Whirlpool Refrigerator Damper Control Assembly WPW10479155, Replaces W10479155

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Refrigerator compartment warm while the freezer remains cold
• Food freezing in the refrigerator compartment
• Temperature fluctuations in the fresh-food section
• Refrigerator running frequently or continuously
• Clicking, buzzing, or other abnormal noise from the damper actuator

Check Before Replacing

• Confirm the freezer is producing cold air before attributing a fresh-food temperature problem to the damper.
• Visually inspect the damper area for a door that is stuck open or closed, without forcing the mechanism.
• Listen for abnormal actuator noise during normal cooling operation.
• Check for visible damage to the damper housing, wiring connector, or included thermistor.
• Verify the refrigerator is unplugged before inspecting or handling the assembly.

Pro Tip

Part Details

Installation Notes

• Disconnect electrical power before beginning service.
• Access procedures vary by refrigerator model; follow the model-specific service information.
• The assembly may be retained by tabs and a cover, and its wiring connector must be disconnected before removal.
• If the included thermistor or sensor is present, route and retain it in the same position as the original assembly.
• Do not force the damper door or retaining tabs; confirm the replacement part number and model fit before installation.

Verified Compatible Models

IX7DDEXDSM01, KRFF507HBL00, KRFF507HPS03, KRFF507HPS04, WRF736SDAB00, WRF736SDAB13, WRF736SDAF00, WRF736SDAM00, WRF736SDAM13, WRF736SDAT00, WRF736SDAT10, WRF736SDAW00, WRF757SDHV02, WRF757SDHV04, WRF757SDHZ01, WRF736SDAM11, WRF736SDAM12, WRF736SDAM14, 7WF736SDAM13

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
