DA82-01396A Samsung Refrigerator Ice Tray Assembly – Fix Your Ice Maker That Won't Make Ice, Makes Misshapen Ice, Leaks Water, Won't Eject Ice, or Makes Grinding Noises

Name: DA82-01396A Refrigerator Ice Tray Assembly - XPart Supply Ltd.
Brand: XPart Supply Ltd.
SKU: DA82-01396A
Price: 99.99 CAD
Availability: InStock

The DA82-01396A is a genuine OEM ice tray assembly for Samsung refrigerators. This complete assembly includes the ice tray, ejector mechanism, and mounting hardware needed to produce and dispense ice cubes. The tray fills with water, freezes it into ice cubes, and then ejects them into the ice bin for storage.

Over time, ice tray assemblies can fail due to cracking, motor wear, or mechanical damage. When the ice tray assembly fails, symptoms include ice maker won't produce ice, ice cubes are misshapen or hollow, water leaks from the ice maker area, ice won't eject from the tray, ice maker makes loud grinding or clicking noises, or ice production is slow or inconsistent. A damaged ice tray assembly prevents proper ice production.

This genuine Samsung part ensures proper fit and reliable operation. Engineered to exact specifications, it restores full ice-making functionality to your refrigerator.

IMPORTANT: Only use OEM ice tray assemblies for proper fit and ice quality. CRITICAL: Turn off ice maker and disconnect power before servicing.

✓ Model-Specific Repair Pages

MODEL RF263TEAEWW RF263TEAESR RF263BEAESR RF263BEAEBC RF30HBEDBSR/AA RF263TEAESR/AA RF263BEAEBC/AA RF263TEAEWW/AA RF263TEAEBC/AA RF263BEAEWW/AA RF263TEAEBC/AA RF263BEAEWW/AA RF323TEDBSR/AA RF323TEDBBC/AA RF30HBEDBSR/AA RF263BEAESR/AA RF323TEDBSR/AA RF323TEDBBC/AA

✅Compatibility & Cross Reference

Part number DA82-01396A replaces DA97-14474C, DA97-12604D

RF263BEAEBCAA, RF263BEAESR/AA, RF30HBEDBSR/AA, RF323TEDBBC/AA, RF323TEDBSR/AA, RF263BEAEWW/AA, RF263TEAEBC/AA, RF263TEAEWW/AA, RF263BEAEBC/AA, RF263TEAESR/AA

Why is my Samsung ice maker not making ice?

A Samsung ice maker that stops producing ice can be caused by several things — check these in order of likelihood: (1) Ice maker turned off — verify the ice maker is switched on. Press the Ice Maker button on the display or check the switch inside the freezer. (2) Water supply issue — the ice maker needs water to make ice. Check that the water supply valve behind the refrigerator is fully open, the water line isn't kinked, and the water filter isn't overdue for replacement (a clogged filter restricts flow to the ice maker). Listen when the ice maker fills — you should hear a brief buzzing sound as the water inlet valve opens. No sound means the valve isn't getting power or is clogged. (3) Freezer temperature too warm — the freezer must be at 0°F or below for ice to form properly. If the freezer is above 10°F, ice won't freeze in the tray. Check the temperature setting and verify the freezer is cooling properly. (4) Frozen fill tube — the small tube that delivers water to the ice tray can freeze solid, blocking water flow. Thaw it with warm water using a turkey baster. (5) Cracked or warped ice tray — if water fills the tray but leaks out before freezing, or ice forms but won't eject, the tray is damaged. Replace the ice tray assembly. (6) Failed ice maker motor or heater — if the tray fills and freezes but the ice maker never runs the harvest cycle (no motor sound, no ejection attempt), the motor or control module has failed.
