Whirlpool Refrigerator icemaker assembly W11557002, Replaces W11091220, W11262316, W11391035, W11414318

Genuine Whirlpool OEM refrigerator icemaker assembly. The assembly includes the ice mold and control device; it receives water, freezes it, ejects the ice, and refills automatically.

Is This the Right Part?

✅ Cross Reference Information

Common Symptoms

• No ice or very little ice despite the refrigerator being cold enough
• Ice production stops because the icemaker is off or its control arm is obstructed
• Ice production is reduced when water flow is restricted by the filter, supply line, or fill path
• Water may overflow or leak if the icemaker is unlevel or the fill cup is misaligned

Check Before Replacing

• Confirm the icemaker is switched on and that its control or feeler arm can move freely without obstruction.
• Verify the refrigerator has an active water supply and that the water shutoff valve is open.
• Check whether the water filter is correctly installed and allowing normal water dispensing.
• Visually inspect the icemaker mold, fill cup, and accessible fill-tube area for ice blockage or obvious misalignment; do not pry on frozen components.
• Allow the freezer to reach normal operating temperature and observe whether the icemaker completes a harvest-and-refill cycle before concluding that the assembly has failed.

Pro Tip

Part Details

Key Features

• Genuine Whirlpool OEM refrigerator icemaker assembly
• Includes the ice mold and control device
• Performs automatic freeze, eject, and refill functions
• Replaces archived Whirlpool numbers W11091220, W11262316, W11391035, and W11414318

Installation Notes

• Disconnect electrical power before servicing the refrigerator and follow the refrigerator's model-specific service instructions.
• Shut off the water supply if the service procedure requires disconnecting the icemaker water connection.
• Reconnect the wiring harness and water connection securely, keeping the fill path aligned with the icemaker fill cup.
• After installation, restore power and verify that the icemaker is enabled and completes a fill/harvest cycle before returning the appliance to normal use.

Verified Compatible Models

JFFCC72EFP02, JFFCC72EFS02, JFFCC72EFS03, JFFCC72EFS04, JFFCC72EHL01, JFFCC72EHL02, JFFCC72EHL03, JFFCC72EHL04

Fitment reminder: Match the complete appliance model number, including suffix or revision where applicable, before ordering.
