Whirlpool Dishwasher Circulation Pump Motor W11084656 Replaces W10854710, W10805387

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Dishes on both racks not getting clean — food residue after a full cycle
• No water spray audible during the wash phase — dishwasher runs silently
• Weak or uneven spray — upper rack dishes consistently dirtier than lower
• Grinding, humming, or buzzing noise from the pump area during the wash cycle
• Dishwasher fills and drains normally but dishes are never cleaned
• Error codes related to wash motor or circulation failure on display

Check Before Replacing

• Confirm the dishwasher fills with water at the start of the cycle — a failed inlet valve mimics pump failure
• Verify the drain pump is functional — water should drain completely at end of cycle
• Remove and inspect the spray arms — clogged spray arm holes cause identical symptoms at a fraction of the cost
• Test the motor capacitor with a multimeter — a failed capacitor causes the motor to hum but not spin
• Check for visible burn marks, seized bearings, or damaged wiring on the existing motor assembly

Part Details

Verified Compatible Models

2212413N414, 2213092N413, 2213099N413, 2213222N414, 2213223N414, 2213229N414, 2213479N413, 2214523N611, 2214545N711, 2214573N612, 66512413N413, 66513092N413, 66513093N413, 66513202N413, 66513204N413, 66513209N413, 66513223N414, 66513229N414, 66513355N020, 66513472N413, 66513479N413, 66513542N414, 66513543N414, 66513549N414, 66514522N611, 66514523N611, 66514529N611, 66514543N711, 66514549N711, 66514562N611, ADB1500ADB4, ADB1500ADS4, ADB1500ADW4, ADB1700ADB4, ADB1700ADS4, ADB1700ADW4, IDT830SAGS0, KDFE104DBL5, KDFE104DSS5, KDFE104DWH5, KDFE104HBL0, KDFE104HBL1, KDFE104HBS0, KDFE104HBS1, KDFE104HPS0, KDFE104HPS1, KDFE104HWH0, KDFE104HWH1, KDFE204EBL4, KDFE204ESS4, KDFE204EWH4, KDPE204GBS0, KDPE204GPS0, KDPE234GBS0, KDPE234GPS0, KDTE104EBL4, KDTE104EBS4, KDTE104ESS4, KDTE104EWH4, KDTE204EBL4, KDTE204EPA4, KDTE204ESS4, KDTE204EWH4, KDTE204GPS0, KDTE204GPS1, KDTE234GBL0, KDTE234GBL1, KDTE234GBS0, KDTE234GBS1, KDTE234GPS0, KDTE234GPS1, KDTE234GWH0, KDTE234GWH1, KDTE304GPS0, KDTE304GPS1, WDF560SAFB2, WDF560SAFM2, WDF560SAFT2, WDF560SAFW2, WDF590SAJB0, WDF590SAJM0, WDF590SAJW0, WDF770SAFZ2, WDT705PAKB0, WDT705PAKW0, WDT710PAHB1, WDT710PAHW1, WDT710PAHZ1, WDT720PADB3, WDT720PADE3, WDT720PADH3, WDT720PADM3, WDT720PADW3, WDT730PAHB0, WDT730PAHV0, WDT730PAHW0, WDT730PAHZ0, WDT750SAHB0, WDT750SAHM0, WDT750SAHV0, WDT750SAHW0, WDT750SAHZ0, WDT970SAHB0, WDT970SAHV0, WDT970SAHW0, WDT970SAHZ0, WDT995SAFM0, WDTA50SAHB0, WDTA50SAHM0, WDTA50SAHN0, WDTA50SAHV0, WDTA50SAHW0, WDTA50SAHZ0

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
