Whirlpool Range Oven bake element WPW10308477

Whirlpool genuine OEM electric oven bake element installed at the bottom of the oven to supply baking heat. It uses push-on wire terminals.

Is This the Right Part?

Common Symptoms

• Bake element will not heat
• Little or no heat during baking
• Uneven oven heating
• Visible holes, blisters, burning, or breakage in the element

Check Before Replacing

• With power disconnected, visually inspect the element for holes, blisters, burning, or breaks.
• If appropriate for the appliance and service procedure, test the element for electrical continuity with a multimeter after disconnecting power.
• Confirm that the element is mounted at the bottom of the oven and uses push-on terminals before ordering.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM part
• Electric range oven bake element
• Bottom-mounted oven element
• Push-on wire terminals
• Approximately 2400 watts
• Approximately 20 7/8 inches wide by 15 1/2 inches long; approximately 2 5/8-inch terminal inserts

Installation Notes

• Disconnect power to the range at the plug or circuit breaker before servicing.
• Remove the old element and transfer the wires to the replacement element without allowing the wires to fall behind the oven liner.
• Ensure the replacement element sits flat and is securely fastened before restoring power.

Verified Compatible Models

4KAER5500AW0, 4KMER7600AW0, 4KMER7600AW1, 4KWFC120MAW0, 4KWFC120MAW1, 4RF302BXEQ1, 4RF302BXGQ0, 4RF302BXGQ1, 4RF302BXKQ0, 4RF302BXKQ1, 4RF315PXEQ0, 4RF315PXGQ0, 4RF315PXKQ0, 4RF315PXMQ0, 66592153300, FEP310KV2, FEP310KW2, GR470LXMB0, GR470LXMC0, GR470LXMP0, GR475LXMS0, IER310RW0, IES366RS0, KERI201PBL0, KERI201PBS0, KERI201PWH0, RF196LXMB1, RF196LXMB2, RF196LXMQ1, RF196LXMQ2, YACR3230BCW0, RF110AXST1, RF199LXKT0, RF199LXKT1, RF262LXSB0, RF262LXSQ0, RF262LXST0, RF262LXSW0, RF264LXSB0, RF264LXSQ0, RF264LXST0, RF324PXEW1, RF368LXPS2, RF385PXGN1, RF396LXEB1, YMER7651WS1

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
