Samsung Range Header-board to cable 3711-000321

Samsung 7-position board-to-cable header connector: 1-wall, 7-pin, 1-row, 3.96 mm pitch, straight, solder, white.

Is This the Right Part?

Common Symptoms

• Intermittent or lost electrical connection caused by a damaged, loose, or heat-affected connector.

Check Before Replacing

• With power disconnected, inspect the connector body and solder joints for cracking, discoloration, melting, bent contacts, or signs of overheating.
• Verify that the mating cable is fully seated and that the connector is not loose on the circuit board.

Pro Tip

Part Details

Key Features

• 1-wall construction
• 7 pins
• 1 row
• 3.96 mm pitch
• Straight configuration
• Solder termination style based on Samsung service documentation‌

Installation Notes

• Disconnect appliance power before inspecting or replacing this connector.
• Use the appliance service documentation for the correct board location and solder-repair procedure; do not force the mating cable into place.

Verified Compatible Models

FE-N500WX/XAC, FE-R700WX-XAC, FTQ386LWUX/XAA, FTQ386LWX/XAC, FTQ387LWGX/XAA, NE597N0PBSR, NE597R0ABSR/AC, FEN500WXXAA, NE595N0PBSR/AA, NE597R0ABSR/AA, FER700WXXAC

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
