VERIFIED PART INFORMATION
Samsung Dryer IC-PLD MICOM DC13-00209A
Samsung IC-PLD MICOM integrated circuit identified as T8741NG-6NA5/FMDRY, 64-pin, 4.5V, for select Samsung dryers.
Part DC13-00209ASamsung
Samsung IC-PLD MICOM integrated circuit identified as T8741NG-6NA5/FMDRY, 64-pin, 4.5V, for select Samsung dryers.
Is This the Right Part?
Part NumberDC13-00209A
ManufacturerSamsung
Appliance TypeDryer
Part TypeIC-PLD MICOM
Check Before Replacing
- Verify the appliance model number against a documented compatibility listing before ordering.
- Compare the marking and pin configuration of the failed component with the replacement specification before installation.
Pro Tip
This is a board-level electronic component; confirm the exact dryer model and control-board application before purchase.
Part Details
Part NumberDC13-00209A
Part TypeIC-PLD MICOM
ManufacturerSamsung
Appliance TypeDryer
Primary FunctionDryer control-board microcontroller/programmable logic device.
Key Features
- T8741NG-6NA5/FMDRY designation
- 64-pin package
- 4.5V specification
- Samsung dryer application
Installation Notes
- Disconnect electrical power before servicing the dryer.
- Use appropriate electrostatic-discharge precautions when handling the integrated circuit.
- Replacement may require board-level soldering or electronics repair expertise.
Verified Compatible Models
DV206AES/XAA, DV206LEW/XAC, DV2C6BEW/XAC, DV306LEW/XAA, DV316BEC/XAA, DV316BEW/XAA, DV316LEW/XAA, DV316LGS/XAP, DV317AES/XAA, DV3C6BGW/XAX, DV316BGC/XAA, DV316LES/XAA, DV316LGS/XAA, DV316LGW/XAA, DV316LES/XAA (0001), DV316LGS/XAA (0002)
Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
