The actuator mode shifter is the electromechanical component that shifts the drive system between agitation mode and spin mode during the wash cycle. It receives a signal from the main control board and physically engages or disengages the agitator drive shaft from the spin basket. When it fails, the washer loses the ability to switch modes — it may agitate but never spin, spin but never agitate, or stall entirely with a drive-related error code. Part WG04F12302 is the OEM GE actuator mode shifter for compatible GE, Hotpoint, and Kenmore top-load washers, replacing WG04L05391, WH05X25036, and WH03X30517. OEM and premium XPart options available.
⚠️ Symptoms This Part Fixes
- Washer agitates but will not spin
- Washer spins but will not agitate
- Drum does not engage at the start of the cycle
- Washer fills and drains but the drum never moves
- Clicking or grinding noise when the machine attempts to switch between agitation and spin
- Drive-related error codes on the control panel
- Washer stops mid-cycle when transitioning from wash to spin
- Agitator moves weakly or intermittently
✓ Part Details
- OEM Part Number: WG04F12302
- Replaces / Cross-References: WG04L05391, WH05X25036, WH03X30517
- Component: Actuator mode shifter assembly — shifts drive system between agitation and spin modes
- Compatible Brands: GE, General Electric, Hotpoint, Kenmore
- OEM Option (WG04F12302): Genuine GE factory mode shifter — exact fit, no modifications
- XPart Option (WH03X30517CM): Premium aftermarket mode shifter engineered to OEM spec. Direct fit. Not affiliated with or endorsed by GE.
⚙️ Installation Notes
- Skill Level: Intermediate — 30 to 45 minutes
- Disconnect power and turn off the water supply before starting
- Remove the agitator (if equipped) and the wash basket to access the drive assembly below
- The mode shifter is mounted on the drive motor/gearcase assembly at the bottom of the tub
- Photograph the wiring harness connections before disconnecting
- Disconnect the harness, remove the mounting screws, and swap the shifter assembly
- Reconnect the harness in the same positions, reassemble the basket and agitator, restore power, and run a diagnostic cycle to confirm agitation and spin both engage correctly
- If the washer still fails to shift after replacement, check the main control board output signal to the shifter before condemning the new part
✓ Compatible Models
Fits compatible GE, Hotpoint, and Kenmore top-load washers. Contact us at xpartsupply.com/pages/contact with your full model number to confirm fit before ordering.
The motor coupling is a three-piece plastic and rubber coupler between the motor and the transmission. When it breaks, the motor runs but neither agitation nor spin engages — identical to a failed mode shifter. The coupling costs a fraction of the shifter and takes 15 minutes to replace. Test it first: if the motor hums but nothing moves, pull the coupling before ordering the shifter. If the washer agitates fine but won’t spin (or vice versa), the mode shifter is the correct diagnosis.
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
