3711-000240 HEADER-BOARD TO CABLE
3711-000240 HEADER-BOARD TO CABLE

Samsung Range Header-board to cable connector 3711-000240

$8.16
In stock and ready for shipping
Buying Options: OEM Genuine

Product variant with selected options does not exist!

Frequently Bought Together

Confirm This Fits Your Model
Not sure where to find your model number? See guide →
VERIFIED PART INFORMATION

Samsung Range Header-board to cable connector 3711-000240

Samsung 4-position, one-wall board-to-cable header connector with 3.96 mm pitch and a straight configuration.

Part 3711-000240Samsung

Samsung 4-position, one-wall board-to-cable header connector with 3.96 mm pitch and a straight configuration.

Is This the Right Part?

Part Number3711-000240
ManufacturerSamsung
Appliance TypeRange
Part TypeHeader-board to cable connector

Check Before Replacing

  • With power disconnected, compare the installed connector against the required four-position, 3.96 mm-pitch, straight header configuration before ordering or installing.

Pro Tip

Match the part number and connector configuration exactly; similar Samsung headers have different position counts, pitches, and orientations.

Part Details

Part Number3711-000240
Part TypeHeader-board to cable connector
ManufacturerSamsung
Appliance TypeRange
Primary FunctionProvides a four-position connection between a circuit board and a cable harness.

Key Features

  • 4-position (4P) header
  • One-wall (1WALL) configuration
  • Single-row (1R) configuration
  • 3.96 mm pitch
  • Straight configuration
  • Specified as SN

Installation Notes

  • Disconnect appliance power before servicing electrical components.
  • Confirm the board footprint and cable-side mating connector match the specified 4P, 3.96 mm, straight configuration.

Verified Compatible Models

NE597R0ABSR/AC, FTQ386LWUX/XAA, FTQ387LWGX/XAA, NE594R0ABSR/AA, NE59J3421SS/AC, CLP-325W/XAA, FCQ321HTUB/XAA, FE-N500WX/XAC, FTQ307NWGX/XAA, FTQ352IWUB/XAA, FTQ352IWUX/XAA/0001, FTQ353IWUX/XAA, FTQ386LWUX/XAA/0001, NE595N0PBSR/AA, NE595R0ABSR/AC, NE59J3420SW/AA

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
