6" Burner Won't Heat or Heats Unevenly – Fix Your Range Coil Element Fast
A failed 6" coil surface element is one of the most common causes of a dead or underperforming small burner on Whirlpool, Amana, and related brand electric ranges. When the element fails, that burner produces no heat or heats unevenly — making everyday cooking unreliable. ⚡ Order before 4 PM for same-day processing. Part W11396792 is the direct OEM replacement with pigtail ends that restores full burner performance with no modification required. XPart alternative SU31058 also available.
❓ Is This the Right Part?
This is the correct fix if ALL of the following are true:
- ✔ Your range is a Whirlpool, Amana, or related brand electric coil-top model in the ACR, WEC, WFC, or WFC315 series
- ✔ You need the 6-inch small burner element (for the 8'' element, order W11396790)
- ✔ The burner does not heat, heats slowly, or glows unevenly
- ✔ Your current element part number is W11396792, W11255551, W11199519, or W11364018
- ✔ ONLY problem is the surface element — not the infinite switch, receptacle block, or wiring harness
🔧 Common Symptoms
- Small burner produces no heat at any setting
- Burner heats slowly or takes much longer than normal
- Uneven glow — element red in spots, dark in others
- Visible burn marks, cracks, or blistering on the coil
- Burner trips the breaker when turned on
- Sparking or arcing at the pigtail terminal connections
✔ If these symptoms match, the 6" coil surface element is the most likely failed component.
✔ In most cases, replacing this element restores full burner performance immediately.
📦 Part Details
- Part Number: W11396792
- Type: 6" Coil Surface Element with Pigtail Ends
- Replaces: W11199519, W11255551, W11364018, WB30X31058, 53045161160 (no modification required)
- XPart Alternative: SU31058
- Brands: Whirlpool, Amana, KitchenAid
- Note: For the 8'' large burner element, order W11396790
⚙️ Installation Notes
Skill Level: Easy — 5–10 min. Disconnect power or unplug the range before beginning. Lift the failed element slightly and pull the pigtail terminals straight out of the receptacle block — no tools required. Align the new element's pigtail ends with the receptacle and press firmly until fully seated. Do not force or bend the terminals. Restore power and test on high heat to confirm even glow across the full coil.
💡 Pro Tip
With the element removed, check the receptacle block for burn marks, melted plastic, or loose contacts. A damaged receptacle will burn out your new element prematurely — and it's the #1 cause of repeat element failures. If you see any heat damage, replace the receptacle block at the same time. It's a 15-minute add-on that protects your repair and prevents a callback.
ACR4303 Series Repair Hub, WEC310S0 Series Repair Hub, WFC310S0 Series Repair Hub, WFC315S0 Series Repair Hub
✓ Model-Specific Repair Pages
✅Compatibility & Cross Reference
Not sure about your model number? Call 1-877-899-7278 and we’ll help you confirm. All brand names are the property of their respective owners and are used for compatibility reference only.
