195820, 11097511701, 11097511702, 11097531700, 11097531701, 11097531702, 11097561601, 11097561602, 11097561603, 11097562601, 11097562602, 11097562603, 11097566601, 11097566602, 11097566603, 11097567700, 11097567701, 11097571601, 11097571602, 11097571603, 11097572601, 11097572602, 11097572603, 11097576602, 11097576603, 11097577700, 11097581601, 11097582601, 11097595200, 11097595220, 11097595400, 11097595420, 11097595500, 11097595520, 11097701700, 11097709700, 11097721700, 11097721701, 11097721702, 11097727701, 11097727702, 11097728701, 11097728702, 11097729700, 11097729701, 11097729702, 11097731700, 11097731701, 11097731702, 1109773701, 11097737701, 11097738701, 11097738702, 11097739701, 11097751800, 11097751801, 11097761800, 11097761801, 11097872601, 11097872602, 11097872603, 11097892601, 11097892602, 110C66012011, 110C66112310, 110C66132410, 110C66132411, 110C67032601, 110C67042801, 110C67132411, 110C68012011, 110C68102310, 110C68132410, 110C68132413, 110C69132410, 110C69133410, 110C76112310, 110C85081400, 110C85087400, 110C85088400, 110C85089400, 110C87561601, 110C87562601, 110C87566601, 110C87571601, 110C87572601, 110C87576601, 110C96562500, 3LCED9100WQ0, 3LCED9100WQ1, 3LCED9100WQ2, 3LCGD9100WQ0, 3LCGD9100WQ1, 3LCGD9100WQ2, 3LCGD9100WQ3, 3LWED5500YW0, 3LWED5500YW1, 3LWED5500YW2, 4GMEDX500YW0, 4GMEDX500YW2, 4GWED5500YW0, 4GWED5500YW1, 4GWED5500YW2, 4GWED5500YW3, 4KMEDX505BW1, 7EWED5550YW0, 7EWED5550YW1, 7MGGW9200MW0, 7MGGW9200MW1, 7MGGW9200MW2, 7MGGW9200MW3, 7MGGW9868KL1, 7MGGW9868KQ1, 7MGGX9868JQ1, 7MGGX9868JQ2, 7MMEDX550XW0, 7MMEDX550XW1, 7MMGD0100TQ0, 7MMGD0100TQ1, 7MMGD0600TB0, 7MMGD0600TB1, 7MMGD6630HC0, 7MMGD6630HC1, 7MMGD6630HW0, 7MMGD6630HW1, 7MMGDB835EW0, 7MMGDB835EW2, 7MMGDB850WL0, 7MMGDB850WL1, 7MMGDB855EC0, 7MMGDB855EC1, 7MMGDB855EC2, 7MMGDB950AG0, 7MMGDB950AG1, 7MMGDX550XW0, 7MMGDX550XW1, 7MMGDX600BW0, 7MMGDX700BG0, 7MMGDX700YL0, 7MMGDX700YL1, 7MMGE7973TW0, 7MMGE7973TW1, 7MMGE9959TB0, 7MMGE9959TW0, 7MMGM0100VW0, 7MWED5600BW0, 7MWED5620HW0, 7MWED5620HW1, 7MWED6613HC0, 7MWED6613HC1, 7MWED6613HW0, 7MWED6613HW1, 7MWED81HEDW0, 7MWED90HEFW0, 7MWED90HEFW1, 7MWED90HEFW2, 7MWG77900SB0, 7MWG77900SW0, 7MWGD5550XW0, 7MWGD5550XW1, 7MWGD5600BW0, 7MWGD5622HW0, 7MWGD5622HW1, 7MWGD5700BC0, 7MWGD5700YW0, 7MWGD5700YW1, 7MWGD6620HW0, 7MWGD6620HW1, 7MWGD6621HC0, 7MWGD6621HC1, 7MWGD7000EW0, 7MWGD7000EW1, 7MWGD7000EW2, 7MWGD72HEDW0, 7MWGD72HEDW1, 7MWGD75HEFW0, 7MWGD7800XW0, 7MWGD8000EW0, 7MWGD8000EW1, 7MWGD8000EW2, 7MWGD81HEDW0, 7MWGD8300SW0, 7MWGD8300SW1, 7MWGD8500EC0, 7MWGD8500EC1, 7MWGD8500EC2, 7MWGD8500SR0, 7MWGD8500SR1, 7MWGD8500SR2, 7MWGD8620HC0, 7MWGD8620HC1, 7MWGD87HEDC0, 7MWGD87HEDC1, 7MWGD8800AW0, 7MWGD8800AW1, 7MWGD90HEFC0, 7MWGD90HEFC1, 7MWGD90HEFW0, 7MWGD90HEFW1, 7MWGD9150XW0, 7MWGD9150XW1, 7MWGD9150XW2, 7MWGD9150XW3, 7MWGD9200TQ0, 7MWGD9200TQ1, 7MWGD9270XL0, 7MWGD9270XL1, 7MWGD9270XR0, 7MWGD9270XR1, 7MWGD9400TU0, 7MWGD9400TU1, 7MWGD9400TU2, 7MWGD95HEDU0, 7MWGD97HDBD0, 8TMGD6630HW0, 8TMGD6630HW1, 8TWED5620HW0, 8TWED5620HW1, 8TWGD5620HW0, 8TWGD5620HW1, 8TWGD6622HW0, 8TWGD6622HW1, 