GE Refrigerator Cold Water Tank WR03F04477 — U.S. Cross-Reference WR17X25212
WR03F04477 Refrigerator Cold Water Tank (replaces WR17X25212)
GE Refrigerator Cold Water Tank WR03F04477 — U.S. Cross-Reference WR17X25212
WR03F04477 Refrigerator Cold Water Tank (replaces WR17X25212)

GE Refrigerator Cold Water Tank WR03F04477 — U.S. Cross-Reference WR17X25212

Sale price
$54.95
Regular price
$59.90
You save
$4.95 (8%)
Buying Options: OEM

Product variant with selected options does not exist!

Frequently Bought Together

Confirm This Fits Your Model
Not sure where to find your model number? See guide →
OEM REPLACEMENT PART

GE Refrigerator Cold Water Tank WR03F04477 — Fixes Reservoir Leaks / Restores Chilled-Water Storage

Part# WR03F04477 🇺🇸 U.S. Equivalent: WR17X25212 Fits GE Fits GE Profile Fits GE Café

GE Refrigerator Cold Water Tank WR03F04477 — Fixes Reservoir Leaks / Restores Chilled-Water Storage

Canadian GE/Mabe Part Number: WR03F04477
🇺🇸 Matching U.S. Part Number: WR17X25212
GE/Mabe Production Reference: 238C5224G002

WR03F04477 is a genuine GE/Mabe refrigerator cold-water tank assembly. The matching U.S. GE service number is WR17X25212, and the associated production reference is 238C5224G002.

The reservoir stores water inside the refrigerated compartment before it reaches the dispenser. Water is chilled by the refrigerator compartment surrounding the reservoir; the tank does not contain an active cooling system.

A damaged reservoir may contribute to water leaking inside the refrigerator, restricted dispenser flow or insufficient stored water at refrigerator temperature.

Similar symptoms can also result from damaged tubing, loose connectors, a clogged water filter, frozen water lines, low household water pressure or a defective inlet or isolation valve.

Confirm the complete refrigerator model and tubing arrangement before ordering. Shut off the refrigerator's water supply and disconnect electrical power before service.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

  • ✔ Refrigerator powers on and runs normally
  • ✔ Ice maker and other functions work correctly
  • ✔ Water supply line, filter, and inlet valve confirmed OK
  • ✔ ONLY problem is water leaking from reservoir area or no stored water reaching the dispenser

Not sure? Send us your model number — we'll confirm before you order.

🔧 Common Symptoms

  • Water pooling or leaking inside the refrigerator compartment
  • No water or reduced flow from door dispenser
  • Dispenser water not reaching refrigerator temperature
  • Visible crack or damage to the reservoir body

✔ If these symptoms match and the water supply system has been ruled out, this reservoir is the most likely failed component.

✔ Replacing this tank restores chilled-water storage when the complete water system is functioning correctly.

📦 Part Details

  • Canadian Part Number: WR03F04477
  • U.S. Equivalent: WR17X25212 (active GE U.S. service part — not discontinued)
  • Production Reference: 238C5224G002
  • Type: Refrigerator cold-water tank / coiled reservoir assembly
  • Manufacturer: GE Appliances / Mabe
  • Brands: GE, GE Profile, GE Café
⚠️ Recommended While Repairing:
Inspect the door water lines and tubing connectors while the panel is open — cracked tubing or loose connectors are a common secondary cause of leaks and restricted flow. Replacing them at the same time prevents a repeat service call.

⚙️ Installation

Skill Level: MODERATE — 30–60 minutes. Shut off the refrigerator's water supply and disconnect electrical power before service. Remove the refrigerator door panel to access the reservoir, disconnect the water lines, swap the tank, and reassemble. Flush the new tank with 2–3 glasses of water before use.

✓ Compatible Models

Independently verified compatible models: GNE25JMKBFES, GNE27JMMAFES, GWE19JSLNFSS. Additional GE, GE Profile, and GE Café models in the GNE, GWE, CWE, QNE, and XNE series may be compatible. Contact us to verify your model number before ordering.

💡 Pro Tip

Diagnose the Full Water System First:
Before ordering, confirm the water filter is current, the inlet valve opens fully, and no lines are frozen. A reservoir replacement will not correct low flow or warm water caused by a clogged filter, failed valve, or frozen line — ruling these out first saves a return trip.

