Samsung Dryer Assembly Bracket Motor DC96-00790C

Samsung dryer motor-bracket assembly for the MDE9700AYW dryer design. The assembly includes the motor bracket, tension spring, belt-break micro-switch, switch cover, and idler-bracket assembly.

Is This the Right Part?

Common Symptoms

• Drive belt may not remain properly tensioned if the integrated idler mechanism is damaged or seized.
• Dryer operation may be interrupted if the integrated belt-break micro-switch is not mechanically actuated.

Check Before Replacing

• With power disconnected, inspect the motor bracket and integrated idler assembly for visible damage, distortion, or looseness.
• With power disconnected, check that the idler mechanism moves freely and applies tension to the drive belt.
• Verify that the belt-break micro-switch is mechanically actuated by the belt/bracket mechanism before replacing the complete assembly.

Pro Tip

Part Details

Key Features

• Genuine Samsung part number DC96-00790C.
• Motor-bracket assembly designation: MDE9700AYW dryer.
• Includes micro-switch 3405-001077.
• Includes motor bracket DC61-01213A.
• Includes tension spring DC61-01215B.
• Includes switch cover DC63-00919A and idler-bracket assembly DC96-00882C.

Installation Notes

• Disconnect electrical power before inspecting or replacing the assembly.
• Confirm the belt, idler mechanism, and belt-break switch are correctly positioned before returning the dryer to service.
• Verify exact model compatibility before ordering because the assembly is model-specific.

Verified Compatible Models

40289032011, 40299032010, 40299032011, DV2C6BEWXAA, DV2C6BGW, DV2C6BGW/XAA, DV2C6BGWXAA, DV40J3000EW/A2, DV40J3000EW/AC, DV40J3000GW/A2, DV42H5000EW/A3, DV42H5000EW/AC, DV42H5000GW/A3, DV42H5200EP/A3, DV42H5200EP/AC, DV42H5200EW/A3, DV42H5200EW/AC, DV42H5200GP/A3, DV42H5200GW/A3, DV42H5400EF, DV42H5600EP/AC, DV42H5600GW/A3-00, DV45H6300EG/A3, DV45H6300EW/AC-00, DV45H7000EW/A2, DV45H7000EW/AC, DV45H7000GW, DV45H7000GW/A2, DV45K6500EV/A3, DV45K6500GV/A3, DV45K6500GW/A3, DV45K7600EW/A3, DV48J7700EW/A2, DV48J7700GW/A2, DV48J7770EP/A2, DV48J7770EW/A2, DV48J7770GP/A2, DV48J7770GW/A2, DV50K7500EV/A3, DV50K7500EW/A3, DV50K7500GV/A3, DV50K7500GW/A3, DV50K8600EV/A3, DV50K8600EV/AC, DV206LEW/XAC, DV209AEW/XAA, DV210AEW/XAA, DV218AEB, DV219AEW/XAA-02, DV219AGW/XAA, DV220AGW/XAA-02, DV229AEG/XAC, DV306LEW/XAA, DV316LEW, DV316LEW/XAA, DV316LGW, DV316LGW/XAA, DV317AEG, DV317AEG/XAA, DV317AEGXAA, DV317AES, DV317AES/XAA, DV317AESXAA, DV317AEW, DV317AEW/XAA, DV317AEWXAA, DV317AGG, DV317AGG/XAA, DV317AGGXAA, DV317AGS, DV317AGS/XAA, DV317AGSXAA, DV317AGW, DV317AGW/XAA, DV317AGWXAA, DV328AER/XAA, DV328AEW/XAA-01, DV331AEW/XAA, DV337AEG, DV337AEG/XAA, DV337AEGXAA, DV337AEL, DV337AEL/XAA, DV337AELXAA, DV337AER, DV337AER/XAA, DV337AERXAA, DV337AEW, DV337AEW/XAA, DV337AEWXAA, DV337AGG, DV337AGG/XAA, DV337AGGXAA, DV337AGL, DV337AGL/XAA, DV337AGLXAA, DV337AGR, DV337AGR/XAA, DV337AGRXAA, DV337AGW, DV350AEP/XAC, DV350AEW/XAA, DV350AGW/XAA-02, DV350AGW/XAA-04, DV363EWBEUF/A1-00, DV365ETBGWR/A3-01, DV393ETPAWR/A1, DV393ETPAWR/A1-01, DV395ETPASU/A1, DV405ETPASU/AC-IN01, DV405GTPASU/AA-01, DV409AER/XAA-00, DV409AER/XAA-0001, DV410AEW/XAC, DV419AES, DV431AEP/XAA-01, DV431AEW/XAA-02, DV433GTGJWR/A1-00, DV448AEW/XAC, DV457GVGSGR/AA, DV511AER/XAA, DV520AEP/XAA-01, DV520AEW/XAA-01, DV520AGP/XAA-02, DV520AGW/XAA-03, DV5451AEW/XAA, DV5451AEW/XAC, DV5451AGW/XAA, DV5471AEP/XAA, DV5471AEP/XAA-00, DV5471AEW/XAA, DV5471AGP/XAA, DV5471AGP/XAA-03, DV5471AGW/XAA, 402.89032010, 402.89032012, 402.99032012, DV2C6BEW, DV2C6BEW/XAA, DV203AGS, DV203AGS/XAA, DV203AGSXAA, DV203AGW, DV203AGW/XAA, DV203AGWXAA, DV206AES, DV206AES/XAA, DV206AESXAA, DV231AGW, 402.89032011, 402.99032010, 402.99032011

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
