3711-000270 HEADER-BOARD TO CABLE
3711-000270 HEADER-BOARD TO CABLE

Samsung Range/Stove/Oven; Microwave Header-board to cable connector 3711-000270

$8.16
In stock and ready for shipping
Buying Options: OEM Genuine

Product variant with selected options does not exist!

Frequently Bought Together

Confirm This Fits Your Model
Not sure where to find your model number? See guide →
INTERMITTENT APPLIANCE POWER OR OPERATION

Samsung Range/Stove/Oven; Microwave Header-board to cable connector 3711-000270, Fixes Intermittent appliance power or operation caused by a loose, damaged, or burned connector connection

Samsung header-board-to-cable wire connector with one wall, five positions, one row, and 3.96 mm pitch.

Part 3711-000270Samsung

Samsung header-board-to-cable wire connector with one wall, five positions, one row, and 3.96 mm pitch.

Is This the Right Part?

Part Number3711-000270
ManufacturerSamsung
Appliance TypeRange/Stove/Oven; Microwave
Part TypeHeader-board to cable connector

Common Symptoms

  • Intermittent power or operation
  • Appliance may turn off unexpectedly when the connector or wiring has a poor connection

Check Before Replacing

  • With appliance power disconnected, inspect the connector and adjoining wiring for looseness, broken conductors, discoloration, or burn marks.
  • Verify that the connector is fully seated and that its contact count and physical pitch match the original before replacement.

Pro Tip

Match the connector’s five-position, 3.96 mm configuration before ordering; Samsung uses several similar header-to-cable connectors.

Part Details

Part Number3711-000270
Part TypeHeader-board to cable connector
ManufacturerSamsung
Appliance TypeRange/Stove/Oven; Microwave
Primary FunctionProvides an electrical connection between a circuit-board header and the appliance cable harness.

Key Features

  • One wall
  • Five positions/contacts
  • One row
  • 3.96 mm pitch
  • Samsung genuine OEM part number 3711-000270

Installation Notes

  • Disconnect electrical power before inspecting or replacing the connector.
  • Replace only after confirming the connector configuration matches the original harness and board header.
  • Ensure the connector is fully seated after installation.

Verified Compatible Models

NE595R0ABSR/AC, NE597R0ABSR/AC, NE59J3420SS/AA, NE59J3420SW/AA, NE59J3421SS/AC, NE597N0PBSR/AA

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