8TWGD8620HW0, 8TWGD8620HW1, BSG17B6ANA0, BSG17BVANA0, BSG17CCANA0, CDG8990XW1, CED7464GW0, CED7464GW1, CED8990XW0, CED8990XW1, CED9050AW0, CED9060AW0, CED9150GW0, CED9160GW0, CET8000AQ0, CET8000AQ1, CET8000XQ0, CEW9100VQ0, CEW9100WQ0, CGD7464GW0, CGD8990XW0, CGD8990XW1, CGD8990XW2, CGD9050AW0, CGD9050AW1, CGD9060AW0, CGD9060AW1, CGD9150GW0, CGD9160GW0, CGT8000AQ0, CGT8000AQ1, CGT8000XQ0, CGW9100VQ0, CGW9100WQ0, GEQ9858JQ0, GEQ9858JQ1, GEQ9858JT0, GEQ9858JT1, GEW9200LL1, GEW9200LL2, GEW9200LQ0, GEW9200LQ1, GEW9200LQ2, GEW9200LT1, GEW9200LT2, GEW9200LW0, GEW9200LW1, GEW9200LW2, GEW9250PL0, GEW9250PL1, GEW9250PT0, GEW9250PT1, GEW9250PW0, GEW9250PW1, GEW9250SU0, GEW9260PL0, GEW9260PL1, GEW9260PW0, GEW9260PW1, GEW9868KL0, GEW9868KL1, GEW9868KL2, GEW9868KL3, GEW9868KL4, GEW9868KQ0, GEW9868KQ1, GEW9868KQ2, GEW9868KQ3, GEW9868KQ4, GEW9868KT0, GEW9868KT1, GEW9868KT2, GEW9868KT3, GEW9868KT4, GEW9878JQ0, GEW9878JQ1, GEW9878JT0, GEW9878JT1, GEW9878LG0, GEW9878LW0, GEW9878LW1, GEW9878PG0, GEW9878PG1, GEW9878PW0, GEW9878PW1, GEX9868JQ0, GEX9868JQ1, GEX9868JQ2, GEX9868JQ3, GEX9868JT0, GEX9868JT1, GEX9868JT2, GEX9868JT3, GGQ9858JQ0, GGQ9858JQ1, GGQ9858JQ2, GGQ9858JT0, GGQ9858JT1, GGQ9858JT2, GGW9200LL1, GGW9200LL2, GGW9200LQ0, GGW9200LQ1, GGW9200LQ2, GGW9200LT1, GGW9200LT2, GGW9200LW0, GGW9200LW1, GGW9200LW2, GGW9250PL0, GGW9250PL1, GGW9250PL2, GGW9250PL3, GGW9250PT0, GGW9250PT1, GGW9250PT2, GGW9250PT3, GGW9250PW0, GGW9250PW1, GGW9250PW2, GGW9250PW3, GGW9250SU0, GGW9260PL0, GGW9260PL1, GGW9260PL2, GGW9260PL3, GGW9260PW0, GGW9260PW1, GGW9260PW2, GGW9260PW3, GGW9868KL0, GGW9868KL1, GGW9868KL2, GGW9868KL3, GGW9868KL4, GGW9868KL5, GGW9868KQ0, GGW9868KQ1, GGW9868KQ2, GGW9868KQ3, GGW9868KQ4, GGW9868KQ5, GGW9868KT0, GGW9868KT1, GGW9868KT2, GGW9868KT3, GGW9868KT4, GGW9868KT5, GGW9878JQ0, GGW9878JQ1, GGW9878JQ2, GGW9878JT0, GGW9878JT1, GGW9878JT2, GGW9878LG0, GGW9878LW0, GGW9878LW1, GGW9878PG0, GGW9878PG1, GGW9878PW0, GGW9878PW1, GGX9868JQ0, GGX9868JQ1, GGX9868JQ2, GGX9868JQ3, GGX9868JQ4, GGX9868JT0, GGX9868JT1, GGX9868JT2, GGX9868JT3, GGX9868JT4, IGD7300WW0, IGD7300WW1, KEHS01PMT0, KEHS01PMT1, KEHS01PMT2, KEHS01PWH1, KEHS01PWH2, KEHS02RMT0, KEHS02RMT1, KEHS02RWH0, KEHS02RWH1, KEYS977EQ0, KEYS977EZ0, KEYW977BWH0, KGHS01PMT0, KGHS01PMT1, KGHS01PMT2, KGHS01PMT3, KGHS01PWH1, KGHS01PWH2, KGHS01PWH3, KGHS02RMT0, LE9800XSN0, LE9800XSW0, LEE9848BQ0, LEE9848BQ1, LEE9848BQ2, LEE9848BZ0, LEE9848BZ1, LEE9848BZ2, LG9701XSN0, LG9801XSW0, LGE9848BQ1, LGE9848BQ2, LGE9848BZ1, LGE9848BZ2, MDE20PDAGW0, MDE20PDAYW0, MDE20PDAZW0, MDE20PNAGW0, MDE20PRAYW0, MDE20PRAZW0, MDE22PDAGW0, MDE22PDAYW0, MDE22PDAZW0, MDE22PDBYW0, MDE22PDBZW0, MDE22PRAYW0, MDE22PRAZW0, MDE22PRBYW0, MDE22PRBZW0, MDE25PDAGW0, MDE25PDAGW1, MDE25PDAYW0, MDE25PDAYW1, MDE25PDAZW0, MDE25PDAZW1, MDE25PDAZWO, MDE25PDBGW0, MDE25PNAGW0, MDE25PNAGW1, MDE25PNBGW0, MDE25PRAYW0, MDE25PRAYW1, MDE25PRAZW0, MDE25PRAZW1, MDE28PDCGW0, MDE28PDCYW0, MDE28PDCZW0, MDE28PNCGW0, MDE28PRCYW0, MDE28PRCZW0, MDG20PDAGW0, MDG20PDAWW0, MDG20PDAXW0, MDG20PNAGW0, MDG20PRAWW0, MDG22