The WS01A03219 is the OEM GE Café range main cooktop glass assembly that forms the top surface of the induction or electric smoothtop range. This tempered glass panel sits over the heating elements and provides the cooking surface. When the glass cracks, chips, or shatters — from thermal shock, impact, or normal wear — the cooktop becomes unsafe to use and must be replaced. The WS01A03219 is the current OEM replacement, superseding WS01L16343, WS01L17346, and 295D4478G001. It is a direct-fit replacement for GE Café CCHS900 and CCHS950 series ranges.

✓ Model-Specific Repair Pages

Don't see your model? Contact us and we'll confirm compatibility. This glass fits all 21 CCHS900 and CCHS950 series GE Café ranges.

The WS01A03219 cooktop glass assembly is manufactured from tempered glass to GE factory specifications. It is the complete top glass panel that sits over the induction or radiant heating elements. The glass supersedes WS01L16343, WS01L17346, and 295D4478G001 — if any of those numbers appear on your parts diagram, WS01A03219 is the correct current replacement. Due to the size and fragility of this part, it ships with protective packaging.

✓ Common Symptoms Fixed

Replacing the WS01A03219 cooktop glass assembly typically resolves the following issues:

• Cracked, chipped, or shattered cooktop glass surface
• Cooktop unsafe to use due to glass damage
• Visible cracks spreading across the cooking surface
• Glass surface scratched or etched beyond cosmetic repair
• Cooktop elements visible through broken glass

✓ Key Features & Specifications

• OEM GE part number: WS01A03219
• Supersedes: WS01L16343, WS01L17346, 295D4478G001
• Material: Tempered glass
• Complete cooktop glass panel — full surface replacement
• Fits GE Café CCHS900 and CCHS950 series ranges (21 models)
• Ships with protective packaging due to size and fragility

✓ Buying Options

OEM (WS01A03219): The genuine GE Café range cooktop glass assembly. Factory-tempered glass with exact dimensions and cutouts for the original heating element layout and control markings.

✓ Replacement Part Numbers

WS01A03219 replaces the following part numbers:

• WS01L16343
• WS01L17346
• 295D4478G001

✓ Installation Tips

• Disconnect power to the range at the breaker before beginning — do not rely on the range power switch alone.
• Allow the cooktop to cool completely before handling the glass.
• Have a second person assist — the glass panel is large, heavy, and fragile.
• Remove the existing glass by lifting it free from the cooktop frame after removing any retaining clips or screws around the perimeter.
• Clean the cooktop frame and element area before installing the new glass.
• Lower the new WS01A03219 glass carefully into position, ensuring all element cutouts align correctly.
• Reinstall any retaining clips or screws, restore power, and test each cooking zone.