✅Compatibility & Cross Reference

CNE25SSKAKSS, CWE19SP2NBS1, CWE19SP2NKS1, CWE19SP2NLS1, CWE19SP2NNS1, CWE19SP2NTS1, CWE19SP2NWS1, CWE19SP2NWS1, CWE19SP2TNS1, CWE19SP3NBD1, CWE19SP3NKD1, CWE19SP3NND1, CWE19SP3NTD1, CWE19SP3NWD1, CWE19SP3NWD1, CWE19SP3TND1, CWE19SP3TND1, CWE19SP4NBW2, CWE19SP4NKW2, CWE19SP4NNW2, CWE19SP4NTW2, CWE19SP4NTW2, CWE19SP4NWW2, CWE19SP4TNW2, GNE25JGKAFBB, GNE25JGKAFWW, GNE25JGKBFBB, GNE25JGKBFWW, GNE25JGKCFBB, GNE25JGKCFWW, GNE25JGKFFWW, GNE25JGKGFBB, GNE25JGKGFWW, GNE25JGKJFBB, GNE25JGKJFWW, GNE25JGKKFBB, GNE25JGKKFWW, GNE25JGKLFBB, GNE25JGKLFWW, GNE25JGKNFBB, GNE25JGKNFWW, GNE25JGKTFBB, GNE25JGKTFWW, GNE25JGKTFWW, GNE25JGKWFBB, GNE25JGKWFWW, GNE25JGKXFBB, GNE25JGKXFWW, GNE25JGKYFBB, GNE25JGKYFWW, GNE25JMKAFES, GNE25JMKBFES, GNE25JMKCFES, GNE25JMKFFES, GNE25JMKGFES, GNE25JMKJFES, GNE25JMKKFES, GNE25JMKLFES, GNE25JMKNFES, GNE25JMKPFES, GNE25JMKPFES, GNE25JMKTFES, GNE25JMKTFES, GNE25JMKWFES, GNE25JMKXFES, GNE25JMKXFES, GNE25JMKYFES, GNE25JSKAFSS, GNE25JSKBFSS, GNE25JSKCFSS, GNE25JSKDFSS, GNE25JSKFFSS, GNE25JSKGFSS, GNE25JSKJFSS, GNE25JSKKFSS, GNE25JSKLFSS, GNE25JSKNFSS, GNE25JSKPFSS, GNE25JYKBFFS, GNE25JYKEFFS, GNE25JYKEFFS, GNE25JYKFFFS, GNE25JYKGFFS, GNE25JYKHFFS, GNE27JGMAFBB, GNE27JGMAFWW, GNE27JGMKFWW, GNE27JGMNFBB, GNE27JGMNFWW, GNE27JGMTFBB, GNE27JGMTFWW, GNE27JGMWFBB, GNE27JGMWFBB, GNE27JGMWFWW, GNE27JGMWFWW, GNE27JGMXFBB, GNE27JGMXFWW, GNE27JMMAFES, GNE27JMMKFES, GNE27JMMNFES, GNE27JMMPFES, GNE27JMMTFES, GNE27JMMTFES, GNE27JMMWFES, GNE27JMMWFES, GNE27JSMAFSS, GNE27JSMDFSS, GNE27JSMKFSS, GNE27JSMNFSS, GNE27JSMNFSS, GNE27JYMKFFS, GNE27JYMNFFS, GNE27JYMTFFS, GNE27JYMTFFS, GNE27JYMWFFS, GNE27JYMWFFS, GWE19JGLGFBB, GWE19JGLGFWW, GWE19JGLKFBB, GWE19JGLKFWW, GWE19JGLNFWW, GWE19JGLTFBB, GWE19JGLTFBB, GWE19JGLTFWW, GWE19JGLTFWW, GWE19JGLWFBB, GWE19JGLWFWW, GWE19JGLWFWW, GWE19JGLXFBB, GWE19JGLXFWW, GWE19JMLGFES, GWE19JMLKFES, GWE19JMLNFES, GWE19JMLPFES, GWE19JMLTFES, GWE19JMLWFES, GWE19JMLXFES, GWE19JSLAFSS, GWE19JSLDFSS, GWE19JSLGFSS, GWE19JSLKFSS, GWE19JSLNFSS, GWE19JYLBFFS, GWE19JYLEFFS, GWE19JYLFFFS, GWE19JYLGFFS, QNE27JBMAFTS, QNE27JBMKFTS, QNE27JBMLFTS, QNE27JBMNFTS, QNE27JBMWFTS, QNE27JBMWFTS, QNE27JSMAFSS, QNE27JSMKFSS, QNE27JSMLFSS, QNE27JSMNFSS, QNE27JYMKFFS, QNE27JYMNFFS, QNE27JYMWFFS, QNE27JYMWFFS, QNE27JYMXFFS, XNE25JGKBFBB, XNE25JGKBFWW, XNE25JGKJFBB, XNE25JGKJFWW, XNE25JGKLFBB, XNE25JGKLFWW, XNE25JGKNFBB, XNE25JGKNFWW, XNE25JGKWFBB, XNE25JGKWFWW, XNE25JGKXFBB, XNE25JGKXFWW, XNE25JGKYFBB, XNE25JGKYFWW, XNE25JSKBFSS, XNE25JSKJFSS, XNE25JSKLFSS, XNE25JSKNFSS, XNE25JSKPFSS, XNE25JSKWFSS, XNE25JSKXFSS, XNE25JSKYFSS

Regional Cross-Reference

  • Canadian GE/Mabe Part Number: WR03F04477
  • Matching U.S. GE Part Number: WR17X25212

WR17X25212 is the verified matching U.S. GE service number. WR03F04477 is the Canadian/Mabe-format service number. These are regional equivalents, not a supersession chain.

GE/Mabe Production Reference: 238C5224G002 (engineering/production number — not a retail service part number)

Verified Compatible Models

  • GNE25JMKBFES
  • GNE27JMMAFES
  • GWE19JSLNFSS

3 models independently verified through two sources. Confirm your complete model number and tubing arrangement before ordering.

Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