PDAGW0, MDG22PDAWW0, MDG22PDAXW0, MDG22PDBWW0, MDG22PDBXW0, MDG22PNAGW0, MDG22PRAWW0, MDG22PRBWW0, MDG25PDAGW0, MDG25PDAGW1, MDG25PDAGW2, MDG25PDAGW3, MDG25PDAWW0, MDG25PDAWW1, MDG25PDAWW2, MDG25PDAXW0, MDG25PDAXW1, MDG25PDAXW2, MDG25PDBGW0, MDG25PNAGW0, MDG25PNAGW1, MDG25PNAGW2, MDG25PNAGW3, MDG25PNBGW0, MDG25PRAWW0, MDG25PRAWW1, MDG25PRAWW2, MDG28PDCGW0, MDG28PDCWW0, MDG28PDCXW0, MDG28PNCGW0, MDG28PRCWW0, MED3000BW0, MED3100DW0, MED3500FW0, MED3500FW1, MED4000BW0, MED4100DW0, MED4200BG0, MED4200BW0, MED5100DC0, MED5100DC1, MED5100DW0, MED5100DW1, MED5500FC0, MED5500FC1, MED5500FC2, MED5500FW0, MED5500FW1, MED5500FW2, MED5630HC0, MED5630HC1, MED5630HC2, MED5630HW0, MED5630HW1, MED5630HW2, MED5900TW0, MED5900TW1, MED5920TW0, MED5921TW0, MED6000AG0, MED6000AW0, MED6000XG0, MED6000XG1, MED6000XG2, MED6000XR0, MED6000XR1, MED6000XR2, MED6000XW0, MED6000XW1, MED6000XW2, MED6230HC0, MED6230HC1, MED6230HC2, MED6230HW0, MED6230HW1, MED6230HW2, MED6230RHW0, MED6230RHW1, MED6230RHW2, MED6300TQ0, MED6400TB0, MED6400TQ0, MED6600TQ0, MED6630HC0, MED6630HC1, MED6630HC2, MED6630HW0, MED6630HW1, MED7000AG0, MED7000AW0, MED7000XG0, MED7000XG1, MED7000XG2, MED7000XR0, MED7000XR1, MED7000XW0, MED7000XW1, MED7000XW2, MED7100DC0, MED7100DC1, MED7100DW0, MED7100DW1, MED7230HC0, MED7230HC1, MED7230HC2, MED7230HW0, MED7230HW1, MED7230HW2, MED8000AG0, MED8000AW0, MED8100DC0, MED8100DC1, MED8100DW0, MED8100DW1, MED8150EW0, MED8200FC0, MED8200FC1, MED8200FC2, MED8200FW0, MED8200FW1, MED8200FW2, MED8230HC0, MED8630HC0, MED8630HC1, MED8630HC2, MED8630HW0, MED8630HW1, MED8630HW2, MED9000YG0, MED9000YG1, MED9000YG2, MED9000YR0, MED9000YR1, MED9000YW0, MED9000YW1, MED9000YW2, MED9600SQ0, MED9700SB0, MED9700SQ0, MED9800TK0, MED9800TQ0, MEDB200VQ0, MEDB200VQ1, MEDB400VQ0, MEDB400VQ1, MEDB700BW0, MEDB700VQ0, MEDB725BW0, MEDB750YW0, MEDB750YW1, MEDB750YW2, MEDB755DW0, MEDB755DW1, MEDB755DW2, MEDB765FC0, MEDB765FW0, MEDB766FW0, MEDB800VB0, MEDB800VQ0, MEDB800VU0, MEDB835DC3, MEDB835DC4, MEDB835DW0, MEDB835DW1, MEDB835DW2, MEDB835DW3, MEDB835DW4, MEDB850WB0, MEDB850WB1, MEDB850WL0, MEDB850WL1, MEDB850WQ0, MEDB850WQ1, MEDB850WR0, MEDB850WR1, MEDB850YG0, MEDB850YG1, MEDB850YG2, MEDB850YW0, MEDB850YW1, MEDB850YW2, MEDB855DC0, MEDB855DC1, MEDB855DC2, MEDB855DC3, MEDB855DC4, MEDB855DW0, MEDB855DW1, MEDB855DW2, MEDB855DW3, MEDB855DW4, MEDB880BW0, MEDB950YG0, MEDB950YG1, MEDB950YG2, MEDB950YW0, MEDB950YW1, MEDB950YW2, MEDB955FC0, MEDB955FC1, MEDB955FC2, MEDB955FW0, MEDB955FW1, MEDB955FW2, MEDB980BG0, MEDB980BW0, MEDE200XW0, MEDE200XW1, MEDE201YW0, MEDE201YW1, MEDE250XL0, MEDE251YG0, MEDE251YG1, MEDE251YL0, MEDE251YL1, MEDE300VF0, MEDE300VF1, MEDE300VF2, MEDE300VW0, MEDE300VW1, MEDE301YG0, MEDE301YW0, MEDE400XR0, MEDE400XW0, MEDE500VF0, MEDE500VF1, MEDE500VP0, MEDE500VP1, MEDE500VW0, MEDE500VW1, MEDE500VW2, MEDE500WJ0, MEDE500WR0, MEDE900VJ0, MEDE900VJ1, MEDE900VW0, MEDE900VW1, MEDX500XL0, MEDX500XW0, MEDX500XW1, MEDX550XW0, MEDX5SPAW0, MEDX5SPAW1, MEDX600XW0, MEDX600XW1, MEDX700AG0, MEDX700AG1, MEDX700XL0, MEDX700XL1, MEDX700XW0, MEDX700XW1, MEDZ400TQ1, MEDZ400TQ2, MEDZ600TB1, MEDZ600TB2, MEDZ600TE2, MEDZ600TK1, MEDZ600TK2, MEDZ600TW1, MEDZ600TW2, MEDZ600WR0, MGD3000BW0, MGD3000BW1, MGD3100DW0, MGD3100DW1, MGD3500FW0, MGD4000BW1, MGD4100DW0, MGD4200BG0, MGD4200BG1, MGD4200BW0, MGD4200BW1, MGD5100DC0, MGD5100DC1, MGD5100DW0, MGD5100DW1, MGD5500FC0, MGD5500FC1, MGD5500FW0, MGD5500FW1, MGD5630HC0, MGD5630HC1, MGD5630HC2, MGD5630HC3, MGD5630HW0, MGD5630HW1, MGD5630HW2, MGD5630HW3, MGD5900TW0, MGD5900TW1, MGD5920TW0, MGD5921TW0, MGD6000AG0, MGD6000AG1, MGD6000AW0, MGD6000AW1, MGD6000XG0, MGD6000XG1, MGD6000XG2, MGD6000XR0, MGD6000XR1, MGD6000XR2, MGD6000XW0, MGD6000XW1, MGD6000XW2, MGD6200KW0, MGD6200KW1, MGD6230HC0, MGD6230HC1, MGD6230HW0, MGD6230HW1, MGD6230RHW0, MGD6300TQ0, MGD6300TQ1, MGD6400TB0, MGD6400TQ0, MGD6600TQ0, MGD6600TQ1, MGD6630HC0, MGD6630HC1, MGD6630HC2, MGD6630HC3, MGD6630HW0, MGD6630HW1, MGD6630HW2, MGD6630HW3, MGD7000AG0,
MGD7000AG1, MGD7000AW0, MGD7000AW1, MGD7000XG0, MGD7000XG1, MGD7000XG2, MGD7000XR0, MGD7000XR1, MGD7000XW0, MGD7000XW1, MGD7000XW2, MGD7100DC0, MGD7100DC1, MGD7100DW0, MGD7100DW1, MGD7230HC0, MGD7230HC1, MGD7230HW0, MGD7230HW1, MGD8000AG0, MGD8000AG1, MGD8000AW0, MGD8000AW1, MGD8100DC0, MGD8100DC1, MGD8100DW0, MGD8100DW1, MGD8200FC0, MGD8200FC1, MGD8200FW0, MGD8200FW1, MGD8230HC0, MGD8630HC0, MGD8630HC1, MGD8630HC2, MGD8630HC3, MGD8630HW0, MGD8630HW1, MGD8630HW2, MGD8630HW3, MGD9000YG0, MGD9000YG1, MGD9000YG2, MGD9000YR0, MGD9000YR1, MGD9000YW0, MGD9000YW1, MGD9000YW2, MGD9600SQ0, MGD9700SB0, MGD9700SQ0, MGD9800TB0, MGD9800TK0, MGD9800TQ0, MGDB200VQ0, MGDB200VQ1, MGDB400VQ0, MGDB400VQ1, MGDB700BW0, MGDB700VQ0, MGDB725BW0, MGDB750YW0, MGDB750YW1, MGDB750YW2, MGDB750YW3, MGDB755DW0, MGDB755DW2, MGDB755DW3, MGDB765FC0, MGDB765FW0, MGDB766FW0, MGDB800VB0, MGDB800VQ0, MGDB800VU0, MGDB835DC3, MGDB835DC4, MGDB835DW0, MGDB835DW1, MGDB835DW2, MGDB835DW3, MGDB835DW4, MGDB850WB0, MGDB850WB1, MGDB850WL0, MGDB850WL1, MGDB850WQ0, MGDB850WQ1, MGDB850WR0, MGDB850WR1, MGDB850YG0, MGDB850YG1, MGDB850YG2, MGDB850YG3, MGDB850YW0, MGDB850YW1, MGDB850YW2, MGDB850YW3, MGDB855DC0, MGDB855DC3, MGDB855DC4, MGDB855DW0, MGDB855DW3, MGDB855DW4, MGDB880BW0, MGDB950YG0, MGDB950YG1, MGDB950YG2, MGDB950YG3, MGDB950YW0, MGDB950YW1, MGDB950YW2, MGDB950YW3, MGDB955FC0, MGDB955FW0, MGDB980BG0, MGDB980BW0, MGDE200XW0, MGDE200XW1, MGDE201YW0, MGDE201YW1, MGDE201YW2, MGDE250XL0, MGDE250XL1, MGDE251YG0, MGDE251YL0, MGDE300VF0, MGDE300VF1, MGDE300VF2, MGDE300VF3, MGDE300VW0, MGDE300VW1, MGDE300VW3, MGDE301YG0, MGDE301YW0, MGDE400XR0, MGDE400XR1, MGDE400XW0, MGDE400XW1, MGDE500VF0, MGDE500VF1, MGDE500VP0, MGDE500VP1, MGDE500VW0, MGDE500VW1, MGDE500VW2, MGDE500VW3, MGDE500WJ0, MGDE500WJ1, MGDE500WR0, MGDE500WR1, MGDE900VJ0, MGDE900VJ1, MGDE900VJ2, MGDE900VW0, MGDE900VW1, MGDE900VW2, MGDX500XL1, MGDX500XW1, MGDX500XW2, MGDX550XW0, MGDX550XW1, MGDX5SPAW0, MGDX600XL0, MGDX600XL1, MGDX600XW0, MGDX600XW1, MGDX600XW2, MGDX700AG0, MGDX700AG1, MGDX700XL0, MGDX700XL1, MGDX700XL2, MGDX700XW0, MGDX700XW1, MGDX700XW2, MGDZ400TQ1, MGDZ400TQ2, MGDZ600TB1, MGDZ600TB2, MGDZ600TE2, MGDZ600TK1, MGDZ600TK2, MGDZ600TW1, MGDZ600TW2, MGDZ600WR0, MLE20PDAGW0, MLE20PDAYW0, MLE20PDAZW0, MLE20PDBGW0, MLE20PDBGW1, MLE20PDBGW2, MLE20PDBYW0, MLE20PDBYW1, MLE20PDBYW2, MLE20PDBZW0, MLE20PDBZW1, MLE20PDBZW2, MLE20PDCGW0, MLE20PDCYW0, MLE20PDCZW0, MLE20PNAGW0, MLE20PNAGWO, MLE20PNBGW0, MLE20PNBGW1, MLE20PNBGW2, MLE20PNCGW0, MLE20PRAYW0, MLE20PRAZW0, MLE20PRBYW0, MLE20PRBYW1, MLE20PRBYW2, MLE20PRBZW0, MLE20PRBZW1, MLE20PRBZW2, MLE20PRCYW0, MLE20PRCZW0, MLE21PDAGW0, MLE21PNAGW0, MLE22PDAGW0, MLE22PDAYW0, MLE22PDAZW0, MLE22PNAGW0, MLE22PRAYW0, MLE22PRAZW0, MLG20PDAGW0, MLG20PDAWW0, MLG20PDBGW0, MLG20PDBGW1, MLG20PDBGW2, MLG20PDBGW3, MLG20PDBWW0, MLG20PDBWW2, MLG20PDCGW0, MLG20PDCWW0, MLG20PDCWW1, MLG20PRAWW0, MLG20PRBWW0, MLG20PRBWW2, MLG20PRCWW0, MLG20PRCWW1, MLG21PDAGW0, MLG22PDAGW0, MLG22PDAWW0, MLG22PNAGW0, MLG22PRAWW0, NED5800DW0, NED5800HW0, NED5800HW1, NED7300WW0, NED7300WW1, NED7500VM0, NED7500VM1, NED7500VW0, NED7500VW1, NGD5700BW0, NGD5800DW0, NGD5800DW1, NGD5800HW0, NGD5800HW1, NGD5800HW2, NGD7300WW0, NGD7300WW1, NGD7500VM1, NGD7500VW0, NGD7500VW1, SFF1000CLN0, SFF1000CSA0, SFF1001CLN0, SFF1001CSA0, SFF1002CLN0, SFF1002CSA0, WED5100HC0, WED5100HC1, WED5100HC2, WED5100HW0, WED5100HW1, WED5100HW2, WED5500BW0, WED5500XL0, WED5500XW0, WED5500XW1, WED5550XW0, WED5600XW0, WED5600XW1, WED560LHW0, WED560LHW1, WED560LHW2, WED5610XW0, WED5610XW1, WED5620HW0, WED5620HW1, WED5620HW2, WED5700AC0, WED5700AC1, WED5700XL0, WED5700XW0, WED5800BC0, WED5800BW0, WED5810BW0, WED5900SB0, WED5900SW0, WED6120HC0, WED6120HC1, WED6120HC2, WED6120HW0, WED6120HW1, WED6120HW2, WED6200SW0, WED6200SW1, WED6400SB0, WED6400SB1, WED6400SG0, WED6400SG1, WED6400SW0, WED6400SW1, WED6600VU0, WED6600VW0, WED6600WL0, WED6620HC0, WED6620HC1, WED6620HC2, WED6620HW0, WED6620HW1, WED6620HW2, WED7000DW0, WED7000DW1, WED7000DW2, WED70HEBW0, WED7120HC0, WED7120HC1, WED7120HW0, WED7120HW1, WED71HEBW0, WED71HEDW0, WED71HEDW1, WED72HEDW0, WED72HEDW1, WED7300DC1, WED7300DC2, WED7300DW0, WED7300DW1, WED7300DW2, WED7300XW0, WED7400XW0, WED7500GC0, WED7500GW0, WED7505FW0, WED7540FW0, WED7540FW1, WED7590FW0, WED7590FW1, WED75HEFW0, WED75HEFW1, WED7600XW0, WED7800XB0, WED7800XL0, WED7800XW0, WED7990FW0, WED7990XG0, WED8000BW0, WED8000DW0, WED8000DW1, WED8000DW2, WED8000DW3, WED8000DW4, WED80HEBC0, WED80HEBW0, WED8100BW0, WED8120HC0, WED8120HW0, WED8127LC0, WED8127LC1, WED8127LW0, WED8127LW1, WED81HEDW0, WED81HEDW1, WED8200YW0, WED8200YW1, WED8200YW2, WED8300SB0, WED8300SB1, WED8300SB2, WED8300SE2, WED8300SW0, WED8300SW1, WED8300SW2, WED8410SW0, WED8410SW1, WED8410SW2, WED8500BC0, WED8500BR0, WED8500BW0, WED8500DC0, WED8500DC1, WED8500DC2, WED8500DC3, WED8500DC4, WED8500DR0, WED8500DR1, WED8500DR2, WED8500DR3, WED8500DR4, WED8500DW0, WED8500DW1, WED8500DW2, WED8500DW3, WED8500DW4, WED8500SR0, WED8540FW0, WED8540FW1, WED8540FW2, WED85HEFC0, WED85HEFC1, WED85HEFC2, WED85HEFW0, WED85HEFW1, WED85HEFW2, WED8600YW0, WED8600YW1, WED8600YW2, WED8620HC0, WED8620HC1, WED8