Whirlpool Washer Basket Drive Assembly with Clutch W10820043, Replaces 285209, 285542, 285757, 285792, 3347182, 387948, 388951, 388952, 388953, 62656, 62659, 62706, 62959, 62993, 63388, 63390, 64033, 64135, 64197, 64234,

Inner basket drive kit for direct-drive washers. It sits on top of the transmission shaft, houses the spin-basket brake mechanism, and rotates the basket during the spin cycle. The assembly includes the basket drive, brake and clutch components, and installation instructions.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Basket does not spin or spins slowly
• Clothes remain wet at the end of the cycle
• Loud or grinding noise during spin
• Basket vibration or shaking during spin
• Hard or abrupt stopping at the end of spin

Check Before Replacing

• With power disconnected, inspect the basket drive and surrounding area for obvious wear, stripped tabs, corrosion, or oil contamination.
• Check whether the spin-tube tabs and basket drive block are visibly worn or stripped before attributing the problem to the basket drive.
• Observe whether the inner basket rotates normally during a spin-only cycle; do not reach into or restrain a moving basket.
• If the clutch pads appear worn or contaminated and the drive block and spin-tube tabs are in good condition, the basket drive assembly may be implicated; confirm with the appliance’s service documentation or a qualified technician.

Pro Tip

Part Details

Key Features

• Whirlpool OEM basket drive assembly
• Includes the basket drive, brake, and clutch components
• Mounts on top of the transmission shaft
• Designed for direct-drive washer spin systems
• Replacement assembly covers multiple earlier Whirlpool part numbers

Installation Notes

• Disconnect electrical power and shut off the washer’s water supply before beginning service.
• Use work gloves when handling the assembly and washer cabinet or tub components.
• Installation requires access to the basket-drive/brake area and may require removal of the washer access panel and related tub components.
• Follow the model-specific service instructions; the assembly is a moderate-to-advanced mechanical repair and may require specialized tools.
• After installation, verify that the basket rotates freely by hand before reconnecting power and testing the washer.

Verified Compatible Models

6MAL5143VW0, 6MAX5133VW0, 11023032102, 11024942300, 11024942301, 11024944300, 11024944301, 11024952300, 11024952301, 11082427630, LA5500XTF1, LA5580XSF2, LA5580XSN3, LA9800XSN2, MVWC500VW1

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
