GE Range 12" Dual Radiant Surface Element Won't Heat – Fix Cooktop Fast

The WS01F01164 is the OEM 12" dual-zone radiant surface element for compatible GE smooth-top electric ranges. In most GE appliances, a failed surface element is the direct cause of a burner that won't heat, only heats on one ring, or produces uneven heat across the cooking zone. When it fails, one or both heating circuits open — leaving you with a partially or completely dead burner. ⚡ Don't let a dead burner shut down your kitchen. Part WS01F01164 is the genuine OEM replacement that restores full dual-zone heating immediately — no modification required.

❓ Is This the Right Part?

This is the correct fix if ALL of the following are true:

• ✔ You have a GE, Hotpoint, or Mabe smooth-top electric range
• ✔ The affected burner is the 12" large dual-zone element
• ✔ The infinite switch and relay board have been ruled out (or not yet tested)
• ✔ Your model number is listed in the supported models (check door frame label)
• ✔ ONLY problem is the surface element not heating — one or both rings

🔧 Common Symptoms

• Surface burner won't heat at all
• Only inner or outer ring heats (dual element partial failure)
• Weak heat / slow boiling on the large burner
• Uneven heating / hot spots on the cooking zone
• Intermittent heating from heat-damaged terminals or receptacle
• Arcing or burning smell under cooktop (terminal overheating)

✔ If these symptoms match, this is the most likely failed component in the system.

✔ In most cases, replacing this surface element restores normal operation immediately.

📦 Part Details

• Part Number: WS01F01164
• Type: 12" Dual Radiant (Dual-Zone) Surface Element
• Wattage: 1050W / 1950W / 3000W (inner / outer / combined)
• Replaces: WB30T10130, WB44M00937, WG02F04089, WS01F06241, 191D4988P003R10 — no modification required
• Brands: GE, Hotpoint, Mabe, select Kenmore (verify by model)

⚙️ Installation Notes

Skill Level: Advanced — 45–75 minutes. Always kill power at the 240V breaker before servicing — never rely on the range switch alone. Remove the cooktop or range top panel, carefully lift the ceramic glass, disconnect element terminals, remove mounting clips, install the new element, reconnect terminals, reseat glass, reassemble, restore power and test both rings. Glass cooktops are fragile — handle with care and photograph connectors before removal.

💡 Pro Tip

📋 Replacement Part Numbers

• WS01F01164 — current OEM (this part)
• WB30T10130 — superseded, direct cross-reference
• WB44M00937 — superseded, direct cross-reference
• WG02F04089 — superseded, direct cross-reference
• WS01F06241 — superseded, direct cross-reference
• 191D4988P003R10 — superseded, direct cross-reference

✅ Buying Options

OEM: Genuine GE replacement — exact factory specifications and fit.

XPart: Premium aftermarket — same fit and function, backed by XPart Supply's guarantee. Aftermarket replacement parts are not affiliated with, sponsored by, or endorsed by GE or any OEM manufacturer.

⚠️ Important — Additional Part Required

If your model number is JCB840EK2ES or JCB840EK3ES, you will also need to replace the wiring harness. Order wiring harness WS01F09725 separately in addition to this element.

❓ Frequently Asked Questions

JCB850SF4SS, JCB850SF1SS, PEB159CSN1SS, PB911SJ1SS, GDWF800V00WW, GDWF700V02WW, CCS975SD2SS, CCS975SD1SS, CBC980ST7SS, CBC980ST6SS, CBC980ST5SS, JCSP42DR3WW, CHP9530SJ2SS, JCB865SJ1SS, JCGBS60DEF1WW, JCTP30BM1BB