620HC2, WED8620HW0, WED8620HW1, WED8620HW2, WED86HEBC0, WED86HEBW0, WED8700EC0, WED8700EC2, WED8740DC0, WED8740DC1, WED8740DW0, WED8740DW1, WED87HEDC0, WED87HEDC1, WED87HEDW0, WED87HEDW1, WED8800YC0, WED8800YC1, WED8800YC2, WED8800YW0, WED8800YW1, WED8800YW2, WED88HEAC0, WED88HEAC1, WED88HEAW0, WED88HEAW1, WED8900BC0, WED8900BW0, WED9050XW0, WED9050XW1, WED9051YW0, WED9051YW1, WED90HEFC0, WED90HEFC1, WED90HEFC2, WED90HEFW0, WED90HEFW1, WED90HEFW2, WED9150WW0, WED9150WW1, WED9151YW0, WED9151YW1, WED9200SQ0, WED9200SQ1, WED9200SQ2, WED9250WL0, WED9250WL1, WED9250WR0, WED9250WR1, WED9250WW0, WED9250WW1, WED9270XL0, WED9270XL1, WED9270XL2, WED9270XR0, WED9270XR1, WED9270XR2, WED9270XW0, WED9270XW1, WED9270XW2, WED9290FC0, WED9290FW0, WED92HEFBD0, WED92HEFBD1, WED92HEFBD2, WED92HEFC0, WED92HEFC1, WED92HEFC2, WED92HEFU0, WED92HEFU1, WED92HEFU2, WED92HEFW0, WED92HEFW1, WED92HEFW2, WED9300VU0, WED9300VU1, WED9371YL0, WED9371YW0, WED9371YW1, WED9400SB0, WED9400SB1, WED9400ST0, WED9400ST1, WED9400SU0, WED9400SU1, WED9400SU2, WED9400SW0, WED9400SW1, WED9400SW2, WED9400SZ0, WED9400SZ1, WED9400SZ2, WED9400VE0, WED9400VE1, WED9450WL0, WED9450WL1, WED9450WR0, WED9450WR1, WED9450WW0, WED9450WW1, WED9470WL1, WED9470WR1, WED9470WW1, WED9470WW2, WED94HEAC0, WED94HEAC1, WED94HEAW0, WED94HEAW1, WED94HEXL0, WED94HEXL1, WED94HEXL2, WED94HEXR0, WED94HEXR1, WED94HEXR2, WED94HEXW0, WED94HEXW1, WED94HEXW2, WED9500EC0, WED9500EW0, WED9500TC0, WED9500TC1, WED9500TC2, WED9500TU0, WED9500TU1, WED9500TW0, WED9500TW1, WED9500TW2, WED9500TW3, WED9550WL0, WED9550WL1, WED9550WL2, WED9550WR0, WED9550WR1, WED9550WW0, WED9550WW1, WED9550WW2, WED95HEDC0, WED95HEDC1, WED95HEDU0, WED95HEDU1, WED95HEDW0, WED95HEDW1, WED95HEXL0, WED95HEXL1, WED95HEXL2, WED95HEXR0, WED95HEXR1, WED95HEXW0, WED95HEXW1, WED95HEXW2, WED9600SU0, WED9600TA0, WED9600TA1, WED9600TA2, WED9600TB0, WED9600TB1, WED9600TU0, WED9600TU1, WED9600TW0, WED9600TW1, WED9600TW2, WED9600TZ0, WED9610XW0, WED9610XW1, WED9620HBK0, WED9620HBK1, WED9620HBK2, WED9620HC0, WED9620HC1, WED9620HC2, WED9620HW0, WED9620HW1, WED9620HW2, WED96HEAC0, WED96HEAC1, WED96HEAU0, WED96HEAU1, WED96HEAW0, WED96HEAW1, WED96HEYW0, WED9750WL0, WED9750WL1, WED9750WR0, WED9750WW0, WED9750WW1, WED97HEDBD0, WED97HEDBD1, WED97HEDC0, WED97HEDC1, WED97HEDU0, WED97HEDU1, WED97HEDW0, WED97HEDW1, WED97HEXL0, WED97HEXL1, WED97HEXL2, WED97HEXL3, WED97HEXL4, WED97HEXR0, WED97HEXR1, WED97HEXR2, WED97HEXW0, WED97HEXW1, WED97HEXW2, WED97HEXW3, WED97HEXW4, WED99HEDC0, WED99HEDW0, WEL98HEBU0, WGD5100HC0, WGD5100HC1, WGD5100HW0, WGD5100HW1, WGD5500BW0, WGD5500XL0, WGD5500XL1, WGD5500XW0, WGD5500XW1, WGD5500XW2, WGD5550XW0, WGD5550XW1, WGD5600XW0, WGD5600XW1, WGD5600XW2, WGD560LHW0, WGD560LHW1, WGD560LHW2, WGD560LHW3, WGD5610XW0, WGD5610XW1, WGD5610XW2, WGD5620HW0, WGD5620HW1, WGD5620HW3, WGD5700AC0, WGD5700AC1, WGD5700XL0, WGD5700XL1, WGD5700XW0, WGD5700XW1, WGD5800BC0, WGD5800BW0, WGD5810BW0, WGD5900SB0, WGD5900SW0, WGD6120HC0, WGD6120HC1, WGD6120HW0, WGD6120HW1, WGD6200SW0, WGD6200SW1, WGD6200SW2, WGD6400