Whirlpool Dryer 8557403 – Superseded by WP8557403

Whirlpool dryer high-limit thermostat and inlet thermistor assembly mounted on the heating-element housing.

Is This the Right Part?

Common Symptoms

• No heat when the high-limit thermostat is open or defective
• Overheating or incorrect temperature control when the inlet thermistor gives an incorrect temperature signal

Check Before Replacing

• Disconnect power before servicing and inspect the assembly and wiring for visible damage.
• Test the thermostat for continuity with the dryer disconnected from power; an open reading when the thermostat should be closed can indicate a fault.
• Measure thermistor resistance at room temperature; one established parts reference specifies approximately 50–60 kΩ.

Pro Tip

Part Details

Key Features

• High-limit thermostat and inlet thermistor combined assembly
• Thermostat rating identified by a parts reference as L295-80F
• Thermistor room-temperature resistance reference of approximately 50–60 kΩ

Installation Notes

• Disconnect electrical power before accessing or replacing the assembly.
• The assembly is mounted on or associated with the dryer heating-element housing; confirm the model-specific parts diagram before removal.

Verified Compatible Models

7MWED6613HW1, 110.87081601, 110.87729700, 11061652021, MED4200BW0, MED7230HC0, MED7230HW0, MED8230HC0, MED8630HC1, MED9000YW0, MEDB400VQ0, MEDB400VQ1, MEDB700BW0, MEDB835DW3, MEDB880BW0, WED70HEBW0, WED75HEFW1, WED85HEFC0, WED85HEFC2, WED85HEFW0, WED85HEFW1, WED92HEFBD0, WED92HEFC0, WED92HEFC1, WED92HEFC2, WED92HEFU0, WED92HEFW0, WED92HEFW1, WED92HEFW2, WED96HEAU1, WED560LHW1, WED5620HW1, WED5720RU0, WED5720RW0, WED6620HC1, WED6620HW1, WED6720RU0, WED7120HC1, WED7120HW0, WED7590FW0, WED7590FW1, WED8000DW0, WED8000DW1, WED8000DW2, WED8000DW3, WED8000DW4, WED8120HC0, WED8120HW0, WED8127LC1, WED8500DC0, WED8500DC1, WED8500DC2, WED8500DC3, WED8500DC4, WED8500DW4, WED8620HC1, WED8620HW1, WED8700EC0, WED8700EC2, WED8800YW0, WED9620HBK1, WED9620HW1, YMED8630HW0, YMEDB750YW2, YMEDB835DW4, YMEDB855DC3, YNED5800DW0, YWED72HEDW0, YWED85HEFC2, YWED85HEFW1, YWED85HEFW2, YWED560LHW1, YWED5620HW2, YWED5720RW0, YWED6620HW1, YWED6720RU0, YWED6720RW0, YWED7120HC0, YWED7120HC3, YWED8620HC1, YWED8620HC2, YWED9620HC1, YWED9620HW1, WED6720RW0, WED7000DW0, WED7000DW1, WED7000DW2, WED7120HC2, WED7120HC3, WED7120HW2, WED7120HW3, WED71HEBW0, WED71HEDW0, WED71HEDW1, WED72HEDW1, WED7300DC1, WED7300DC2

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
