ACDelco Gold Steering Drag Link 45A0920

XPart Number XP10576051
$105.40
Available by special order
Buying Options: OEM Genuine

Choose an available buying option.
Available by special order
Check Fit & Find Parts
Bubba checks verified models, product descriptions, cross-references and store data. Find your model number →

Frequently Bought Together
AUTOMOTIVE PART

ACDelco Gold Steering Drag Link 45A0920

Steering Drag Link, Gold

Part 45A0920ACDelco GoldSteering Drag Link
Match your exact vehicle configuration to the verified applications below.
Confirm the year, make, model, engine, drivetrain and required position before ordering.

Is This the Right Part?

Manufacturer Part Number45A0920
ManufacturerACDelco Gold
Part TypeSteering Drag Link

Part Details

Part Specifications

Color Black
Grade Type Regular
Greaseable Yes
Length 241.3 MM
Length 9.5 IN
Material Steel
Mounting Hardware Included Yes
Mounting Hole Quantity 0
Stud Thread Diameter 14 MM

Verified Vehicle Fitment

Make: Dodge, Jeep
Model: 5 verified models — see exact combinations below.
Years: 2003–2018 — varies by model and configuration.

Check before ordering: Match the year, make, model, position, and every engine, transmission or other restriction in the same row. Listed years do not apply to every model.

View vehicle applications (22 configuration groups)
Years Make Model Position Engine / transmission / notes
2006–2007 Dodge Ram 1500 At Pitman Arm Drive Type: 4WD; Sub Model: Laramie; with 8 Lug Wheels, Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2007 Dodge Ram 1500 At Pitman Arm Drive Type: 4WD; Sub Model: SLT; with 8 Lug Wheels, Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2007 Dodge Ram 1500 At Pitman Arm Drive Type: 4WD; Sub Model: Sport; with 8 Lug Wheels, Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2007 Dodge Ram 1500 At Pitman Arm Drive Type: 4WD; Sub Model: ST; with 8 Lug Wheels, Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2008 Dodge Ram 1500 At Pitman Arm Drive Type: 4WD; with 8 Lug Wheels, Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2007 Dodge Ram 1500 At Pitman Arm Sub Model: TRX4; with 8 Lug Wheels, Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2008 Dodge Ram 2500 At Pitman Arm Drive Type: 4WD; Sub Model: Laramie; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2008 Dodge Ram 2500 At Pitman Arm Drive Type: 4WD; Sub Model: SLT; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2007 Dodge Ram 2500 At Pitman Arm Drive Type: 4WD; Sub Model: Sport; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2008 Dodge Ram 2500 At Pitman Arm Drive Type: 4WD; Sub Model: ST; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2008 Dodge Ram 2500 At Pitman Arm Drive Type: 4WD; Sub Model: SXT; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2003–2005 Dodge Ram 2500 At Pitman Arm Drive Type: 4WD; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2008 Dodge Ram 2500 At Pitman Arm Sub Model: Power Wagon; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2006–2007 Dodge Ram 2500 At Pitman Arm Sub Model: TRX4; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2007 Dodge Ram 3500 At Pitman Arm Steering Type: Gear; Sub Model: Laramie; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2007 Dodge Ram 3500 At Pitman Arm Steering Type: Gear; Sub Model: SLT; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2007 Dodge Ram 3500 At Pitman Arm Steering Type: Gear; Sub Model: Sport; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2007 Dodge Ram 3500 At Pitman Arm Steering Type: Gear; Sub Model: ST; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2003–2006, 2008 Dodge Ram 3500 At Pitman Arm Steering Type: Gear; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2007 Dodge Ram 3500 At Pitman Arm Sub Model: TRX4; Tapered Hole Mounted Steering Damper, 6.54 (in) Length
2007–2017 Jeep Wrangler At Pitman Arm No additional restrictions supplied; confirm exact configuration.
2018 Jeep Wrangler JK At Pitman Arm No additional restrictions supplied; confirm exact configuration.

Source: supplier-verified applications for ACDelco Gold 45A0920. A vehicle not listed is not confirmed compatible.