SB0, WGD6400SB1, WGD6400SB2, WGD6400SG0, WGD6400SG1, WGD6400SG2, WGD6400SW0, WGD6400SW1, WGD6400SW2, WGD6600VU0, WGD6600VU1, WGD6600VW0, WGD6600VW1, WGD6600WL0, WGD6620HC0, WGD6620HC1, WGD6620HC2, WGD6620HC3, WGD6620HW0, WGD6620HW1, WGD6620HW2, WGD6620HW3, WGD7000DW0, WGD7000DW1, WGD7000DW2, WGD7000DW3, WGD70HEBW0, WGD70HEBW1, WGD7120HC0, WGD7120HC1, WGD7120HW0, WGD7120HW1, WGD71HEBW0, WGD71HEDW0, WGD72HEDW0, WGD72HEDW1, WGD7300DC2, WGD7300DW0, WGD7300DW1, WGD7300DW2, WGD7300DW3, WGD7300XW0, WGD7400XW0, WGD7500GC0, WGD7500GW0, WGD7505FW0, WGD7540FW0, WGD7590FW0, WGD75HEFW0, WGD7600XW0, WGD7600XW1, WGD7800XB0, WGD7800XL0, WGD7800XW0, WGD7990XG0, WGD8000BW0, WGD8000DW0, WGD8000DW1, WGD8000DW2, WGD8000DW3

CRITICAL SAFETY WARNING: This repair involves working with electrical components in a dryer. Always unplug the dryer before beginning work to prevent electrical shock. For gas dryers, turn off the gas supply at the shutoff valve before beginning work. If uncomfortable with this repair, hire a qualified technician.TOOLS REQUIRED: Phillips screwdriver, flathead screwdriver, putty knife (for some models), 1/4-inch nut driver or socket (optional), flashlight, multimeter for testing (optional).

1. Unplug the dryer from the electrical outlet to ensure complete power disconnection.
2. For gas dryers: Turn off the gas supply at the shutoff valve behind the dryer (turn valve perpendicular to gas line to close).
3. Move the dryer away from the wall to provide working space and access to the rear or top panel.
4. Disconnect the dryer vent hose from the rear of the dryer by loosening the clamp with a screwdriver or pliers.
5. Take multiple photos of the thermistor location, mounting position, and wire connections before removal. This is helpful for proper reinstallation.
6. Determine access method for your model: Most dryers require removing the top panel or rear panel to access the blower housing where the thermistor is located. Consult your service manual if unsure.
7. For TOP PANEL ACCESS (most common): Remove the lint filter from the lint trap. Insert a putty knife between the top and front panel near the corners (approximately 3 inches from each side), push up to release the spring clips, and lift the top panel up and back. Some models have screws at the rear—remove if present.
8. For REAR PANEL ACCESS: Remove the screws around the perimeter of the rear panel (typically 8-12 screws) and remove the panel.
9. Locate the thermistor on the blower housing (typically mounted near the thermal fuse on the side or top of the blower housing, small component with two wire terminals).
10. Take detailed close-up photos of the thermistor mounting position and wire connections from multiple angles.
11. Disconnect the wire terminals from the thermistor by pulling the spade connectors straight off the terminals. Do not pull on wires—grip the connectors. Important: Note which wire connects to which terminal (though thermistors are typically non-polar, maintaining original orientation is good practice).
