WATER LEAKING FROM THE DISHWASHER DOOR AREA
Bosch Dishwasher door seal sealing 00645141, Fixes Water leaking from the dishwasher door area
Genuine Bosch door seal, approximately 1.75 m 69 inches long, installed around the dishwasher tub opening to seal the gap between the tub and door and prevent water leakage.
Part 00645141Replaces 645141Bosch
Confirm your full appliance model number before ordering.
Is This the Right Part?
Part Number00645141
🇺🇸 Matching U.S. Part Number645141
Replaces645141
ManufacturerBosch
Appliance TypeDishwasher
Part TypeDishwasher door seal sealing
✅ Cross Reference Information
Current Part Number00645141
Replaces645141
Common Symptoms
- Visible water at the front edges or below the dishwasher door
- A torn, cut, warped, hardened, or visibly gapped door seal
- Door does not make even contact with the tub opening
- Door-latch sensing or starting problems when the seal is improperly seated or unusually stiff
Check Before Replacing
- Inspect the entire seal for tears, cuts, warping, hardening, gaps, or displacement.
- With the door closed, check whether the seal makes consistent contact around the tub opening; a paper or dollar-bill contact check may help identify a gap.
- Confirm the seal is fully seated in its channel, especially at the corners and ends.
- If the dishwasher leaks, observe the leak location during a supervised cycle and first verify that the leak is occurring at the door seal area rather than at the lower door seal, hinges, or another component.
- If the door will not latch or the dishwasher will not start, verify that the seal is not displaced and that the appliance door is level and square before concluding that the seal is defective.
Pro Tip
After installation, keep the dishwasher door closed for several hours so the new seal can properly seat; recheck for uniform contact before operating normally.
Part Details
Part Number00645141
Part TypeDishwasher door seal sealing
ManufacturerBosch
Appliance TypeDishwasher
Primary FunctionForms a watertight seal between the dishwasher tub opening and the door perimeter to help prevent wash-cycle water from escaping.
Installation Notes
- Disconnect electrical power and follow the appliance-specific service instructions before beginning work.
- Remove the old seal and clean debris from the seal channel without damaging the channel.
- Press the replacement seal firmly and evenly into the existing channel, ensuring it is fully seated and correctly positioned around the opening.
- Check that the door closes and latches normally, then perform a supervised leak check.
- Keep the door closed for several hours after installation to allow the seal to seat.
Verified Compatible Models
63013902010, 63013902011, 63013903010, 63013903011, 63013909010, 63013909011, 63013909012, 63013912010, 63013912011, 63013913010, 63013913011, 63013919010, 63013919011, S36KMK12UC, S36KMK12UC-05
Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
