Frigidaire / Electrolux Washer drive belt, 6-rib 134051000, Replaces 131276300

Genuine OEM 6-rib inner-tub drive belt connecting the washer drive motor to the wash basket or drum. Used in compatible belt-driven washers for spinning and agitation.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Slow or weak spinning
• Failure to agitate
• Burning-rubber smell
• Squealing or loud belt noise
• Washer will not drain because the drive system is not operating normally

Check Before Replacing

• Unplug the washer before inspection.
• Inspect the belt for breakage, fraying, cracking, glazing, missing ribs, or visible belt dust.
• With power disconnected, check whether the belt is seated correctly on the motor shaft and drive pulley.
• With power disconnected, manually rotate the drive pulley or basket as appropriate and check for obvious binding or abnormal resistance.
• Inspect the motor and drive pulleys for damage, contamination, or apparent misalignment before condemning the belt.

Pro Tip

Part Details

Key Features

• Genuine OEM Frigidaire/Electrolux washer drive belt
• Six-rib inner-tub drive belt
• Designed to connect the washer drive motor to the drive system
• Used in compatible washers and washer-dryer combinations

Installation Notes

• Disconnect electrical power before removing panels or handling the belt.
• Follow the model-specific service instructions because panel access and belt routing can vary.
• Install the belt with the ribbed side seated in the matching pulley grooves.
• After installation, confirm that the belt is fully seated and tracks correctly on both pulleys before restoring power and water connections.

Verified Compatible Models

CRTF1240AS0, CRTR9300AS0, FTF530ES0, FTR630AS0, FWTB8200DS0, FWTBB30DS0, GLEH1642DS0, GLGH1642DS0, GLTF530DS0, GLTF1040AS0, GLTF1240AS0, GLTF1670AS0, GLTF2070CS0, GLTF2070DS0, GLTR1670AS0

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