12. Remove the thermistor mounting screw or clip (typically one Phillips screw or a metal clip) that secures the thermistor to the blower housing.
13. Remove the old thermistor from the blower housing and set aside.
14. Inspect the old thermistor for visible damage: burned or discolored housing, corroded terminals, cracked housing, or damaged wires. This confirms the diagnosis.
15. Test the old thermistor with a multimeter (optional) set to measure resistance (ohms). Touch probes to the two terminals. At room temperature (70°F/21°C), the thermistor should read approximately 11.9K ohms (11,900 ohms). At 77°F/25°C, should read approximately 10K ohms (10,000 ohms). Infinite reading = open circuit (failed thermistor). Very low reading (under 1K ohms) = shorted thermistor or bias resistor failure. Note: Resistance decreases as temperature increases (NTC behavior).
16. Clean the thermistor mounting area on the blower housing, removing any lint, dust, or debris that could affect heat transfer to the new thermistor.
17. Inspect the wire connectors for damage, corrosion, or burned terminals. Clean with electrical contact cleaner or replace if damaged.
18. Unpack the new WP8577274 thermistor from its packaging. Caution: Handle carefully—thermistor element is sensitive to physical shock.
19. Compare the new thermistor to the old one to verify dimensions, terminal configuration, mounting hole position, and part number match.
20. Inspect the new thermistor for any shipping damage before installation.
21. Test the new thermistor with a multimeter (optional)—should read approximately 11.9K ohms at room temperature (70°F/21°C). This verifies the thermistor is good before installation.
22. Position the new thermistor on the blower housing, aligning the mounting hole with the screw hole in the housing. Important: Ensure the thermistor body is in good contact with the blower housing for accurate temperature sensing—some models have a specific orientation or contact surface.
23. Install the thermistor mounting screw or clip and tighten firmly but not excessively. Important: Do not overtighten—plastic housing can crack. Hand-tight plus 1/8 turn is sufficient.
24. Verify the thermistor is securely mounted with no movement or play, and the body is in good contact with the blower housing.
25. Reconnect the wire terminals to the thermistor by pushing the spade connectors firmly onto the terminals until fully seated. Important: Ensure connectors are fully pushed on—partial connections cause intermittent operation or false readings.
26. Verify both wire connections are secure by gently tugging on each connector—should not pull off.
27. Double-check all connections against your detailed photos to ensure correct installation.
28. For TOP PANEL ACCESS: Reinstall the top panel by positioning it over the cabinet, engaging the rear hinges, and pushing down firmly at the front corners until the spring clips engage with clicking sounds. Reinstall the lint filter.
29. For REAR PANEL ACCESS: Reinstall the rear panel by positioning it and installing the mounting screws around the perimeter. Tighten firmly.
30. Reconnect the dryer vent hose to the rear of the dryer and secure with the clamp. Ensure the connection is tight with no gaps.
31. Move the dryer back to its installation location.
32. For gas dryers: Turn on the gas supply by turning the shutoff valve parallel to the gas line. Check for gas leaks at all connections using soapy water—bubbles indicate leaks.
33. Restore electrical power by plugging in the dryer.
34. Run a test cycle (timed dry, medium heat, 15-20 minutes) with a small load of damp towels to verify proper operation.
35. Monitor the dryer operation: Should heat normally, cycle should complete in expected time, dryer should not overheat or shut off prematurely.
36. Test automatic cycles (if equipped) to verify moisture sensing works properly—cycle should end when clothes are dry, not too early or too late.
37. Check for error codes on the display panel. No error codes should appear if the thermistor is installed correctly and functioning properly.
38. Feel the exhaust air during the cycle—should be warm to hot (120-160°F) but not excessively hot (over 180°F indicates possible overheating).
39. Run a second test cycle (automatic sensor dry, normal setting) with a full load of damp towels to verify the dryer accurately senses moisture and ends the cycle at the proper time.
40. Verify clothes are properly dried at the end of the automatic cycle—should be dry but not over-dried or scorched.
41. If the dryer operates properly with accurate temperature control, proper cycle timing, and no error codes, the repair is complete.

Safety Notes: Always unplug the dryer and turn off gas supply before working on electrical components. Handle the thermistor carefully—element is sensitive to physical shock. Do not overtighten mounting screw—plastic housing can crack. Ensure wire connectors are fully seated on terminals. Test operation thoroughly with both timed and automatic cycles. This repair requires basic mechanical and electrical skills and typically takes 30-45 minutes for DIY.

1. Test old thermistor for resistance (typically 10–50kΩ at room temp; check service manual).
2. Inspect wiring and connectors for corrosion—replace if needed.
3. If error persists after replacement, check control board and heating element.
4. Document installation for warranty and troubleshooting.
5. Use only OEM thermistors—aftermarket may not match resistance curve.
6. Keep spare thermistors in stock for high-turnover properties.
7. Clean lint from exhaust duct and blower for accurate temperature sensing.
8. Test dryer with a full load to confirm repair.
9. If sensor fails repeatedly, check for vent restrictions or airflow problems.
10. Replace mounting screw(s) if corroded for secure installation.
11. Handle sensor leads carefully—avoid kinking or bending.
