Whirlpool Refrigerator Evaporator Fan Motor with Wire Harness W11249952, Replaces W10701003, W11039078, W11109595

Genuine Whirlpool refrigerator freezer evaporator fan motor and wire-harness assembly. Includes a thermistor and defrost thermostat; documented specifications are 12 VDC, 2750 RPM, and 2.5 W. It circulates air through the refrigerator/fresh-food compartment for cooling.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• Fan does not run
• Intermittent fan operation
• Unusually loud or vibrating fan noise
• Freezer temperature rises or cooling becomes uneven
• Frost or cold-air distribution problems associated with loss of evaporator airflow

Check Before Replacing

• With the refrigerator unplugged, visually inspect the fan blade and confirm it is not obstructed by ice or debris.
• With power disconnected, carefully check whether the fan blade turns freely without binding.
• Listen for abnormal grinding, rattling, or cycling noises during normal operation, without removing safety covers while energized.
• Inspect the included wire harness and connectors for visible damage, looseness, or broken wires.
• If the appliance has a manufacturer service-test function, use the model-specific procedure to command the evaporator fan on; do not perform live-voltage testing unless qualified.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool evaporator fan motor and wire-harness assembly
• Includes thermistor and defrost thermostat
• 12 VDC rating
• 2750 RPM
• 2.5 W
• Designed for refrigerator evaporator-air circulation

Installation Notes

• Unplug the refrigerator or disconnect its circuit before installation.
• Safely protect or remove food that could deteriorate while the appliance is powered off.
• Wear work gloves when handling the assembly and nearby sheet-metal components.
• After installation, reconnect the harness securely and confirm that the fan blade is unobstructed before restoring power.
• Follow the appliance model's service documentation for access-panel removal and final testing.

Verified Compatible Models

KRMF606ESS00, KRMF606ESS01, KRMF706EBS00, KRMF706EBS01, KRMF706EBS04, KRMF706ESS00, KRMF706ESS01, KRMF706ESS02, KRMF706ESS04, WRV976FDEM00, WRV976FDEM01, WRV986FDEM00, WRV986FDEM01, WRV996FDEE00, WRV996FDEE01, WRV996FDEE02, WRV996FDEH00, WRV996FDEH01, WRV996FDEM00, WRV996FDEM01

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
