When the drive hub fails, your washer goes through the motions but clothes come out soaking wet — the drum fills, agitates weakly or not at all, and the spin cycle produces nothing. The W10324651 is the genuine OEM drive hub kit for Whirlpool and Kenmore top-load direct-drive washers, reconnecting the wash basket to the motor shaft with precision-machined splines and factory-calibrated torque capacity. Stripped or worn hubs are one of the most common causes of spin failure on this platform, and aftermarket kits routinely use inferior steel that strips again within months. Fix it once with the part Whirlpool engineered for this drivetrain.
⚠️ Symptoms of a Failed Washer Drive Hub
- Washer won't spin — drum fills and drains but clothes come out soaking wet
- Loud grinding, clicking, or banging during agitation or spin
- Wash basket feels loose or wobbles when pushed by hand
- Washer agitates but won't reach full spin speed
- Visible stripped splines on the hub when inspected from below
- Metal shavings or debris found in the wash basket or tub
- Burning smell during spin cycle — motor overloading against a slipping hub
✓ Part Details
- OEM Part Number: W10324651
- Part Type: Washer Drive Hub Kit (Drive Hub Assembly / Basket Drive Kit / Spin Hub)
- Fits: Whirlpool and Kenmore top-load washers with direct-drive transmission
- Construction: Precision-machined heat-treated steel, corrosion-resistant coating
- Torque Capacity: Exceeds 100 ft-lbs — engineered for high-torque spin and agitation loads
- Includes: Drive hub body, mounting bolts, retaining hardware
- Condition: Genuine OEM — new in manufacturer packaging
- Typical Lifespan: 10–15 years; failures most often caused by wear from repeated high-torque cycles, corrosion from water exposure, or foreign object damage
💡 Pro Tip — Inspect the Transmission Shaft and Tub Seal While You're In There:
Replacing the drive hub requires removing the wash basket — which gives you direct access to the transmission shaft, the tub seal, and the basket bearing. A worn tub seal is the #1 cause of water leaking into the transmission and corroding the drive hub in the first place. If you see rust staining, water residue, or a worn seal lip around the shaft, replace the tub seal at the same time. It's a $15–25 part and adds 20 minutes to a job you're already doing — skipping it means the new hub may fail for the same reason within a year.
Replacing the drive hub requires removing the wash basket — which gives you direct access to the transmission shaft, the tub seal, and the basket bearing. A worn tub seal is the #1 cause of water leaking into the transmission and corroding the drive hub in the first place. If you see rust staining, water residue, or a worn seal lip around the shaft, replace the tub seal at the same time. It's a $15–25 part and adds 20 minutes to a job you're already doing — skipping it means the new hub may fail for the same reason within a year.
⚙️ Installation Notes
- Skill Level: Intermediate — washer cabinet removal and basket extraction required
- Always disconnect power and water supply before servicing
- Access requires tipping the washer back or removing the front/rear cabinet panel depending on model
- Photograph the hub and spline engagement before removal for reference during reinstallation
- Clean the transmission shaft of any rust, debris, or old lubricant before installing the new hub
- Follow OEM torque specifications on mounting bolts — under-torquing causes slippage; over-torquing cracks the hub body
- Verify spline engagement and basket alignment before reassembling the cabinet
- Run a test cycle with a small load after reassembly — listen for grinding or vibration before returning to full service
✓ Compatible Models
Fits Whirlpool and Kenmore top-load washers with direct-drive transmission systems. Verify your model number against W10324651 before ordering. Model tag is located inside the lid frame or on the rear panel. Contact XPart Supply for fitment confirmation.
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
